Nespresso C 290 Bedienungsanleitung

C 290

D 290

Instruction Manual

Read this Instruction Manual and the safety instructions (pages 8 and 9) before operating the appliance!

Nespresso_C_D290-Zone1_1105_2.indd 2 14.12.2005 10:04:50 Uhr

6 x

Start up

Verify that the voltage indicated on the technical speciﬁcations plate on the

bottom of the unit corresponds to your electrical installation.

Remove protective

foil

Reﬁll with fresh

water Insert water tank

ON/OFF

Rinse

STOP

Daily care and cleaning

Remove the

capsule used

Empty Reﬁll with fresh

water

Empty used capsule

container

Nespresso_C_D290-Zone1_1105_2.indd 1 14.12.2005 10:04:20 Uhr

Remove the capsule used

ON/OFF

Warm up phase Machine is ready

Small cup (Espresso) Large cup

Press and hold button for at least

seconds

Close closing handleInsert capsule

Place cup underneath Release at desired level

Programming the ﬁll-up level

Functions Closing ha

Floa

ON/OFF, Steam,

Control-LED

Nespresso_C_D290-Zone1_1105_2.indd 1 14.12.2005 10:04:20 Uhr

30s

dle Hot water /

Steam lever

Fresh water tank 1,2 l

Hot water / steam nozzle

Capsule container (10 - 12 capsule)

ter

Grid

Drip tray

CAPPUCCINO – CAFFELATTE

Small cup,

large cup

CAPPUCCINO  CAF

Steam rises from

Warm up phase

Milk foam Hot milk

Temp

~55–

Automatic cool down (If not manually activated,

cool down starts automatically after 2 minutes)

Steam nozzle is very hot

Switch position CAPPUCCINO or CAFFELATTE

Nespresso_C_D290-Zone1_1105_2.indd 1 14.12.2005 10:04:20 Uhr

30s

Clean after each use

STOP

ELATTE:

CAPPUCCINO  CAFFELATTE:

he drip tray

achine is ready

rature change

5°C

Warm up phase Machine is

ready Reﬁll with fresh water

Steam rises from the drip tray

Automatic

cool down

Remove and clean nozzle once weekly

Warm up phase Machine is

ready

Do not touch

the buttom of

the cup

Steam nozzle is very hot

Automatic

cool down

STOP

Hot water

Heat up beverages

Rinse for at

least 10 s

Steam nozzle is very hot

Nespresso_C_D290-Zone1_1105_2.indd 1 14.12.2005 10:04:20 Uhr

min 1 l

30s

5x

30s

5x

min 1 l

Descaling

Water hardness Descale after

Preparation

Descaling water system

Descaling coﬀee system

Rinse

Clean

Decalciﬁer: aggressive to the surface of the casing

Never use vinegar!

Flush out the entire tank

Reuse decalciﬁer

Clean and rinse with a lot of

water. Reﬁll with fresh water Rinse coﬀee

system

Remove steam nozzle 100 ml

decalciﬁer +

500 ml water

Clean

Warm up phase

Decalcify coﬀee

system

Waste solution

Flush residue from

the tank

Press

simultaneously

3 s

Press

simultaneously

3 s

Machine is ready

STOP

OFF

STOP

Nespresso_C_D290-Zone1_1105_2.indd 1 14.12.2005 10:04:20 Uhr

3 x beep

1 x beep

Problems / Solutions

No control-LEDs turn on Check plug, mains switch and fuses

Milk does not froth Check the switch position CAPPUCCINO – CAFFELATTE.

Clean it if needed.

Noisy pump

Fill tank

No hot water/steam

Remove steam nozzle and clean, descale if necessary

Lower/upper jaws leak

Call the NESPRESSO Club

Coﬀee not hot enough

Preheat cup (hot water without capsule), descale if necessary

wait 30 seconds

Alerts

Empty used capsule container:

Machine is not ready:

Drip tray is not

properly placed.

No coﬀee

ﬂows when the

container is full.

Temperature is too

high or too low.

Nespresso_C_D290-Zone1_1105_2.indd 2 14.12.2005 10:04:50 Uhr

Optional accessories

NESPRESSO descaling kit

Art. 3035/C290

Service-Kit 1b

Baseplate, ejector

Service-Kit 2

Capsule cage, capsule cage key

Water tank Cover

Environment

Packaging is made of recyclable materials.

Warranty according to the enclosed certiﬁcate of guarantee.

Date of purchase

Dealer‘s stamp / Signature

The guarantee becomes void if incorrectly connected.

The manufacturer cannot be held liable for damages caused

by unintended purpose or by improper operation.

Spare parts

Technical data

Environnement protection ﬁrst!

Your appliance contains valuable materials which can be recovered or recycled.

Leave it at a collection point.

Nespresso_C_D290-Zone1_1105_2.indd 2 14.12.2005 10:04:50 Uhr

CD290_Z1_01.06

• Please read these instructions carefully

before using your appliance for the ﬁrst

time and retain them for future use.

Any use which does not conform to the

instructions will absolve NESPRESSO

from any liability.

• Emergency: remove immediately the

power cord from the socket.

• Do not leave this appliance within reach

of unsuper vised children. The use of

this appliance by young children or by

disabled persons must be supervised at

all times.

• Check that voltage indicated on the

information plate on the appliance does

in fact match that of your electrical

system.

• Only use an earthed socket to connect

the appliance. Any connection error will

nullify the guarantee.

• Your appliance is intended solely for

domestic and indoor use.

• Hot water, steam, spout and capsule

holder are hot. Danger of burning

Injuries.

• Do not direct steam or hot water to-

wards the body. Danger of burning

injuries.

• Danger of ﬁnger injury in the capsule

holder from the sharp capsule puncher.

• Heat up drinks: Dip the steam nozzle

deep into the liquid in order to avoid

hot water or steam splashes.

• Close the jaw ﬁrmly by using the handle.

Do not open the capsule container

during operation.

• Unplug your appliance as soon as

you have ﬁnished using it. Before

maintenance/cleaning unplug the

machine and let it cool down. Do not

unplug it by pulling on the cord.

• Do not use the appliance if it is not

working correctly or if it has been

damaged. If this happens, please

contact an approved NESPRESSO service

centre.

• Any intervention other than normal

cleaning and maintenance by the

customer must be carried out by

an approved NESPRESSO service centre.

• Do not place the appliance, the power

cord or the plug in water or any other

liquid.

• Do not allow the cord to hang down

within reach of children.

Safety advice

Nespresso_C_D290-Zone1_1105_2.indd 2 14.12.2005 10:04:50 Uhr

• The power cord must not be close to

or in contact with hot parts of your

appliance, close to a source of heat or

resting on a sharp edge.

• If the power cord or the plug are

damaged, do not use the appliance.

To prevent any risk, you must have these

replaced by an approved NESPRESSO

service centre.

• Do not place the appliance on a hot

surface such as a hotplate and never use

it close to a naked ﬂame.

• For your own safety, please use only the

NESPRESSO accessories and spare parts

which are suitable for your appliance.

• Do not use the appliance when the drip

tray and the grille are not in place.

• All NESPRESSO appliances are subject

to strict quality controls. Practical user

tests are done with appliances

selected at random, which explains any

signs of use.

• Disposal: Unplug the machine and

cut oﬀ the power cord. Bring machine

and power cord to your next customer

service or any public collection area.

Nespresso_C_D290-Zone1_1105_2.indd 2 14.12.2005 10:04:50 Uhr
