Display a white background with a bright image at full page setting on

the monitor, using such applications as MicrosoftWord, Excel or Paintbrush.

To begin the setup/adjustment of the NEC MultiSync LCD1525V

monitor, push the Proceed button on the front bezel of the monitor to

bring up the NEC

On Screen Manager

.

Press the right arrow to highlight the „AUTO‰ tab and to select the

„AUTO ADJUST‰ menu in green.

Press the š„PROCEED‰ button to initiate the

Auto Adjust

Function

(This function will take a few seconds to be completed).

Press EXIT to close the OSM



 menu.

NEC Technologies, Inc. MultiSync



LCD1525V 





Setup instructions for Windows



95/98 & NT Computers

For Optimal Performance

the MultiSync LCD

1525V

should be set up for

1024x768 @ 60Hz.

Once you have booted up your computer and have entered Windows, please follow the instructions below

to fully optimize your MultiSync LCD monitor.

Step 1 Auto Adjust your MultiSync LCD monitor.

see reverse side

(Proceed to Step 2.)

Part No.78658652

Printed in Japan

Step 3 Auto Adjust.

As soon as your computer is set to 1024x768 resolution, the monitor automatically activates the

Auto Adjust Function. This function is activated only when the new video signal is received for the first

time. If the image quality after the Auto Adjust is activated is not sufficient, please repeat Step1.

On the right side of the Display Properties window, there is a box labeled Display

area. Make sure the „Screen‰ slide bar (6)(6)

(6)(6)

(6) is set to 1024x768.

You may have to restart your computer for this change to take effect. After the restart,

double check the Display Properties/Settings window to make sure you are

now at 1024x768 resolution.

(Proceed to Step 3.)

2

1

3

4

5

6

Step 2 Make sure your computer is set up for 1024x768 resolution.

Open the Display Properties window by following this mouse click sequence ((

((

(11

11

1

, 2, 3, 4, & 5), 2, 3, 4, & 5)

, 2, 3, 4, & 5), 2, 3, 4, & 5)

, 2, 3, 4, & 5) indicated

by the numbered arrows below.

If you have questions regarding the setup of your MultiSync LCD monitor, please refer to the user’s manual

or contact the NEC Technical Support Center at 1-800-632-4662.
