Newer Technology MAXPower Bedienungsanleitung

Quick Installation Guide

MaxPower 802.11n/g/b Wireless Guide

Table of Contents

English

1. Before Installation .............................................................................................................................2

2. Hardware Installation ........................................................................................................................3

3. Configure your computer’s TCP/IP Settings......................................................................................4

4. Configure your AP.............................................................................................................................7

Français

1. Avant l'Installation............................................................................................................................11

2. Installation du Matériel....................................................................................................................12

3. Configurer les Paramètres TCP/IP de votre Ordinateur..................................................................13

4. Configurer votre AP.........................................................................................................................16

Deutsch

1. Vor der Installation ..........................................................................................................................20

2. Hardware-Installation......................................................................................................................21

3. Die TCP/IP-Einstellungen TCP/IP Ihres Computers konfigurieren..................................................22

4. Den AP konfigurieren ......................................................................................................................25

Italiano

1. Prima dell’installazione....................................................................................................................29

2. Installazione dell’hardware..............................................................................................................30

3. Configurazione delle Impostazioni TCP/IP del computer ................................................................31

4. Configurazione dell’AP....................................................................................................................34

Español

1. Antes de la Instalación....................................................................................................................38

2. Instalación del Hardware.................................................................................................................39

3. Programe la Configuración TCP/IP de su computadora..................................................................40

4. Configurar su AP.............................................................................................................................43

한국어

1. 설치 시작 전..................................................................................................................................47

2. 하드웨어 설치하기.........................................................................................................................48

3. 사용자 컴퓨터의 TCP/IP 등록하기 ...............................................................................................49

4. 사용자 AP 등록하기......................................................................................................................52

1. Before Installation

Thank you for purchasing the Wireless 11n AP Router. This guide will help you set-up and configure

your AP with easy-to-follow instructions. For more detailed or advanced settings, please refer to the

User Manual on the CD-ROM.

Package Contents

Please make sure you have the following in the box:

♦WRTR-501 Wireless-N Broadband AP Router

♦Multi-Language Quick Installation Guide

♦User Manual CD-ROM

♦Three dipole 2dBi RSMA detachable Antennas

♦AC/DC Power Adapter

♦RJ-45 Cat.5 UTP Cable

♦Warranty Card

Note: if anything is missing, please contact your vendor

2. Hardware Installation

1. Power off your network devices.

2. Locate an optimum location for the AP. The best place for the AP is usually at the center of your

wireless network, with line of sight to all of your wireless devices.

3. Adjust the antennas. Normally, higher location of your AP may get better performance.

4. Using a standard Ethernet network cable, connect to the AP’s Ethernet port to your local network.

5. Connect the AC power adapter to the AP's Power port. Then connect the other end to an electrical

outlet. Only use the power adapter supplied with the AP. Use of a different adapter may cause

product damage.

6. The Hardware installation is completed. Please refer to the following content or user guide for AP

configuration.

Verify Hardware LED status

Verify the following LED lights are on:

Power: The Power LED lights up and will keep while the AP is powered on.

Security (orange): WPS encryption is work or not.

Wireless: When wireless is available, this led lights. When transmit or receive the data, this led is

blinking.

Router: When Router is working as "Router", this LED light

DIAG(red): When FW updating or system is abnormal, it will light

Internet: The Internet LED flashes when there is a successful Internet connection.

LAN: The LAN LED lights up when Ethernet port of AP was connected to LAN. When the LED is

flashing it indicates the network activity over that port.

3. Configure your computer’s TCP/IP Settings

Windows 2000/XP

1. Click Start; click Settings and then click on the Control Panel.

2. Double-Click the Network Connection icon.

3. Right-Click on the Local Area Connection icon and then click on Properties. The Local Area

Connection Properties windows will appear.

4. Under the General Configuration Tab, locate and select TCP/IP with the corresponding network

card, then click Properties. The Internet Protocol (TCP/IP) Properties window will appear.

5. Click on Use the following IP Address and enter

IP Address: 192.168.1.10

Subnet Mask: 255.255.255.0

Default gateway: 192.168.1.1

6. Now your computer is ready to access and configure the AP.

Windows VISTA

1. Click Start ÆControl Panel, then Network and Internet ÆManage network connections.

2. Right-Click on the Local Area Connection icon and then click on Properties. The Local Area

Connection Properties windows will appear.

3. Under the Networking Configuration Tab, locate and select Internet Protocol Version4

(TCP/IPv4) with the corresponding network card, then click Properties. The Internet Protocol

(TCP/IP) Properties window will appear.

4. Click on Use the following IP Address and enter

IP Address: 192.168.1.10

Subnet Mask: 255.255.255.0

Default gateway: 192.168.1.1

5. Now your computer is ready to access and configure the AP.

NOTE : The default IP address setting for the AP is a class C IP address (192.168.1.1 /

255.255.255.0). Please make sure that the current workstation is following the class C IP

address range, from 192.168.1.2 to 192.168.1.254

4. Configure your AP

1. Open your web browser, type http://192.168.1.1 in the Address bar, and press Enter.

2. An authentication window will appear. Enter the username and password, and then click OK.

By default, please leave blank in username and type admin in password.

3. Turn to the Wireless Section; here you may select a different channel, SSID or enable Security

if it is necessary.

4. Click “Save Settings” button to finish the Setup if you have something change. The following

screen would appear to notify you the system is rebooting. All changes will be taken effect

while reboot procedure is completed.

5. When the AP reboot procedure is completed, you may change the TCP/IP properties of this

computer. Select the “Obtain an IP address automatically” instead of “Use the following IP

Address “ item if your local network has DHCP server service to assign IP address for your

wireless client. This step will set your computer as DHCP client and get IP from your DHCP

server via AP.

If there is no DHCP server in your network, then you should assign one proper IP address

manually to fit your network IP subnet.

6. For DHCP client, using following command to check if your computer already got IP address.

zWin2000, WinXP, WinVISTA: type the “ ipconfig “ on your windows Command Prompt.

Once you got the IP address, subnet mask and default gateway, that means your computer

already connected to local network.

For detail configuration of this AP, please refer to the CD-ROM.
