Netvox R718A01 Bedienungsanleitung

Wireless Temperature and Humidity Sensor for Low Temperature

Environment

R718A01

Wireless Temperature and Humidity Sensor

for Low Temperature Environment

R718A01

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be

maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written

permission of NETVOX Technology. The specifications are subject to change without prior notice

Table of Content

1. Introduction ...........................................................................................................................................2

2. Appearance ............................................................................................................................................3

3. Main Features ........................................................................................................................................3

4. Set up Instruction...................................................................................................................................4

5. Data Report............................................................................................................................................5

5.1 Data Storage Function.....................................................................................................................6

5.2 Example of ReportDataCmd ...........................................................................................................6

5.3 Example of ConfigureCmd .............................................................................................................7

5.4 Example for MinTime/MaxTime logic ...........................................................................................8

6. Installation ........................................................................................................................................... 10

7. Information about Battery Passivation................................................................................................. 12

7.1 To determine whether a battery requires activation.......................................................................12

7.2 How to activate the battery ...........................................................................................................12

8. Important Maintenance Instruction......................................................................................................13

1. Introduction

R718A01, mainly used to detect the temperature and humidity at low temperature environment such as the freezer air. It collects

data over LoRa network and sends it to devices to be shown, fully compatible with LoRa protocol.

LoRa Wireless Technology:

LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other

communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation

equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption,

transmission distance, anti-interference ability and so on.

LoRaWAN:

LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and

gateways from different manufacturers.

2. Appearance

3. Main Features

⚫Compatible with LoRaWAN protocol.

⚫2 x ER14505 AA lithium batteries (3.6V/ section) parallel power supply

⚫Capable to detect the temperature and humidity

⚫Capable to cache 50 records of temperature and humidity data

⚫Simple operation and installation

⚫IP rating IP65

⚫Compatible with LoRaWANTM Class A

⚫Frequency hopping spread spectrum

⚫Configuration parameters can be configured via a third-party software platform, data can be read and alerts can be set via SMS text

and email (optional)

⚫Applicable to third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne

⚫Low power consumption and long battery life

⚫Battery Life:

⁻ Please refer to web: http://www.netvox.com.tw/electric/electric_calc.html/

⁻ At this website, users can find battery life time for variety models at different configurations.

1. Actual range may vary depending on environment.

2. Battery life is determined by sensor reporting frequency and other variables.

Indicator

Function Key

Built-in temperature and humidity

sensor

4. Set up Instruction

On/Off

Power on

Insert batteries. (users may need a screwdriver to open)

Turn on

Press and hold the function key for 3 seconds till the green indicator flashes once.

Turn off (Restore to factory setting)

Press and hold the function key for 5 seconds till green indicator flashes for 20 times.

Power off

Remove Batteries.

Note

1. Remove and insert the battery; the device is at off state by default.

2. On/off interval is suggested to be about 10 seconds to avoid the interference of

capacitor inductance and other energy storage components.

3. At 1st -5th second after power on, the device will be in engineering test mode.

Network Joining

Never joined the network

Turn on the device to search the network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Had joined the network

(not at factory setting)

Turn on the device to search the previous network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Fail to join the network

Suggest to check the device registration information on the gateway or consult your platform

server provider.

Function Key

Press and hold for 5 seconds

Restore to factory setting / Turn off

The green indicator flashes for 20 times: success

The green indicator remains off: fail

Press once

The device is in the network: green indicator flashes once and sends a report

The device is not in the network: green indicator remains off

Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the reportchange exceeds setting value or the state changes: send a data report according

to Min Interval.

Low Voltage Warning

Low Voltage

3.2V

The device will immediately send a version packet report along with an uplink packet including temperature, humidity and

battery voltage.

The device sends data in the default configuration before any configuration is done.

Default setting:

MaxTime : Max Interval = 15 min = 900s

MinTime : Min Interval = 15 min = 900s (the current voltage value is detected every Min Interval)

BatteryChange: 0x01 (0.1V)

TemperatureChange:0x0064 (1℃)

HumidityChange:0x0064 (1%)

Data Storage Function

1. R718A01 has the function of temperature and humidity data storage, and the upper limit of stored data is 50 packets

(if more than 50 packets, the initially stored data will be overwritten. For example, the data in packet 51 covers packet 1,

and the data in packet 52 covers packet 2, and so on)

2. Users read the data they want to find by issuing command ”ReadBackUpDataReq”

3. When issuing the ReadBackUpDataReq command, the UplinkCounter is based on the serial number (Fcnt) on the network

server. For example, if fcnt = 51 on the network server, downlink port 12, 0100000033 *(33Hex = 51Dec)

4. If the fcnt belongs to a non-temperature and humidity packet or there is no fcnt, reply no found.

5. Only the temperature and humidity data are stored, others such as battery power and time data are not stored.

Note:

The device report interval will be programmed based on the default firmware which may vary.

The interval between two reports must be the minimum time.

Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver

http://loraresolver.netvoxcloud.com:8888/page/index to resolve uplink data.

5. Data Report

Data report configuration and sending period are as following:

Min Interval

(Unit:second)

Max Interval

(Unit:second)

Reportable Change

Current Change≥

Reportable Change

Current Change＜

Reportable Change

Any number between

1~65535

Any number between

1~65535

Can not be 0.

Report

per Min Interval

Report

per Max Interval

5.1 Data Storage Function

FPort: 0x0C

Ex1.

Downlink: 0100000001 // Read Fcnt 1 data

Respond: 8100000001000A721745 // Temperature = 26.74°, Humidity = 59.57%

0A72 Hex = 2674Dec

1745 Hex = 5957Dec

Ex2.

Downlink: 0100000033 // Read Fcnt 51 data

Respond: 8100000033000A281770 // Temperature = 26°, Humidity = 60%

At this time, if fcnt 1 is read again, the data will not be found because it has been overwritten by fcnt 51.

5.2 Example of ReportDataCmd

FPort：0x06

Bytes

Var(Fix=8 Bytes)

Version

DeviceType

ReportType

NetvoxPayLoadData

Version–1 byte –0x01——the Version of NetvoxLoRaWAN Application Command Version

DeviceType–1 byte –Device Type of Device

The devicetype is listed in Netvox LoRaWAN Application Devicetype doc

ReportType – 1 byte –the presentation of the NetvoxPayLoadData，according the devicetype

NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)

Device

Type

Report

Type

NetvoxPayLoadData

R718A

(R718A01)

0x0B

0x01

Battery

(1Byte, unit:0.1V)

Temperature

(Signed2Bytes,unit:0.01°C)

Humidity

(2Bytes,unit:0.01%)

Reserved

(3Bytes,fixed 0x00)

Description

CmdID

PayLoad

ReadBackUpDataReq

0x01

ResendUpLinkCounter(4bytes)

ReadBackUpDataRsp

0x81

Resend (4bytes)

UpLinkCounter

Status (1byte)

0x00_Found

0x01_NoFound

Temperature

(Signed2Bytes,unit:0.01°C)

When not found, it will be 0x0000

Humidity

(2Bytes,unit:0.01%)

When not found, it will be 0x0000

Uplink: 010B01220A52169E000000

1st byte (01): Version

2nd byte(0B): DeviceType 0x0B － R718A/R718A01

3rd byte (01): ReportType

4th byte(22): Battery － 3.4V, 22(Hex) = 34(Dec), 34x0.1v=3.4v

5th6th byte (0A52): Temperature －26.42oC , A52(Hex)=2642 (Dec), 2642x0.01=26.42°

7th8th byte (169E): Humidity － 57.9%, 169E(Hex)=5790(Dec), 5790x0.01=57.9%

9th-11th byte (000000): Reserved

5.3 Example of ConfigureCmd

FPort：0x07

Bytes

Var (Fix =9 Bytes)

CmdID

DeviceType

NetvoxPayLoadData

CmdID–1 byte

DeviceType–1 byte –Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

(1)Command Configuration:

MinTime = 1min、MaxTime = 1min、BatteryChange = 0.1v、TemperatureChange = 1℃、HumidityChange = 1%

Downlink： 010B003C003C0100640064 003C(Hex) = 60(Dec), 64(Hex) = 100(Dec)

Response：

810B000000000000000000 (Configuration success)

Description

Device

Cmd

Device

Type

NetvoxPayLoadData

Config

ReportReq

R718A

(R718A01)

0x01

0x0B

MinTime

(2bytes Unit:s)

MaxTime

(2bytesUnit:s)

BatteryChange

(1byte Unit:0.1v)

TemperatureChange

(2byte Unit:0.01℃)

HumidityChange

(2byte Unit:0.01%)

Config

ReportRsp

0x81

Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq

0x02

Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp

0x82

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte Unit:0.1v)

TemperatureChange

(2byte Unit:0.01℃)

HumidityChange

(2byte Unit:0.01%)

810B010000000000000000 (Configuration failure)

(2)Read Configuration:

Downlink： 020B000000000000000000

Response：

820B003C003C0100640064（Current configuration）

5.4 Example for MinTime/MaxTime logic

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V

MaxTime MaxTime

Sleeping(MinTime) Sleeping(MinTime)

Note: MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange

value.

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

Sleeping(MinTime) sleeping sleeping sleeping

0H 15th M 30th M 45th M 1H 2H

Wakes up and

collects data

3.6V

Does not report

Wakes up and

collects data

3.6V

Does not report

Wakes up and

collects data

3.6V

Does not report

Wakes up and

collects data

REPORTS 3.6V

Wakes up and

collects data

REPORT 3.6V

Wake up and collects data

REPORTS 3.6V

Wakes up and collects data

REPORTS 3.6V

Wakes up and collects data

REPORTS 3.6V

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

sleeping sleeping ...

0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M

Note:

1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect

data.

Notes :

1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect

data.

2) The data collected is compared with the last data reported. If the data variation is greater than the ReportableChange value, the

device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device reports

according to MaxTime interval.

3) We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up

frequently and the battery will be drained soon.

4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle

of MinTime/MaxTime calculation is started.

Wakes up and

collects data

REPORTS 3.6V

Wakes up and collects data

3.5V |3.5-3.6|=0.1

REPORTS 3.5V

Wakes up and

collects data

3.5V

Does not report

Wakes up and

collects data

3.5V

Does not report

Wakes up and

collects data

3.5V

Does not report

Wakes up and

collects data 3.5V

Does not report

Wakes up and

collects data

3.5V

Does not report

Wakes up and

collects data

REPORTS 3.5V

Wakes up and

collects data

3.6V

Does not report

Users push the button,

REPORTS 3.5V.

Recalculate MaxTime.

Inhaltsverzeichnis

Andere netvox Temperaturregler Handbücher

netvox

netvox R718AD Bedienungsanleitung

netvox

netvox RA0716 Bedienungsanleitung

netvox

netvox R711 Bedienungsanleitung

netvox

netvox R720A Bedienungsanleitung

netvox

netvox R720E Bedienungsanleitung

netvox

netvox R718AB Bedienungsanleitung

netvox

netvox R718PB14 Bedienungsanleitung

netvox

netvox R718A Bedienungsanleitung

netvox

netvox R718EC Bedienungsanleitung

netvox

netvox R720C Bedienungsanleitung

netvox

netvox R711A Bedienungsanleitung

netvox

netvox RA0715 Bedienungsanleitung

netvox

netvox R718A Bedienungsanleitung

Beliebte Temperaturregler Handbücher anderer Marken

Swegon

Swegon LUNAd MB Bedienungsanleitung

Lucky Reptile

Lucky Reptile Thermo Control II Bedienungsanleitung

SENSORMETRIX

SENSORMETRIX Argon 100 Bedienungsanleitung

Fuji Electric

Fuji Electric PXE4 Bedienungsanleitung

Yuyao gongyi

Yuyao gongyi XMT-808 series Bedienungsanleitung

Selec

Selec TC544C Bedienungsanleitung

P.W. KEY

P.W. KEY rt-208gt Bedienungsanleitung

Future Design

Future Design FDC-9200 Bedienungsanleitung

BH Thermal

BH Thermal BriskONE Bedienungsanleitung

Omron

Omron E5EX-H Bedienungsanleitung

West Control Solutions

West Control Solutions KS 45 Kurzanleitung

MCS

MCS RITC-15B Bedienungsanleitung

SMC Networks

SMC Networks Thermo-con INR-244-639 Bedienungsanleitung

eltherm

eltherm Ex-TC It Series Bedienungsanleitung

Omron

Omron C200H-TV Series Bedienungsanleitung

industrie technik

industrie technik CA1 Bedienungsanleitung

KRAL

KRAL EET 32 Bedienungsanleitung

dixell

dixell XR420C Verdrahtungsschema

netvox R718A01 Bedienungsanleitung

Beliebte Temperaturregler Handbücher anderer Marken
