NETGEAR LBR20 Bedienungsanleitung

1. Insert a Nano SIM

Card

Note: A nano SIM card is not included

with your 4G LTE Orbi. Get a nano SIM

card from your LTE provider.

IMPORTANT: Make sure that the 4G LTE

Orbi is powered off before inserting a

nano SIM card.

Insert the nano SIM card into the nano

SIM slot on the back of the 4G LTE Orbi.

Note: The 4G LTE Orbi does not

support SIM hot-swapping. If you want

to change the nano SIM card, power off

the 4G LTE Orbi before changing the

nano SIM card.

You can also connect your 4G LTE Orbi

to a cable or DSL modem. For more

information, see the Do More booklet

or the user manual. The user manual

is available online at downloadcenter.

netgear.com.

2. Connect Power to

Your 4G LTE Orbi

a. Connect your 4G LTE Orbi router

to a power source.

b. Wait for the Orbi router’s ring LED

to light white.

Note: Your 4G LTE Orbi router

tries to connect to the LTE network

automatically. If it cannot, you might

need to manually set the APN. Ask

your internet service provider for

the required APN and follow the

instructions to manually update the

APN while you set up the network.

4G LTE WiFi

Orbi Router

Quick Start

Guide

Nano SIM

3. Connect to the

Internet

a. Connect your computer or mobile

device to the Orbi router with an

Ethernet or WiFi connection:

• Ethernet. Use an Ethernet

cable to connect your

computer to the Orbi router.

• WiFi. Use the preassigned

WiFi network name (SSID) and

password on the Orbi label

to connect to the Orbi WiFi

network.

b. Set up your network using one of

the following options:

• NETGEAR Orbi app. Download

the NETGEAR Orbi app on your

mobile device. You can scan a QR

code on the other side of this quick

start guide to get the app. Launch

the app and follow the onscreen

instructions.

• Web browser. Launch a web

browser and visit orbilogin.

com. If a login window opens,

enter the user name and

password. The user name

is admin and the default

password is password. Follow

the onscreen instructions.

The Orbi router’s ring LED turns o

aer the setup is complete.

Ring LED (not shown in image)

LTE antenna 1and 2

Sync button (also used for WPS

connection)

WAN/LAN port

LAN port

Power LED

DC Power connector

Reset switch

Nano SIM slot

Support

Thank you for purchasing this

NETGEAR product. You can visit

www.netgear.com/support to register

your product, get help, access the latest

downloads and user manuals, and join

our community. We recommend that

you use only ofcial NETGEAR support

resources.

For the current EU Declaration of

Conformity, visit

http://support.netgear.com/app/

answers/detail/a_id/11621/.

For regulatory compliance information,

visit

http://www.netgear.com/about/

regulatory/.

See the regulatory compliance

document before connecting the

power supply.

NETGEAR INTERNATIONAL LTD

Floor 1, Building 3,

University Technology Centre

Curraheen Road, Cork,

T12EF21, Ireland

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

Logo are trademarks of NETGEAR, Inc. Any

non-NETGEAR trademarks are used for reference

purposes only.

July 2020

All Set Up!

Orbi Router Overview

Orbi router

(Model LBR20)

Ethernet cable

Power adapter

(varies by region)

Package Contents

Download the

NETGEAR Orbi App

Use the NETGEAR Orbi app to set up

and manage your network. To nd

the app, scan one of the following QR

codes or search for NETGEAR Orbi in

the Apple App Store or Google Play

Store.
