NetComm CF40MESH Bedienungsanleitung

CF40MESH |INTELLIGENT WI-FI 6

Wi-Fi 6 Gateway

2

GETTING

STARTED

PRE-CONFIGURED?

If you received your gateway from your service provider

and they have provided you with their own instructions,

refer to those to complete the setup. In some cases, the

gateway has been pre-congured for you and is ready to use.

Otherwise, you will need to complete the setup yourself.

3

BEFORE YOU BEGIN

Ensure that you have the following information

from your service provider:

- How your Internet service will physically connect to your gateway

- The Settings specic to your type of service.

There are two primary ways to connect your

gateway to the Internet service:

Ethernet WAN

This is the most common access type in Australia and New Zealand

and covers xed line technologies such as nbn™ FTTP, HFC, FTTC

as well as UFB Fixed Wireless and Sky Muster™ satellite services.

This type of Internet service uses the red WAN port on the

back of the gateway to connect to the dedicated connection

box installed by your access network provider.

VDSL

These access types are provided by nbn™ FTTB,

FTTN or VDSL over a traditional telephone line.

VDSL connection will require an optional DSL box.

Refer to pages 12 and 13 for a diagram and

description of the connection using a DSL box.

4

Wi-Fi 6 Gateway

Power outlet

Power adaptor

OffOn

5

IF YOU’RE CONNECTING WITH

AN NBN™/UFB PLAN

Your nbn™/UFB retail service provider will contact you when your

service is activated. You can set up your gateway before this time,

if you have the required nbn™/UFB hardware.

Once your service is activated, it’s time to complete the set-up of

your Wi-Fi 6 Gateway.

Check with your retail service provider to see what technology

type you are connected with.

Turn off your Wi-Fi 6 Gateway at the power outlet.

Follow the set-up instructions below for your nbn™/UFB

technology type.

You can then switch the Wi-Fi 6 Gateway back on at the

power outlet.

6

Wi-Fi 6 Gateway

Ethernet cable

Power adaptor

7

HYBRID FIBRE COAXIAL (HFC)

Ethernet cable

nbn™ connection box

The Ethernet cable connects

to the UNI-D port on the

nbn™ connection box.

Power outlet

Power adaptor

8

Ethernet cable

Wi-Fi 6 Gateway

Power adaptor

9

FIBRE TO THE PREMISES (FTTP)

Ethernet cable

nbn™ connection box

Power outlet

Power adaptor

The Ethernet cable connects

to the UNI-D port on the

nbn™ connection box.

10

Wait for the lights on the

nbn™ connection box

to turn blue (this may take

up to 15 minutes) and

then connect your

Wi-Fi 6 Gateway

Wi-Fi 6 Gateway

Power adaptor

Ethernet cable
