NEC MultiProfiler Bedienungsanleitung

Version

1.0.05

User’s Guide

2| MULTIPROFILER - USER’S GUIDE

Software Updates

Occasionally updates and enhancements to the MultiProler software will be made available. Visit the MultiProler

section of the NEC DISPLAY SOLUTIONS website to check for availability, or use the Check for updates feature in the

software to automatically see if a newer version is available.

NEC DISPLAY SOLUTIONS welcomes feedback and suggestions for product improvements. Please use the feedback

from on the MultiProler section of the NEC DISPLAY SOLUTIONS website.

Technical Support and Feedback

For technical support with the MultiProler product, please visit the MultiProler section of the NEC DISPLAY SOLUTIONS

website and check for any Frequently Asked Questions that may help to solve the issue. An online feedback form is

available for submitting questions and feedback.

Trademarks and Copyright

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States

and/or other countries.

Apple, Macintosh, Mac and the Mac logo are trademarks of Apple Computer, Inc., registered in the U.S. and other

countries.

Adobe, the Adobe logo, Acrobat, and Photoshop are trademarks of Adobe Systems Incorporated in the United States

and/or other countries.

The content of this manual is furnished for informational use only, is subject to change without notice, and should not be

construed as a commitment by NEC Display Solutions. NEC Display Solutions assumes no responsibility or liability for

any errors or inaccuracies that may appear in this manual.

as outlined below.

It is against the law to copy, reproduce or transmit, including without limitation electronic transmission over any network,

any part of the manual except as permitted by the Copyright Act of the United States, Title 17, United States Code.

Under the law, copying includes translation into another language or format.

The above is not an inclusive statement of the restrictions imposed on you under the Copyright Act.

For a complete statement of the restrictions imposed on you under the copyright laws of the United States of America,

see Title 17, United States Code.

USA and Canada: www.necdisplay.com/multiproler

Europe: www.nec-display-solutions.com

Asia Pacic: www.nec-display.com/ap/contact/

Australia: www.nec.com.au

Revision 110701

Contents

Precautions: . . . . . . . . . . . . . . . . 4

Supported Display Monitors . . . . . . . . . . . 5

System Requirements . . . . . . . . . . . . . 6

1 Introduction to MultiProler 7

Overview . . . . . . . . . . . . . . . . . . 7

2 Dialogs, Settings and Options 8

Main MultiProler window. . . . . . . . . . . . 8

Display Conguration dialog (Windows version only). 10

Picture Mode panel. . . . . . . . . . . . . . 11

PIP panel . . . . . . . . . . . . . . . . .14

Color Vision panel . . . . . . . . . . . . . . 15

Settings panel. . . . . . . . . . . . . . . . 16

USB panel . . . . . . . . . . . . . . . . . 18

Status panel . . . . . . . . . . . . . . . .19

About Picture Modes . . . . . . . . . . . . .20

3 Picture Modes 20

Using the Color Conguration Wizard . . . . . . . 22

4 Example Usage Scenarios 34

Color Managed Workow with Print Emulation . . .34

5 Outside of MultiProler 40

Using ICC/ColorSync Monitor Proles . . . . . . . 40

Using non-Color Managed Applications . . . . . . 40

6 Frequently Asked Questions 41

7 Troubleshooting 43

Installation and Setup . . . . . . . . . . . . . 43

Glossary 45

MULTIPROFILER - USER’S GUIDE | 3

4| MULTIPROFILER - USER’S GUIDE

Precautions:

• ( Mac OS only) Do not use the ColorSync control panel to switch between different

monitor calibrations by selecting different monitor color proles. Always use the

MultiProler application to congure the display prole. This is because all of the

necessary color adjustments, including the Look Up Tables, are stored in the display

monitor and these must be set by MultiProler. The ColorSync proles generated by

MultiProler contain linear Look Up Tables for the video graphics adapter.

• Extreme care should be taken when using the DisplaySync Pro with certain USB

devices such as ash memory sticks and hard drives, as data can be lost or corrupted

if the device is switched between upstream ports while write operations are being

performed. Always use the device “eject” function on the host PC before switching

upstream ports with these types of devices.

Note:

This document covers both the Mac OS and Windows versions of the MultiProler software. The

features and functions of both versions are identical unless noted otherwise. The majority of the

User Interface screen images in this document show the Mac OS version, however the Windows

version is identical in layout unless noted otherwise.

5| MULTIPROFILER - USER’S GUIDE

Supported Display Monitors

MultiProler supports the following NEC display monitor models:

• MultiSync PA231W – 23” standard color gamut LCD monitor

• MultiSync P241W – 24” standard color gamut LCD monitor

• MultiSync PA241W – 24” wide color gamut LCD monitor

• MultiSync PA271W – 27” wide color gamut LCD monitor

• MultiSync PA301W – 30” wide color gamut LCD monitor

• MultiSync MD301C4 – 30” wide color gamut medical LCD monitor

MultiSync PA231W and P241W Important Note:

The color gamut of the PA231W and P241W displays are not wide color gamut, and are closer to

sRGB.

For this reason, certain preset color gamuts such as AdobeRGB and DCI are not available, since

they far exceed the color gamut of the display. Although MultiProler will allow the Picture

Mode settings to be modied to include large color gamuts, keep in mind that the actual color

gamut of the display is smaller, and will not be able to display colors outside of this gamut.

The PA231W display does not have an internal luminance stabilization circuit. It is therefore not

able to automatically set and maintain the luminance at an absolute value.

For this reason, the Brightness and Black Level controls are shown as a percentage values within

MultiProler.

The DICOM mode is called DICOM Sim (simulation) because the lack of an absolute level for

Brightness and Black Level means approximate values are used. True DICOM requires absolute

values for Brightness and Black Level in order to create a very accurate response curve.

6| MULTIPROFILER - USER’S GUIDE

System Requirements

MultiProler has the following system requirements:

Mac OS ÿ Microsoft Windows

Operating System Apple Mac OS X v10.3.9 or higher.

Mac OS 10.5.2 or higher required for

some Mac models. See README le

for details.

Microsoft Windows 2000, XP, XP x64,

Server 2003, Vista and Vista x64, Windows

7 and Windows 7 x64.

Video Graphics Adapter All Apple standard video graphics cards,

including most newer PowerBooks.

Digital (DVI or DisplayPort) output is

highly recommended.

See the README le and NEC website

for the latest information on Macs with

DisplayPort video output.

Most recent ATI, Nvidia, Matrox, S3

Graphics, and Intel graphics adapters.

Digital (DVI or DisplayPort) output is highly

recommended. See README le for

details.

Video Color Depth At least 24 bit color (Millions of colors). At least 24 bit color.

Video Resolution Monitor native resolution highly

recommended (1920x1080, 1920x1200

, 2560x1440, or 2560x1600 depending

on model).

Monitor native resolution highly

recommended (1920x1080, 1920x1200 ,

2560x1440, or 2560x1600 depending on

model).

USB (optional) At least one available USB port and

USB 2.0 cable (not included) if using

USB to control the display instead of

DDC/CI, or using the USB hub on the

monitor.

At least one available USB port and USB

2.0 cable (not included) if using USB to

control the display instead of DDC/CI, or

using the USB hub on the monitor.

Software (optional) Adobe Color Management Module available from:

http://www.adobe.com/downloads/

7| MULTIPROFILER - USER’S GUIDE

1 Introduction to MultiProler

Overview

MultiProler is designed as a companion to NEC MultiSync PA Series monitors. It provides complete control over the

powerful and sophisticated technology in these models in an easy-to-use application.

NEC MultiSync PA Series monitors feature a custom-designed color processor called the SpectraView Engine. This

sophisticated processor, combined with internal luminance, temperature and time monitoring of the monitor, and

individual characterization and calibration of each unit during production, results in an unparalleled level of color control,

accuracy and stability.

The wide color gamut and high-contrast LCD panel used on the monitor, coupled with the SpectraView Engine, provide

the utmost in versatility; from the ability to accurately emulate colorspaces such as AdobeRGB and sRGB, to performing

printer output emulations using ICC Proles and internal 3D Look Up Tables.

Main Features and Benets

MultiProler provides a simple, intuitive interface to perform the following functions:

• Picture Mode preset conguration: Multiple color modes can be quickly congured and selected using

MultiProler. Choose from the simplicity of built-in sRGB, Adobe RGB, DCI, DICOM, REC-BT709 and High

Brightness modes, or load a device ICC prole for color matching a printer or even another monitor. A powerful

Wizard interface helps guide you through creating and customizing different custom Picture Mode congurations,

including controlling every aspect of the monitor such as the gamma characteristics, color gamut, white point,

and brightness.

• Picture-in-Picture (PIP) conguration: The powerful video processor in the MultiSync PA Series allows two

video signals to be viewed at once in a secondary PIP or Picture-by-Picture (PBP) window conguration. The

picture of the secondary window can even be congured to display in a different colorspace, allowing functions

like simultaneous viewing of printer emulations, or even human color vision deciencies.

• DisplaySync Pro and USB hub conguration: The USB hub integrated into the MultiSync PA Series can

also be managed through MultiProler to function as a Keyboard / Video / Mouse (KVM) switch. This feature

allows the mapping of the two USB upstream ports to the various monitor inputs, which is useful for managing

multiple computers attached to the unit.

• Automatic generation of ICC/ColorSync proles: MultiProler automatically generates and updates ICC

proles for the monitor as the color modes are selected or adjusted. This activity, coupled with the internal

stabilization and highly accurate characterization and calibration of each monitor during production, reduces the

need for a proling package to prole the monitor.

• Flexible: Communications with the monitor can be performed either through the video cable using the Display

Data Channel / Command Interface (DDC/CI), or via an USB upstream connection to the unit (using optional

USB cable). This allows for better compatibility with different host PC platforms.

8| MULTIPROFILER - USER’S GUIDE

2 Dialogs, Settings and Options

Main MultiProler window

The MultiProler window shows the current settings and status of the monitor. All of the features of MultiProler are

accessed from this window.

Display listbox

Selects the monitor to control if more than

one is present.

Function list

Selects different function panels.

Function panel

Shows the controls for the

currently selected function.

9| MULTIPROFILER - USER’S GUIDE

Function Panels

Picture Mode - This panel has controls for selecting the current Picture Mode, editing Picture Modes

and adjusting the screen Brightness and Black Level.

PIP - This panel is used to manage the Picture-In-Picture (PIP) settings, including the video input and

Picture Mode used for the PIP function.

Color Vision - This panel selects the Color Vision Emulation settings for simulating human vision

deciencies.

Settings - This panel has controls for conguring the power indicator LED color and brightness, Digital

Uniformity Correction, and ICC prole generation.

Status - This panel shows the current version of the software, and the status of the currently selected

monitor, as well as providing an easy way to check if updates to the software are available from NEC.

USB - This panel has controls for setting the DisplaySync Pro USB hub conguration used for mapping

the two USB upstream ports to the various monitor inputs.

10 | MULTIPROFILER - USER’S GUIDE

This Display Conguration dialog is accessed by clicking

the Display: Congure button in the main MultiProler

window.

If more than one display is being used on Windows, it may

be necessary to manually congure the relationship between

the display layout on the Windows desktop, and the display

that are connected to the system. Correct conguration of

this relationship is necessary so that the display adjustments

are sent to the correct unit, and that the generated ICC prole

is associated with the correct display.

A diagram depicting the display desktop layout is shown and

the display associated with each desktop screen is shown.

The monitor associated with each screen can be selected

using the listboxes.

Clicking on the display rectangles will also select different

displays on the Windows desktop.

If the display is connected to the host PC by using a USB

cable (not supplied) then it can also be controlled by USB

instead of the default DDC/CI interface. If a USB connection

is detected, the display name will be followed by “(USB)” in

the listbox. Select this to use the USB connection.

Note: Some video graphics adapters may show several duplicate displays due to issues with the video drivers

for that adapter. In this case the duplicate displays can be selected to “None”.

Auto Congure - Attempts to automatically detect and congure the display to the display layout on the

Windows desktop. In most cases this will correctly congure the correct relationship, but in some cases it may

be necessary to manually congure.

Test Monitor - Tests the communications with the currently selected display. Clicking this button will send a

command to ash the display power indicator LED between green and blue. If the wrong display ashes, then

change the monitor associated with the display by using the listboxes to select.

Display Conguration dialog ( ÿWindows version only)

Display Conguration button (ÿWindows version

only) opens the Display Conguration dialog, which

is used to congure MultiProler if more than one

monitor is used on the system, or to select between

using DDC/CI and USB interfaces to communicate

with the monitor .

Inhaltsverzeichnis

Andere NEC Software Handbücher

NEC

NEC NP-PH1400U Bedienungsanleitung

NEC

NEC AccuSync LCD52V Kurzanleitung

NEC

NEC Storage Manager Configuration Setting Bedienungsanleitung

NEC

NEC MD21GS-2MP-BK-BB Bedienungsanleitung

NEC

NEC NEC Hiperwall Bedienungsanleitung

NEC

NEC NEC Express5800 Series Bedienungsanleitung

NEC

NEC Storage Performance Monitor/Optimizer Bedienungsanleitung

NEC

NEC Digital Signage Bedienungsanleitung

NEC

NEC NECSAM RICHER APPT FINAL2 Bedienungsanleitung

NEC

NEC AccuSync LCD52V Kurzanleitung

NEC

NEC Storage Manager Service-Handbuch

NEC

NEC Storage Manager IS015-9E Bedienungsanleitung

NEC

NEC SOFTDVD PLAYER Bedienungsanleitung

NEC

NEC CD-RW AND SOFTDVD SOFTWARE Datenblatt

NEC

NEC GPRS Dial Up Bedienungsanleitung

NEC

NEC KT-X46UN Bedienungsanleitung

NEC

NEC LCD2490W2-BK-SV - MultiSync - 24" LCD... Bedienungsanleitung

NEC

NEC NEAX 2000 IVS Bedienungsanleitung

NEC

NEC Storage Software PathManager Bedienungsanleitung

NEC

NEC Memory Editor Bedienungsanleitung

NEC

NEC SMB8000 Bedienungsanleitung

NEC

NEC DiamondPro 2070SB Bedienungsanleitung

NEC

NEC Storage Manager Bedienungsanleitung

NEC

NEC Versa LX Betriebsanleitung

Beliebte Software Handbücher anderer Marken

COMPRO

COMPRO COMPROFM Bedienungsanleitung

Muratec

Muratec OFFICEBRIDGE ONLINE Bedienungsanleitung

Oracle

Oracle Contact Center Anywhere 8.1 Bedienungsanleitung

Adobe

Adobe 65007312 - Photoshop Lightroom Handbuch

Avaya

Avaya NULL One-X for RIM Blackberry Bedienungsanleitung

HP ProLiant BL420c Bedienungsanleitung

PS Audio

PS Audio PowerPlay Betriebsanleitung

Brady

Brady LOCKOUT PRO 3.0 Service-Handbuch

Avaya

Avaya Interaction Center Bedienungsanleitung

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Handbuch

Novell

Novell GROUPWISE 8 - INTERNET AGENT Bedienungsanleitung

Oracle

Oracle Application 9i Bedienungsanleitung

Acer

Acer RDM Bedienungsanleitung

Canon

Canon Vixia HF21 Bedienungsanleitung

Canon

Canon ZR950 Bedienungsanleitung

Samsung

Samsung Auto Backup Bedienungsanleitung

Polycom

Polycom Vortex EF2201 Montage- und Bedienungsanleitung

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Bedienungsanleitung
