Netio PowerCable 101 Series Bedienungsanleitung
PowerCable xxx
101x
MANUAL
-PowerCable Modbus 101x
-PowerCable MQTT 101x
-PowerCable REST 101x
29.4.2020
2
Table of Contents
Introduction .......................................................................................................... 4
1Safety notices .................................................................................................. 4
2General characteristics ....................................................................................... 4
3PowerCable xxx ................................................................................................ 6
4Specifications .................................................................................................. 8
4.1 Specifications of different socket types...................................................... 9
4.2 Features ..........................................................................................11
4.3 Drawings..........................................................................................13
4.4 Device description ..............................................................................14
4.5 LED and button functions ......................................................................15
4.6 Minimum system requirements (for configuration)........................................15
4.7 Package contents ...............................................................................16
5Configuration and control ...................................................................................17
5.1 Connecting PowerCable to a local WiFi (AP Mode) ........................................17
5.2 NFC installation in 60 seconds ................................................................20
5.2.1 NETIO Mobile2 for Android ........................................................20
5.3 Detecting and configuring the IP address ...................................................20
5.4 Login to device web ............................................................................22
5.5 Restoring factory defaults .....................................................................23
5.6 Controlling the output manually..............................................................24
6Web interface .................................................................................................25
6.1 Outputs ...........................................................................................25
6.1.1 Outputs - Energy measurements .................................................26
6.1.2 Outputs - General ..................................................................27
6.2 M2M API Protocol Actions ......................................................................29
6.3 Cloud..............................................................................................30
6.4 Users ..............................................................................................33
6.5 Settings ...........................................................................................35
6.5.1 Wi-Fi..................................................................................35
6.5.2 Network Configuration ............................................................36
6.5.3 Date / Time .........................................................................38
6.5.4 Firmware.............................................................................38
6.5.5 System................................................................................41
6.6 Log.................................................................................................43
7PowerCable REST 101x.......................................................................................44
7.1 Overview .........................................................................................44
7.2 M2M API Protocol – XML (REST M2M API).....................................................45
7.3 M2M API Protocol – JSON (REST M2M API) ...................................................49
7.4 M2M API Protocol – URL-API (REST M2M API)................................................53
7.5 M2M API Protocol – SNMP.......................................................................56
8PowerCable Modbus 101x ...................................................................................59
8.1 Overview .........................................................................................59
8.2 M2M API Protocol – Modubus/TCP ............................................................60
8.3 M2M API Protocol – Telnet .....................................................................64
8.4 M2M API Protocol – SNMP.......................................................................68
9PowerCable MQTT 101x......................................................................................69
9.1 Overview .........................................................................................69
9.2 M2M API Protocol – MQTT-flex ................................................................70
9.3 M2M API Protocol – Netio Push ................................................................73
9.4 M2M API Protocol – SNMP.......................................................................74
10 PowerCable OEM DevKit 101x...............................................................................75
10.1 Overview .........................................................................................75
10.2 OEM – custom modifications (customizations)..............................................76
11 NETIO products overview....................................................................................77
3
4
Introduction
Thank you for purchasing this product of NETIO products a.s. Before using your product, please read
this
User Manual
(MAN) and the included
Quick Installation Guide (QIG)
to avoid problems with
incorrect installation or use.
Caution:
The product works with mains voltage. Mishandling may damage it or result in injury or death.
1Safety notices
1. The manufacturer is not liable for any damage caused by incorrect use of the device or by
operating it in an unsuitable environment.
2. The device is not rated for outdoor use.
3. Do not expose the device to strong vibrations.
4. Unauthorized modifications may damage the device or cause a fire.
5. Protect the device from liquids and excessive temperatures.
6. Make sure the device does not fall.
7. Only electrical appliances approved for use in the electrical network may be connected to the
device.
8. Do not connect multiple devices in series.
9. The cable plug must be easily accessible.
10. The device is completely switched off only when unplugged from the wall socket.
11. If the device malfunctions, disconnect it from the electrical power supply and contact your
vendor.
2General characteristics
One metered and controlled 110/230V output
WiFi interface: 802.11 b/g/n; 2.4GHz (secured / unsecured)
WiFi encryption: WEP, WPA, WPA2
AP mode for connecting the device to a local WiFi network (network selected from a list)
Button to activate AP mode
Output state can be toggled with the On/OFF button (press 3 times)
Built-in web server for device configuration and control
Password-protected login into device configuration
Electricity consumption metering (6 parameters): [V, Hz, A, W, Wh, TPF]
Measurement accuracy <1%
5
ZCS (Zero Current Switching)
IOC (Independent Output Control)
PowerUp state - (ON / OFF / LAST)
1.2m cable
Overvoltage protection
Operating temperature range: -20°C to +65°C
Supported protocols: DNS, NTP, DHCP, HTTP
Supported M2M protocols:
PowerCable Modbus 101x: Modbus/TCP, Telnet, SNMP
PowerCable MQTT 101x: MQTT, Http(s) Push, SNMP
PowerCable REST 101x: XML API, JSON API, URL API, SNMP
6
3PowerCable xxx
PowerCable Modbus 101x PowerCable REST 101x PowerCable MQTT 101x
Overview of types according to the supported M2M protocols
Type / Protocol
PowerCable
Modbus 101x PowerCable
REST 101x PowerCable
MQTT 101x
Web interface Yes Yes
Yes
Telnet Yes -
-
Modbus/TCP Yes -
-
URL API -Yes
-
XML API -Yes
-
JSON API -Yes
-
MQTT-flex --
Yes
Netio Push JSON --
Yes
Netio Push XML --
Yes
SNMP v1 Yes Yes
Yes
PowerCable
Modbus 101x PowerCable
REST 101x PowerCable
MQTT 101x
NETIO Cloud Yes Yes
Yes
NETIO Mobile2 Yes Yes
Yes
7
Overview of models according to the electrical socket type
Model
Variant Output socket Input plug Voltage Max.
current Max.
load
101F DE Type F
E/F (CEE 7/7)
230V ~
16
A
3600
W
101E F
R
Type E
E/F (CEE 7/7)
230V ~
16
A
3600
W
101J CH Type J
Type J
230V ~
10
A
2300
W
101S IEC-320 C13/C14 IEC-320 C13
IEC-320 C14
110/230V ~
10
A
2300
W
101B US Type B
Type B
110V ~
15
A
1600
W
101G U
K
Type G
Type G
230V ~
13
A
3000
W
8
4Specifications
Power
101E, 101F: 230V~; 50Hz; 16A
101J: 230V~; 50Hz; 10A
101S: 110/230V~; 60/50Hz; 10A
101G: 230V~; 50Hz; 13A
101B: 110V~; 60Hz; 15A
Switched outputs
101E, 101F: 230V~; 50Hz; 16[8]A; max. 3600W
101J: 230V~; 50Hz; 10[8]A; max. 2300W
101S: 110/230V~; 60/50Hz; 10[8]A; max. 2300W
101G: 230V~; 50Hz; 13[8]A; max. 3000W
101B: 110V~; 60Hz; 15[8]A; max. 1600W
Surge protection Type 3 (CAT III)
Internal consumption Max 1W
Output relay
Micro-disconnection (µ) (resistive load)
1E5 switching cycles, max. 1.5kV pulse voltage
Switch heat and fire resistance class 1
Interfaces
PowerCable xxx 101x
1x Wi-Fi 802.11b/g/n 2.4 GHz (internal antenna)
with WEP/WPA/WPA2
Environment
IP30, protection rating = class 1
Operating temperature -10 .. 65°C (6A load = max. 63°C,
10A = max. 50°C, 16A = max. 30°C)
Device rated for pollution degree 2.
Designed for continuous operation in altitudes up to 2000m.
No additional cooling required.
Caution
The device is not designed to power appliances with a high inrush
current.
Do not connect several devices in series.
The device is safe only when completely disconnected from the
electrical network. The cable plug serves as the disconnection means
and must be easily accessible.
The electrical socket must be earthed and protected with a circuit
breaker rated at 16A or less.
9
4.1 Specifications of different socket types
NETIO products a.s. supplies the PowerCable xxx 101x in several variants with different
electrical plug/outlet types.
Figure 1 - PowerCable xxx 101F
(DE–schuko - Type F)
Figure 2 - PowerCable xxx 101E
(FR –Type E)
Figure 3 - PowerCable xxx 101J
(CH –Type J)
10
Figure 4 - PowerCable xxx 101S
(IEC-320 C13/C14)
Figure 5 - PowerCable xxx 101B
(US –Type B)
Figure 6 - PowerCable xxx 101G
(UK –Type G)
