CONSTRUCTION

SERVICE MANUAL

E215B

E245B

Crawler Excavators ROPS Tier III

Print No. 84392396A

1aEdition

English 12/10

WARNING

Read this manual before operating the machine

Most accidents occurring during work are due to non-observance of simple safety norms and elementary

precautions.

Many accidents can be avoided if the causes are known and opportune cautions taken beforehand.

There is no device or protection, no matter how advanced, that may prove so effective at avoiding accidents

as a careful and attentive behaviour.

WARNING

Ensure that the attachment is safely resting onto the ground before repairing, adjusting or servicing machines

fitted with hydraulically, mechanically or cable controlled attachments (such as, excavators, loaders, dozers,

scrapers, etc.). Should it be necessary to partially or fully raise the hydraulically, mechanically or cable

controlled attachment to gain access to certain items, make sure the attachment is adequately retained in the

raised position by means other than the hydraulic lift cylinders, cables and/or mechanical devices used for

controlling it.

Product Support

Strada di Settimo, 323 - S. MAURO T.SE ( TO ) ITALY

Find manuals at https://best-manuals.com

IN - 1

INTRODUCTION E215B-E245B

TO THE READER

• This manual is written for an experienced

technician to provide technical information

needed to maintain and repair this machine.

- Be sure to thoroughly read this manual for

correct information concerning the service

procedures.

- If you have any questions or comments, or if you

found any errors regarding the contents of this

manual, please contact:

NEW HOLLAND KOBELCO

CONSTRUCTION MACHINERY S.p.A.

Strada Settimo, 323

San Mauro Torinese (TO)

10099 ITALIA

PRODUCT SUPPORT

Fax. ++39 011 0077357

ADDITIONAL REFERENCES

• Please refer to the materials listed below in

addition to this service manual:

- Operation and Maintenance Instruction

Manual

-PartsCatalog

WORKSHOP MANUAL COMPOSITION

• The Workshop Manual consists of five parts:

- “Safety Precautions”

- “Operational Principle”

- “Operational Performance Test”

- “Troubleshouting”

- “Repair Instructions”

- The “Safety Precaution” part includes the

recommended procedures that, if followed, can

avoid the risk of accident for operator and for staff

related to the work and maintenance machine

operations.

- The “Operational Principle” part includes the

technical information concerning the operation of

main devices and systems.

- The “Operational Performance Test” part includes

the information needed to carry out the machine

operational performance test.

- The “Troubleshooting” part includes the technical

information needed for troubleshooting and

malfunction detection.

- The “Repair Instruction” part includes information

needed for maintenance and repair of the

machine, tools and devices needed for

maintenance and repair, maintenance standards,

removal/installation and assembly/disassembly

procedures.

Find manuals at https://best-manuals.com

E215B-E245B INTRODUCTION

IN - 2

PAGE NUMBER

• Each page has a number, located on the external upper corner of the page. Each page number contains the

following information:

Example: T 1-2-3

Consecutive page number for each group

Group number (if exist))

Section number

T: Technical Manual

W: Workshop Manual

SYMBOLS

In this manual, the following safety alert symbol and signal words are used to alert the reader to the potential

for personal injury or machine damage.

This is the safety alert symbol.

When you see this symbol, be alert to the potential for personal injury.

Never fail to follow the safety instructions prescribed along with the safety alert symbol.

The safety alert symbol is also used to draw attentio in to component/part weights.

To avoid injury and damage, be sure to use appropriate lifting techniques and equipment when lifting

heavy parts.

UNITS USED

SI Units (International System of Units) are used in this manual.

MKSA system units and English units are also indicated in parentheses just behinds SI units.

Example: 24.5 MPa (250 kgf/cm2)

A table for conversion from SI units to other system units is shown below for reference purposes.

Quantity To convert from

(SI)

Into

(Others)

Multiply by Quantity To convert from

(SI)

Into

(Others)

Multiply by

Lenght mm in 0.03937 Pressure MPa kgf/cm210.197

mm ft 0.003281 MPa psi 145.0

Volume L US gal 0.2642 Power kW CV-PS 1.360

L US qt 1.057 kW HP 1.341

m3yd31.308 Temperature °C °F °C x 1.8 + 32

Mass kg lb 2.205 Velocity km/h mph 0.6214

Force N kgf 0.10197 min-1 rpm 1.0

N lbf 0.2248 Flow rate L/min US gpm 0.2642

Torque N.m kgf.m 0.10197 mL/rev cc/rev 1.0

N.m lbf.ft 0.7375

Find manuals at https://best-manuals.com

INDEX E215B-E245B

MANUAL INDEX

SAFETY PRECAUTIONS Page

Section 1 GENERALITIES ..................................................................... S1

Section 2 SAFETY PRECAUTIONS ..................................................... S2

Section 3 SAFETY PLATES .................................................................. S3

OPERATIONAL PRINCIPLE

Section 1 GENERAL

Group 1 Specifications................................................................................. T1-1

Group 2 Component Layout ........................................................................ T1-2

Section 2 SYSTEM

Group 1 Mechatro control system................................................................ T2-1

Group 2 Hydraulic System........................................................................... T2-2

Group 3 Electrical System ........................................................................... T2-3

Section 3 COMPONENT OPERATION

Group 1 Hydraulic Pump Assy..................................................................... T3-1

Group 2 Pilot Valve ...................................................................................... T3-2

Group 3 Control Valve ................................................................................. T3-3

Group 4 Swing Device ................................................................................. T3-4

Group 5 Travel Device ................................................................................. T3-5

Group 6 Swivel Joint.................................................................................... T3-6

Group 7 Cylinders........................................................................................ T3-7

Group 8 Air Conditioner system................................................................... T3-8

OPERATIONAL PERFORMANCE TEST

Section 4 OPERATIONAL PERFORMANCE TEST

Group 1 Introduction ................................................................................... T4-1

Group 2 Standard Performances ................................................................. T4-2

Group 3 Test Procedures ............................................................................ T4-3

Group 4 Mechatro Controller ....................................................................... T4-4

TROUBLESHOOTING

Section 5 TROUBLESHOOTING

Group 1 Troubleshooting (by error codes)................................................... T5-1

Group 2 Troubleshooting (by trouble) .......................................................... T5-2

Group 3 Troubleshooting (trouble diagnosis mode)..................................... T5-3

Find manuals at https://best-manuals.com

E215B-E245B INDEX

REPAIR INSTRUCTIONS

Section 1 GENERAL INFORMATION

Group 1 Precautions for Disassembly and Assembly.................................W1-1

Group 2 Tightening Torque ........................................................................W1-2

Section 2 UPPERSTRUCTURE

Group 1 Upperstructure ..............................................................................W2-1

Group 2 Pump Device.................................................................................W2-2

Group 3 Control Valve ................................................................................W2-3

Group 4 Swing Device ...............................................................................W2-4

Group 5 Pilot Valve .....................................................................................W2-5

Section 3 UNDERCARRIAGE

Group 1 Swing Bearing ..............................................................................W3-1

Group 2 Travel Device ...............................................................................W3-2

Group 3 Swivel Joint ..................................................................................W3-3

Group 4 Track Adjuster ..............................................................................W3-4

Group 5 Front Idler .....................................................................................W3-5

Group 6 Upper and Lower Roller ...............................................................W3-6

Group 7 Tracks ...........................................................................................W3-7

Section 4 FRONT ATTACHMENT

Group 1 Front attachment...........................................................................W4-1

Find manuals at https://best-manuals.com

SAFETY PRECAUTIONS

M0103

Find manuals at https://best-manuals.com

SAFETY PRECAUTIONS E215B-E245B

INDEX

Section 1 GENERALITIES

Section 2 SAFETY PRECAUTIONS

Section 3 SAFETY PLATES
