NetComm FIBRE NF3ADV Bedienungsanleitung

NetCommWireless

QUICK START GUIDE

NetComm

Wireless

NF3ADV

N900 Dual Band WiFi

Gigabit Modem Router

NetComm

Wireless

THANKS FOR PURCHASING NETCOMM WIRELESS

This quick start guide is designed to get you up and running quickly with your new router. For

more advanced setup instructions, refer to the user manual which can be downloaded from

the NetComm Wireless website at www.netcommwireless.com

CONNECTING THE GATEWAY

1. Align the holes on the base of the gateway with the securing pins on the gateway stand

as illustrated below and push the gateway into the stand so that the securing pins lock

into place.

2. Connect the supplied yellow Ethernet cable to one of the yellow Ethernet ports on the

back of the gateway and the other end to the network adapter on your computer.

3. Connect the supplied RJ-11 cable to the DSL port on the back of the gateway and the

other end to the wall port that provides your ADSL service.

4. Connect the supplied AC Power adapter to the power jack on the back of the gateway

and to the wall socket then press the ON/OFF button.

N900 Dual Band WiFi Gigabit Modem Router - NF3ADV

LOGGING INTO THE

WEB INTERFACE

1. Open a web browser (for example,

Mozilla Firefox, Google Chrome, or

Microsoft Internet Explorer) and type

http://192.168.1.1 into the address

bar and press Enter. The login screen

is displayed.

2. Enter admin into both the username and

password elds and click Login. The

First-time Setup Wizard is displayed.

3. Click the Yes, let’s get started with the

wizard button to begin conguring

the gateway.

4. To setup your ADSL service, use the

WAN Type drop down list to select the

ADSL connection type. Your service

provider should be able to give you this

information. If you are unsure, select PPP

over Ethernet. Enter the username and

password of your ADSL account and

click Next.

Note: For 3G/4G or NBN/Fibre connections please consult the

User Guide for setup instructions .

5. To congure a wireless network, set the

Wireless 2.4GHz (WiFi) option to On.

The SSID Broadcast option enables or

disables the gateway from showing the

wireless network name when a scan is

performed by wireless devices. In the

SSID Broadcast Name eld, enter the

wireless network name that you would

like to use. This may be a maximum of

32 characters. Click the Next button

to continue.

6. Use the Security Key Type drop down

list to select the type of wireless security

you would like to use. If you are unsure,

select WPA-PSK / WPA2-PSK. In the

Security Key eld, enter the password

you would like to use for wireless devices

to join your wireless network. This may

be a maximum of 8 characters. Click

the Next button to continue.

7. Steps 4and 5of the wizard are the same

as steps 2and 3but for the 5GHz WiFi

network. Enter the details for the 5GHz

wireless network and click Next.

NetComm

Wireless

8. Step 6of the wizard prompts you to

congure the username and password

used to log in to the gateway. We

highly recommend changing the default

username and password of the gateway

for security reasons.

In the

Desired

Username

eld, enter the username

you would like to use. In the Desired

Password and

Retype Password

elds,

enter the password that you would like to

use. Click the

button to continue.

Note: Remember to write down the username and password

that you configure.

9. The wizard displays a summary of the

settings that you congured. Click the

Finish button to complete the wizard.

CONNECTING VIA WIFI

You can connect multiple computers,

laptops, tablets and smartphones to your

gateway’s wireless networks by performing

the following steps. Note that the gateway

has both a 2.4GHz and a 5GHz wireless

network. The network that you connect to

is congured on your wireless device and is

subject to the device’s compatibility.

1. Using your wireless device, perform a

scan for wireless networks and select

the wireless network name listed on

the included Wireless Security Card.

If you changed the SSID Broadcast

Name using the Setup Wizard, select the

wireless network displaying the name

that you entered.

2. Enter the wireless security key listed

on the included Wireless Security Card

and click Connect. If you changed the

wireless security password using the

Setup Wizard, enter the new password

you congured with the Wizard.

3. Wait approximately 30 seconds for the

connection to establish.

Your NetComm Wireless Dual Band

WiFi Data and VoIP Gateway is now

ready to use.

YML-NF3ADV-V7
