NetComm LIBERTY 3G22WV Bedienungsanleitung

NetCommWireless

Quick Start Guide

NetComm

Wireless

3G22WV

3G WiFi Router with Voice

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

NetComm

Wireless

Thanks for purchasing

neTcomm Wireless

This quick start guide is designed to get you up and running quickly with your new router. More

advanced set up instructions can be found in the user manual which can be downloaded from

www.netcommwireless.com

hardWare insTallaTion

Power adapter Power point

SIM

1. Insert your SIM card into the SIM card slot (you should hear it click into place)

2. For voice functionality, connect a standard analog telephone to the port labelled Voice using the

provided RJ-11 phone cable.

3. Connect the power adapter to the power socket on the back of the router.

4. Plug the power adapter into the wall socket and power on the device.

5. Wait approximately 1 minute for the router to start up.

6. To connect to the router via Ethernet cable, please go to Connecting to the router via a cable

section. To connect via WiFi, please go to Connecting to the router via WiFi on the next page.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

3G WiFi Router with Voice - 3G22WV

connecTing To The rouTer via a cable

Computer

NOTE: This step is optional. If you do not wish to connect via an Ethernet cable to the router, please skip this step and proceed to the

step below.

1. Connect the provided yellow Ethernet cable to one of the Ethernet ports on the back of the router.

2. Connect the other end of the Ethernet cable to your computer.

3. Wait approximately 30 seconds for the connection to establish.

4. Proceed to the Customize your routers settings step to congure Internet access on your router

CONNECTING TO THE ROUTER VIA WIFI

Smart Phone

Online Gaming

Laptop

Tablet

NOTE: This step is optional. If you do not wish to connect via WiFi to the router, please skip this step.

You can connect multiple WiFi devices, including laptops, desktops, tablets and PDA’s to your router by

following these basic steps.

1. Using your WiFi device, scan the WiFi networks in your area and select the wireless network name

listed on the included Wireless Security Card and then click connect.

2. Enter the wireless security key listed on the included Wireless Security Card.

3. Wait approximately 30 seconds for the connection to be established.

4. Proceed to Customize your routers settings step to congure Internet access on your router.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

NetComm

Wireless

QSG-00009 rev1

CUSTOMIZE YOUR ROUTER’S SETTINGS

To customize your router’s settings, please perform the following steps:

1. After establishing your wired or wireless connection as previously outlined, open your Web browser (

such as Firefox, Internet Explorer and Safari) and type http://192.168.20.1 into the address bar at the

top of the Web browser window and press Enter.

2. You will be brought to the Status page. From here you can see the current connection status of

your router.

3. Click on the Login tab and enter the default Username and Password of admin, and then press

Submit to login to the management console.

4. Click on the Internet tab to congure the settings to get you online.

5. You can Enable or Disable the Internet connection to allow your router to get online.

6. The router attempts to automatically congure and may have already connected to the Internet. If it

hasn’t, you may need to congure a custom APN and/or authentication settings. To do this, untick

the checkbox Automatically Congure My Mobile Broadband. Hover over the blue Choose an

APN here link and select your mobile service provider to auto-ll the APN of your 3G network. If you

have a special APN, please enter it manually.

7. Fill in the PIN settings of your SIM, if required, and then click Save to use the settings you have entered.

8. Click on the Wireless tab to congure the WiFi settings of your router. Please note that Wireless

settings do not need to be changed and the default settings can be used.

9. Enter the WiFi Network Name (SSID) and WiFi Password (WPA2-PSK) and then click Save to use the

settings you have entered.

The router will now apply your changes. If a connection is successfully established, the blue network

light on the front of the router will light up. When connecting devices via WiFi, the settings that were

entered will have to be used.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299
