ProSAFE Wireless Controller WC7600

Package Contents

The package contains the following items:

•ProSAFE® Wireless Controller WC7600

•AC power cable

•Straight-through Category 5 Ethernet cable

•Rack-mount kit

•Rubber feet (4) with adhesive backing

•Installation guide

WARNING: DO NOT stack equipment, or place equipment in tight

spaces or in drawers. Be sure that your equipment is surrounded by at

least 2 inches (5 cm) of air space.

Meet Your Wireless Controller

Before you install your wireless controller, familiarize yourself with its

LEDs, buttons, and ports.

Front Panel

Console 9600,N,8,1

LED Mode:

Left LED: Green=Link at 1G E,

Yellow=Linkat 10/100M

Right LED:Green=Link,

Green Blink=Active

LED Mode:

Green= Link at 10G, Blink Green=10G Active,

Yellow=Linkat 1G, Blink Yellow=1G Active

Power

Status

Fan

Stack

Master

Reset

USB

LEDs (top to bottom):

Power, Status, Fan, Stack Master

Reset button

USB port

Digital access point counter

Slots and LEDs for optional

Ethernet port and LEDs

SFP GBIC modules

COM port

Rear Panel

Power input

Power Status LED

Set Up the Wireless Controller

To set up the wireless controller:

1. Configure your computer with a static IP address of

192.168.0.210 and a subnet mask of 255.255.255.0.

2. Connect one end of the supplied Ethernet cable to the Ethernet

port on your computer and the other end to the Ethernet port on

the front panel of the wireless controller.

3. Connect the supplied power cord from the wireless controller to

an AC power outlet.

4. Verify that the following LEDs on the front panel are lit:

LED Description

Power The green Power LED is lit. If this LED is not lit, check the

connections and check to see if the power outlet is controlled

by a wall switch that is turned off.

Status The Status LED is lit yellow while the wireless controller is

initializing. After approximately two minutes, when the

wireless controller has completed its initialization, the Status

LED turns green.

Fan The green Fan LED is lit, indicating that the fans are

functioning correctly.

Ethernet

port

The right Ethernet port LED is lit green for a 1000 Mbps

connection or yellow for a 100 or 10 Mbps connection.

LED Description

Access the Wireless Controller

To access the wireless controller:

1. On your computer, open a browser. In the address field, type

http://192.168.0.250.

The wireless controller’s login screen displays:

2. Enter admin for the user name and password for the password,

both in lowercase letters.

3. Click the Login button.

The wireless controller’s web management interface displays.

Configure the Basic Settings

To configure the basic settings:

1. From the main navigation menu, select Configuration >

System > General.

2. Enter a name for the wireless controller.

3. Select the country in which the wireless controller is used.

4. Click the Apply button.

5. Select Configuration > System > Time.

6. Select the time zone in which the wireless controller is used.

7. (Optional) Configure the NTP settings.

8. Click the Apply button.

9. Select Configuration > System > IP/VLAN.

10. Enter the IP settings for your network and the VLANs that you want

to assign to the wireless controller.

Note: For large deployments, NETGEAR recommends that

the wireless controller and access points are in separate

VLANs to ensure uninterrupted connectivity between the

wireless controller and the access points.

Note: Clear the Untagged VLAN check box only if the hubs

and switches in your network support the VLAN (802.1Q)

standard. Change the untagged VLAN value only if the hubs

and switches in your network support the VLAN (802.1Q)

standard.

11. Click the Apply button.

The connection to the wireless controller is terminated because

you have changed its IP address.

12. Reconfigure your computer with an IP address and subnet mask

that is in the same IP subnet as the wireless controller. Use the

new IP address of the wireless controller to log in again.

13. Select Configuration > System > DHCP Server. The Discovery

Wizard (see Discover Access Points) requires a DHCP server to

discover the access points. If you already have a DHCP server

in your network, disable the DHCP server on the wireless

controller. Otherwise, configure the DHCP settings for the DHCP

server on the wireless controller.

14. Click Apply.

15. Decide whether to use the basic profile group (suitable for a

small WLAN) or one or more advanced profile groups (suitable

for a large WLAN):

•Basic. Allows up to eight profiles (16 for dual-band access

points), each of which has its own SSID, security, MAC ACL,

rate-limiting settings, WMM settings, and so on.

a. Select Configuration > Profile > Basic > Radio.

b. Configure one or more profiles, each with its SSID and

security settings.

c. Click the Apply button.

•Advanced. Allows up to eight profile groups. Each group

includes all the settings that are required to configure a fully

functional access point with up to eight security profiles (16 for

dual-band access points).

a. Select Configuration > Profile > Advanced > Radio.
