[ENG] NetPing Input+Relay R404, User guide



[ENG] NetPing Input+Relay R404, User guide -
2
Содержание

[ENG] 1. [DKST 57]Introduction.................................................................................. 5
[ENG] 2. [DKST 57]Copyright and Disclaimer............................................................. 6
[ENG] 3. [DKST 57]Shipping Kit .................................................................................. 7
[ENG] 4. [DKST 57]Device overview and main features............................................. 8
General view of the device................................................................................................................. 8
Front panel ......................................................................................................................................... 8
Back view............................................................................................................................................ 9
Side view............................................................................................................................................. 9
Device mounting method .................................................................................................................. 9
General characteristics .................................................................................................................... 10
[ENG] 5. [DKST 57]Sockets and Indication Elements .............................................. 12
Front panel ....................................................................................................................................... 12
Connectors on the bottom of the device ........................................................................................ 13
Connectors on the top of the device............................................................................................... 14
[ENG] 6. [DKST 57]Connection, installation and initial configuration of the
device......................................................................................................................... 17
Step 1................................................................................................................................................ 17
Step 2................................................................................................................................................ 17
Step 3................................................................................................................................................ 17
Step 4................................................................................................................................................ 18
Step 6................................................................................................................................................ 20
[ENG] 7. [DKST 57]Connection of external sensors and actuators. ........................ 21
Connected sensors and actuators:.................................................................................................. 21
Sensors of the 1-Wire model range ................................................................................................. 21
Sensors of the "dry contact" type ................................................................................................... 21
Two-wire sensors (discrete) ............................................................................................................ 22
Connection cable leak sensor VT592 .............................................................................................. 22
Leak sensor....................................................................................................................................................................... 23
NetPing Supply Voltage Sensor 995S2............................................................................................................................ 23

[ENG] NetPing Input+Relay R404, User guide -

Impact sensor................................................................................................................................................................... 24

PIR detector (mod.M105-1E)............................................................................................................................................ 25

External loads for RELAYS................................................................................................................ 26

Buzzer (mod.STD-3025) ................................................................................................................... 27

Airflow sensor + GRID 120 * 120 * 10mm NC ................................................................................... 28

Smoke detector (mod. M206-5E)..................................................................................................... 28

[ENG] 8. [DKST 57]Use of IN, OUT and RELAYS lines................................................ 30

Electrical parameters INPUT, OUTPUT lines and RELAYS.............................................................. 30

[ENG] 9. [DKST 57]Factory reset device ................................................................... 32

[ENG] 10. [DKST 57]Precautions............................................................................... 33

[ENG] 11. [DKST 57]Warranty.................................................................................... 34

[ENG] 12. [DKST 57]Additional Documents and Links............................................. 35

[ENG] 13. [DKST 57]Backup power supply............................................................... 36

Plug-in battery module.................................................................................................................... 36

[ENG] NetPing Input+Relay R404, User guide -

              –

•

[ENG] 1. [DKST 57]Introduction

[ENG] 2. [DKST 57]Copyright and Disclaimer

[ENG] 3. [DKST 57]Shipping Kit

[ENG] 4. [DKST 57]Device overview and main features

[ENG] 5. [DKST 57]Sockets and Indication Elements

[ENG] 6. [DKST 57]Connection, installation and initial configuration of the device

[ENG] 7. [DKST 57]Connection of external sensors and actuators.

[ENG] 8. [DKST 57]Use of IN, OUT and RELAYS lines.

[ENG] 9. [DKST 57]Factory reset device

[ENG] 10. [DKST 57]Precautions

[ENG] 11. [DKST 57]Warranty

[ENG] 12. [DKST 57]Additional Documents and Links

[ENG] 13. [DKST 57]Backup power supply

[ENG] NetPing Input+Relay R404, User guide -[ENG] 1. [DKST 57]Introduction

[ENG] 1. [DKST 57]Introduction

              –

[ENG] 1. [DKST 57]Introduction

This user guide helps to become familiar with an operation of a NetPing Input+Relay R404 device and get an idea

about its functionality and technical specifications as well as prepare a device for an operation.

A User Guide is designed for network administrators and users, who set up or operate a device. To work with a

device properly, a user must have an idea about the principles of building and functioning of local networks as well

as possess the next knowledge and skills:

Basic knowledge in the area of local and global networks;

Basic knowledge in the area of architecture and principles of work of TCP/IP networks;

Basic knowledge in the area of architecture and principles of work of Ethernet networks.

[ENG] NetPing Input+Relay R404, User guide -[ENG] 2. [DKST 57]Copyright and Disclaimer

[ENG] 2. [DKST 57]Copyright and Disclaimer

              –

[ENG] 2. [DKST 57]Copyright and Disclaimer

The information, contained in this document, can be changed by a manufacturer without a prior notice. Although

every effort was made to make the information in this document accurate and without errors, a manufacturer is not

liable for their possible presence and for the consequences that may result from the errors herein. A manufacturer is

not liable if supplied equipment, software and this user guide does not correspond to expectations of a user and

his/her opinion about where and how to use all the above. All copyrights on supplied devices, described in this User

Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Copying,

replication and translation of this user guide to other languages are not allowed without a prior written permission

of a rightholder. Copying, replication, changing, disassembling of provided software are not allowed without a prior

written permission of a rightholder. For the part of software that is provided in source codes, there is a separate

license agreement, which defines an order of its use and modification. Other trademarks used in this description

belong to corresponding rightholders.

Developer and manufacturer:

NetPing east Co Ltd.

www.netpingdevice.com

[email protected]

[ENG] NetPing Input+Relay R404, User guide -[ENG] 3. [DKST 57]Shipping Kit

[ENG] 3. [DKST 57]Shipping Kit

              –

•

[ENG] 3. [DKST 57]Shipping Kit

Supply package

If any of the items listed below are missing, contact the seller:

NetPing Input+Relay R404 — 1 pc.;

a screw driver — 1 pc.;

power adapter 12V 1.5A — 1 pc.;

a quick start guide — 1 pc.;

a package box — 1 pc.;

a terminal STK-15EDGK-3.5-6P — 3 pcs.;

a terminal STK-15EDGK-3.5-10P — 2 pcs.;

a terminal STK-15EDGK-3.5-8P — 1 pcs.;

A shipping kit may be altered by a manufacturer!

[ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features

[ENG] 4. [DKST 57]Device overview and main features

              –

[ENG] 4. [DKST 57]Device overview and main features

A device for remote monitoring of sensors over an Ethernet/Internet network on the mounting rail of compatible

DIN 43880-1988 devices. Allows you to remotely receive information about the status of sensors and notifications

about sensor activation, manage connected devices.

General view of the device

Front panel

[ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features

[ENG] 4. [DKST 57]Device overview and main features

              –

Back view

Side view

Device mounting method

Mounting is carried out on a rail compatible with DIN 43880-1988

[ENG] NetPing Input+Relay R404, User guide -[ENG] 4. [DKST 57]Device overview and main features

[ENG] 4. [DKST 57]Device overview and main features

              –

Installation of the device is carried out in an industrial-type cabinet, which ensures the absence of moisture and

condensation in the working space, and also carries out the forced outflow of excess heat

General characteristics

Parameter Value

Supply voltage range from external power

supply

11,8V - 13V

Power consumption no more than 30Watt

Ethernet connector 2x10/100 BASE-TX (unmanaged L2 switch)

Connector 1-wire with independent drivers 4 pcs. (independent output stage, 50 m per connector).
