NEC PlasmaSync 42XR5 Bedienungsanleitung

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com Page 1 of 11PX-42XR5

Contents:

Product Description and Notes Page 1

Ventilation Requirements Page 2

Display Dimensions

Front, Top & Bottom Page 3

Rear Page 4

Left & Right Side Page 5

Display Dimensions w/Optional Speakers and Stand Page 6

Optional Speakers and Stand Dimensions__ Page 7

Dimensions w/Optional Wall Mount Page 8

Dimensions w/Optional Ceiling Mount Page 9

Connections Page 10

Control Codes Page 11

Product Description

Type: Plasma Display Screen Surface: Anti-Reflective

Resolution: 1024x768 Dimensions: 40”(W) x 24”(H) x 3.9”(D)

Aspect Ratio: 16:9 Weight: 59.5 lbs

Color Correction: Bonded Color Filter FCC: Class B

Notes

This document is intended to be used as a reference guide to supply useful information for a design or installation. It is not intended to

be a step-by step procedure for installation.

Any ceilings or walls must be strong enough to support the display and the installation must be in accordance with any local

building codes. All mounts should make secure contact to wood studs.

4:3 sources can be displayed on the 16:9 screen in either normal aspect ratio with bars on the left or right, or stretched horizontally to

fill the screen using the menus (see “Aspect Modes” in menus and user manual).

Distances are in inches, for millimeters multiply by 25.4.

Distances may vary ±5%.

Maximum Tilt Angles

Below is the maximum angle that the display can be tilted

Landscape 30°

Max Tilt

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 2 of 11

Ventilation Requirements (all models)

Dimensions below are minimum required for proper ventilation.

NOTE: The ventilation space should not be covered or closed off at the front of the opening. If for some reason the

opening needs to be covered, other means of ventilation will need to be incorporated into the design. Contact NEC for

design review and recommendations.

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 3 of 11

Display dimensions

40.2

Control Buttons

AC Inlet Speaker Terminal

Power Button

12.28

0.79

IR Receiver

1.86

1.76

14.61 6

2.74

1.72

3.89

4.79

0.74

0.81

11.3 17.61

0.12

1.6 2.26

Ventilation Openings

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 4 of 11

Display dimensions (cont.)

AC IN

(forSPEAKERM8x4)

for PC

4-M4 DEPTH 10

for mount unit

8-M4 DEPTH 16

for mount unit

6-M8 DEPTH 18

17.52"

4.02"

0.87"

20.87"

19.53"

4.96"

5.12"

4.96"

5.91"

20.87"

37.56"

NAME LABEL

for speaker

M8 DEPTH12

19.09"2.4"

10.45"

9.72"

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 5 of 11

Display dimensions (cont.)

0.50

1.59

3.86

0.60

4.00

8.46 11.6

0.85

25.84

22.64

0.58

2.13

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 6 of 11

Dimensions with optional speakers and stand

26.93

15.59

7.0 5.0

1.06

3.19

15.19

27.2

47.0

3.0

0.02

3.0 0.02

2.05

0.85

0.09

4.72

11.06

0.24 3.62

3.86

0.34 23.0 0.34

Optional Speakers

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 7 of 11

Optional Speakers and Stand Dimensions

Table Top Stand (PX-ST4U)

CAUTION

8.81

15.59

26.93

27.87

3.21

0.85

0.47

Optional Speaker (Part# PX-SP4U)

4.92

23.00

3.15

1.10

3.62

17.91

0.94

1.73

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 8 of 11

Dimensions with optional Wall Mount Kit (4250WMK)

FF F F

20.87

9.10

5.05

AC IN

6.70

2.98

8.73

4.31

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 9 of 11

Dimensions with optional Ceiling Mount Kit (4250CMK)

FF F F

20.87

AC IN

8.30

4.57

Note: Optional Accessories

not included with 4250CMK

NEC Corporation of America

Visual Systems Division

42XR5 Installation Guide

42” Plasma Display Rev 1.0

www.necvisualsystems.com PX-42XR5 Page 10 of 11

Connections

Ext. Speaker Connections

Power Switch

AC Inlet

Control Panel

Located at bottom of display
