NETGEAR R7500v2 Bedienungsanleitung

Quick Start Package Contents

The box contains the following items.

In some regions, a resource CD is included in the package.

AC2350 Smart WiFi Router

Model R7500v2

Support

Thank you for purchasing this NETGEAR product.

Aer installing your device, locate the serial number on the label of your product and use it to

You must register your product before you can use NETGEAR telephone support. NETGEAR

recommends registering your product through the NETGEAR website.

For product updates and web support, visit http://support.netgear.com.

NETGEAR recommends that you use only the ocial NETGEAR support resources.

You can get the user manual online at http://downloadcenter.netgear.com or through a link in

the product’s user interface.

Trademarks

Any non‑NETGEAR trademarks are used for reference purposes only.

Compliance

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134 USA

February 2015

Router

Ethernet cable

Power adapter

(varies by region)

BETA DOCUMENT

Antennas (4)

1. Attach the antennas.

To determine where to attach the

antennas, match the labels on the

antennas with the labels on the router.

Attach the antennas on the threaded

antenna posts.

Position the antennas vertically for the

best WiFi performance.

2. Prepare your modem.

Unplug your modem’s power. If it has a

battery backup, remove the battery.

3. Connect your modem.

Plug in your modem. Put the battery back

in. Then cable the modem to the yellow

Internet port on the router.

4. Power on the router.

The Power LED lights amber

and then turns white when the

router is ready.

5. Connect a device.

You can use an Ethernet cable or

connect with WiFi.

You can also use WiFi to connect your

WiFi device to the router. To connect

with WiFi, use the WiFi network name

and password on the product label.

6. Log in to the router.

Launch a web browser.

NETGEAR genie displays.

If you do not see genie, enter

www.routerlogin.net in the address ﬁeld

of the web browser. When prompted, enter

admin for the user name and password for

the password.

Follow the genie steps to connect to the

Internet.

8. Get the user manual.

You can get the user manual online at

http://downloadcenter.netgear.com or

through a link in the product’s user interface.

Router

Ethernet cable

Cable or DSL

Internet

Modem

Power

adapter

You can use this diagram to connect your router or follow the detailed instructions in this booklet.

7. Get free apps.

During the installation process, genie

prompts you to download two free apps:

• genie app. A personal dashboard that

lets you monitor, control, and repair

your home network.

• ReadySHARE Vault app. Enables

automatic continuous backup of a

Windows computer to a USB device

that’s connected to your router.

Ethernet cable

Computer

LEDs

The LEDs on the top of the router light to indicate router activity:

Power

Internet

2.4 GHz WiFi

5 GHz WiFi

USB 3.0 port 1

USB 3.0 port 2

eSATA port

Ethernet ports 1–4

WiFi On/O button with LED

WPS button with LED

Rear Panel

Rest button Ethernet

ports 1–4

Internet

port

Power

On/O

button

Power

connector

LED Indicator

On/O switch

USB 3.0

port 1

USB 3.0

port 2

eSATA

port

Install Your Router

Make sure that your Internet service is active before you install

your router.

¾To install your router:

1. Extend the antennas.

a. To determine where to attach the antennas, match the

labels on the antennas with the labels on the router.

b. Align the antennas with the antenna posts on the router.

c. Attach the antennas on the threaded antenna posts.

d. Position the antennas for the best WiFi performance.

NETGEAR recommends that you position all of the antennas

vertically, as shown.

2. Prepare your modem.

a. Unplug your modem’s power.

b. If the modem has a battery backup, remove its batteries.

c. If your modem was already connected to another router,

disconnect the cable between your modem and that router.

Make sure that your modem is turned o and is cabled only to

the wall jack for your Internet service.

3. Connect your modem.

a. Plug in, then turn on your modem.

b. If you removed the batteries, replace them.

c. With the yellow Ethernet cable that came with the router,

connect your modem to the yellow Internet port on your

router.

Cable or DSL

Modem

Internet

Router

Ethernet

cable

Internet

Modem

Cable or DSL

4. Add power to the router.

a. Connect the power adapter to the router and plug the

power adapter into an outlet.

b. Wait for the Power LED on the front panel to light amber

and turn white.

If no LEDs are lit, press the Power On/O button on the

rear panel of the router.

5. Connect a device.

You can use an Ethernet cable to connect a computer to the

router or you can use WiFi to connect a computer or WiFi

device to the router:

• For a wired connection, use an Ethernet cable (not included)

to connect your computer to a black Ethernet port on your

router.

• To connect your computer or WiFi device to the router with

WiFi, use the WiFi settings on the product label.

Ethernet

cable

Modem

Cable or

DSL

Ethernet cable

Internet

Power

adapter

Router

Ethernet

cable

Modem

Internet

Power

adapter

Cable or

DSL

Power

adapter

Computer

6. Launch a web browser.

The ﬁrst time that you connect to the router, the genie screen

displays. Follow the genie steps to connect to the Internet.

If the genie screen does not display, try the following:

• Close and reopen the browser.

• Make sure that your computer is connected to one of

the four Ethernet ports on the router, or that you are

connected to your WiFi network.

• Make sure that the router has full power, and that its Power

LED is lit.

• If your computer is set to a static or ﬁxed IP address (this is

uncommon), change it to obtain an IP address automatically

from the router.

If you still do not see the genie screen, log in to the router so

that genie can detect your Internet connection.

¾To log in to the router:

1. Launch a web browser.

2. Enter www.routerlogin.net in the address ﬁeld of the

browser.

A login screen displays.

3. Enter admin for the user name and password for the

password.

The BASIC Home screen displays. If your Internet connection

is not set up yet, genie automatically detects your Internet

connection.

WiFi Network Name and Password

The preset WiFi network name (SSID) and password (network key)

are unique to your router, like a serial number. Because the router

automatically uses WiFi security, you don’t need to set it up. The

WiFi settings are on the product label.

NETGEAR recommends that you use the preset WiFi settings

because you can check the product label if you forget them.

NETGEAR genie lets you change these settings. If you do so, write

down the new WiFi settings and store them in a safe place.

You can write the WiFi settings from your product label in this space

for easy reference.

WiFi network name (SSID):

Network key (password):

If you change the WiFi settings, write the new settings here for

easy reference and store this booklet in a safe place.

WiFi network name (SSID):

Network key (password):

Join the WiFi Network

You can either use Wi‑Fi Protected Setup (WPS) or select your WiFi

network and type its password. For help with the WPS button on

your computer or WiFi device, check the instructions or online help

that came with that computer or device. Some older equipment

cannot use WPS.

¾To join the network using WPS:

1. Press the WPS button on the router for 3–5 seconds.

The WPS LED on the router blinks white.

2. Within two minutes, on your computer or WiFi device, press its

WPS button or click its onscreen WPS button.

The WPS LED on the router lights solid white when the

computer or WiFi device connects to your router.

3. Repeat this process to add other computers or WiFi devices.

¾To select your network and enter its password:

1. Open the soware utility that manages your WiFi connections

on the computer or WiFi device that you want to connect to

your router.

This utility scans for WiFi networks in your area.

2. Find and select your router’s WiFi network name (SSID).

The SSID is on the product label.

3. Enter the router’s password (or your custom password if you

changed it) and click the Connect button.

The password is on the product label.

4. Repeat Step 1 through Step 3 to add other computers or WiFi

devices.

View or Change the Router Settings

Aer you use genie to set up the router, you can log in to the router

to view or change its settings.

¾To log in to the router:

1. Connect a computer or WiFi device to the router.

You can use an Ethernet cable or connect with WiFi.

• For a wired connection, use an Ethernet cable (not included)

to connect your computer to a black Ethernet port on your

router.

• To connect with WiFi, select and join your WiFi network.

2. Launch a web browser.

3. Enter www.routerlogin.net in the address ﬁeld of the

browser.

A login screen displays.

4. Enter admin for the user name and password for the

password.

The BASIC Home screen displays.

Change the admin Password

¾To change the admin password:

1. Launch a web browser.

2. Enter www.routerlogin.net in the address ﬁeld of the

browser.

A login screen displays.

Inhaltsverzeichnis

Andere NETGEAR WLAN-Router Handbücher

NETGEAR

NETGEAR Nighthawk RS400 Bedienungsanleitung

NETGEAR

NETGEAR AirCard 785 Bedienungsanleitung

NETGEAR

NETGEAR R8500 Bedienungsanleitung

NETGEAR

NETGEAR JNR3000 Bedienungsanleitung

NETGEAR

NETGEAR DGFV338 - ProSafe Wireless ADSL Modem VPN Firewall... Bedienungsanleitung

NETGEAR

NETGEAR WNA3100M Bedienungsanleitung

NETGEAR

NETGEAR MBR1515 Bedienungsanleitung

NETGEAR

NETGEAR orbi CBR750 Bedienungsanleitung

NETGEAR

NETGEAR WNDR3400v3 Bedienungsanleitung

NETGEAR

NETGEAR WNR2000 Bedienungsanleitung

NETGEAR

NETGEAR Nighthawk RS400 Bedienungsanleitung

NETGEAR

NETGEAR WNDR3800 - N600 WIRELESS DUAL BAND GIGABIT ROUTER-Premium... Bedienungsanleitung

NETGEAR

NETGEAR N150 D500 Bedienungsanleitung

NETGEAR

NETGEAR Nighthawk M2 MR2100 Bedienungsanleitung

NETGEAR

NETGEAR R6200 Bedienungsanleitung

NETGEAR

NETGEAR D6200B Bedienungsanleitung

NETGEAR

NETGEAR WNR3500Lv2 Bedienungsanleitung

NETGEAR

NETGEAR DG834G - 54 Mbps Wireless ADSL Firewall... Bedienungsanleitung

NETGEAR

NETGEAR DG834Gv3 - 54 Mbps Wireless ADSL Firewall... Bedienungsanleitung

NETGEAR

NETGEAR WNDR4500v2 Bedienungsanleitung

NETGEAR

NETGEAR MBR1516 Bedienungsanleitung

NETGEAR

NETGEAR HR314 - Wireless Router Bedienungsanleitung

NETGEAR

NETGEAR R6300v2 Bedienungsanleitung

NETGEAR

NETGEAR WGR614 v5 Bedienungsanleitung

Beliebte WLAN-Router Handbücher anderer Marken

Milesight

Milesight UG67 Bedienungsanleitung

Airlogic

Airlogic AirSync Class 1 Betriebsanleitung

Samsung

Samsung WCH730B Bedienungsanleitung

TELEFONICA

TELEFONICA USB Adapter Bedienungsanleitung

Askey

Askey RAC2V1K Bedienungsanleitung

Alloy

Alloy WLF2454AP-S Bedienungsanleitung

TP-Link

TP-Link TL-WR542G Bedienungsanleitung

Hama

Hama 53120 Bedienungsanleitung

Intellinet

Intellinet 524582 Bedienungsanleitung

Asus

Asus RT-N10P Bedienungsanleitung

D-Link

D-Link DIR-506L Bedienungsanleitung

Sapido

Sapido GR297n Bedienungsanleitung

Asus

Asus DSL-N55U Bedienungsanleitung

AMTC

AMTC WR7502 Bedienungsanleitung

Compaq

Compaq CP-2W - iPAQ Connection Point Bedienungsanleitung

SMC Networks

SMC Networks WBR14-N2 FICHE Bedienungsanleitung

Draytek

Draytek Vigor2120 Series Bedienungsanleitung

Sitecom

Sitecom WLR-4000 Bedienungsanleitung
