Nero 7G Ozone Machine
Product Code: 350078
OWNER’S MANUAL
Please read all of the information provided in this owner’s
manual before operating the new Nero 7G Ozone Machine.
Images in this manual are for illustrative purposes only.
Due to constant improvements, we advise that changes to the design, material,
specifications and product configuration may occur at any time without notice.
Index
3.Warnings
4.Specifications
5.Functions front view
6.Functions rear view
7.Operation
8.Maintenance
9.Troubleshooting
CAUTION
RISK OF ELECTRICAL
SHOCK DO NOT
OPEN
ATTENTION
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO
NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVCE PERSONNEL.
This “bolt of lightning” indicates that uninsulated material
within your unit may cause an electrical shock. For the
safety of everyone, do not remove product covering.
3
INTRODUCTION
The Nero 7G Ozone Machine is an advanced and convenient
contaminant remediation product. High-powered oxidation in a
compact, lightweight, rugged and replugable ozone module design.
Utilizing controlled corona discharge ozone technology developed
specifically to reduce odors and smoke in unoccupied spaces, ideal
for hospitality and office use and more!
4
Model: 350078
Rated Voltage: Europe AC 220-240V/50-60Hz
USA/Japan AC 100-120V/50-60Hz
Power Consumption: 85W
Ceramic Plate Size(2 plates):
95X70MM
Air Volume: Max 106CFM(3 M3/min)
Active Oxygen(on) ：7.0 g/h
Sound Level(DB): 40 Db
Product size(mm): W220xH170xD160MM
Weight: 2.9Kgs(6.38Lbs)
Operating the Nero 7G Ozone Machine
(Front View)
Timer Control Knob Turn clockwise to set the timer for timed
operation up to THREE hours.
Indicator Light Illuminates when unit is in operation.
5
(Back View)
Fuse Holder Houses removable fuse.
(Spare fuse included, 2 amp, 0.79
inch in length)
Power Cord 220~240 Volt grounded cord
6
The Nero 7G Ozone Machine is designed to remove odors in
unoccupied spaces. The unit has a timer that will enable it to run for a
maximum duration of 3 hours. The timer will then shut the air purifier off.
You should allow 40 minutes before returning to the treated area.
To operate the Nero 7G Ozone Machine:
Close off the desired area to be treated.
Remove all occupants and pets.
Position the unit as close as possible to the odor source.
In such environments as motels that have individual heating
and cooling systems, turn the fan on and set on re-circulate.
Set timer to desired time and leave the room.
Allow 40 minutes before re-entering the treated space.
Return to space & ventilation area.
7
When the Nero 7G Ozone Machine no longer produces enough ozone
to be effective, the ozone plates should be replaced.(Usually they
should be replaced after 6000 hours)
How to replace the ozone plate:
Turn off the local power supply.
Pull out the ozone plate module directly by hand.
Install new ozone plate module
(Be careful not to drop the plate module)
8
If you suspect a problem with your unit check the following:
1) Unit is plugged in properly.
2) It’s important that the Nero 7G Ozone Machine be properly
grounded to avoid potential shock.
3) Fuse is installed properly and in good condition. To replace
fuse, pull out the plastic fuse holder, remove old fuse and insert
new fuse. Replacement fuse must be 2 amp (0.79 inch). Refer
to picture as follows:
Backed by the Nero 1 Year Warranty
Imported By:
R Weatherdon & Co Pty Ltd
www.weatherdon.com.au
Made in China
9
