NewLine RS Plus Series Gebrauchsanweisung

RS Plus Series

V2.0

Quick Start Manual

Welcome to the world of NEWLINE.

Thank you for choosing the NEWLINE RS series Interactive Touch Screen. Please use this

document to get the most out of your screen.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:(1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

NOTE 1: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

NOTE 2: Any changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

The symbol of the crossed out wheeled bin indicates this product should not be placed in

municipal waste. Instead, dispose of waste equipment by handing it over to a designated

collection point for the recycling of electrical and electronic equipment.

Symbol Conventions

Symbols are used in this document to indicate operations that need particular attention. The

symbols are defined as follows:

Provides additional information to supplement operation in the

main text.

Indicates a potentially hazardous situation that, if not avoided,

could result in equipment damage, data loss, performance

deterioration, or unanticipated results.

Indicates a hazard with risk that, if not avoided, could result in

death or injury.

WARNING

Safety Instruction

For your safety, please read the following instruction before you use the product. Serious injury or property

damage may be caused by improper operations. Do not try to repair the product on your own.

Disconnect the product from the power supply immediately if major failures occur.

Major failures include the following:

If smoke, a peculiar smell or an abnormal sound is discharged from the product.

No image or sound is displayed, or the image error occurs.

In the preceding scenarios, do not continue to use the product. Disconnect power supply

immediately and contact professional staff for troubleshooting.

Do not drop any liquids, metal or anything combustible onto the product.

If any liquid or metal are dropped onto or into the product, power off the product and

disconnect the power supply, Then contact professional staff for solutions.

Pay attention to children when they are close to the product.

Put the product on a stable surface.

An unstable surface includes, and is not limited to an inclined plane, a shaky stand, desk or

platform, that might cause the product to turnover and be damaged.

Do not open the panel or change the product on your own.

High voltage components are installed in the product. When you open the panel , high voltage,

electric shock, or other dangerous situations may occur.

If inspection, adjustment, or maintenance is required, contact the local distributor for help.

Use the provided power supply.

To prevent the product from being damaged, do not use any types of power cables other than

the one provided with the product.

Use a three-wire socket and ensure that it is properly grounded.

Pull out the power plug from the socket if the product is not used for a long period.

Clean the power plug regularly.

Fire or electric shock may be caused if the product is powered on, while you are cleaning.

Pull out the power plug before cleaning it with a dried cloth.

Power output port is 5V/2A

The voltage/current of the rear power output port is 5 V/2 A (maximum). Purchase the power

code/AC adapter according to customer needs. Please do not connect any products with different

power requirement. Otherwise, it may cause damage to products or fire.

WARNING

Do not put items on the top of the product.

Do not put items, such as a container for liquid (a vase, flowerpot, cosmetics or liquid

medicine) on the top of the product.

If any water or liquid is spilled on the product, the product may short circuit cause fire or

electric shock.

Do not walk on or hang any items on the product.

Do not install the product in an improper place.

Do not install the product in humid places, such as the bathroom, the shower room,

near windows, or outdoor environments that experience rain, snow or other harsh weather.

Avoid installation near hot spring vapor. The preceding environments may cause faults in the

product or electric shock under extreme conditions.

Do not put an exposed fire source, such as a lit candle on the product.

Pull out the power supply during thunderstorms.

Do not touch the product during a lighting storm, you may experience an electric shock.

Install or place components that supply high enough voltage to cause personal injury out of the

reach of children.

Do not touch the power cable with wet hands.

Do not install the product in high temperature environments.

Do not install the product near a heat source, such as a radiator, a heat reservoir, a stove or

other heating products.

Do not expose the product to direct sunlight, which may cause high temperatures and

subsequent faults in the product.

When transporting the product:

Pack the product for transport or maintenance by using the cartons and cushioning material

provided with the product.

Move the product vertically during transport. The screen or other components are easily

broken if the product is moved in an improper way.

Before you move the product, disconnect all external connections and separate all topple

preventing products. Move the product carefully to prevent it from being hit or squeezed,

especially the screen, which may cause injury if broken.

Do not cover or block up any vents on the product.

Any overheated components may cause fire, damage the product, and shorten the service life.

Do not lay the product down in a way where the venting surface will be covered.

WARNING

CAUTION

Do not install the product on carpet or cloth.

Do not use a cloth such as table cloth to cover the product.

Keep the product away from the radio.

The product complies with the international EMI standard to pervent radio interference.

However, interference may still exists and causes noise in the radio. If noise occurs in the radio,

try the following solutions.

Adjust the direction of the radio antenna to avoid the interference from the product.

Keep the radio away from the product.

If the screen glass is broken or falls off.

Keep all personnel 10 feet away from the screen to ensure safety.

Do not perform any installation or disassembly while the screen glass is broken or has fallen

off.

Use the battery correctly.

Galvanic corrosion, electric leakage, and even fire may be caused by improper battery usage.

It is recommended to use the designated type of battery and install the battery by the correct

electrodes (positive and negative).

Do not install and use a new battery with a used one.

Take out the battery if the remote control is not used for a long period.

Do not expose the battery to overheated environments, such as sunlight and or heat sources.

Dispose of the used battery based on your local regulations.

Do not damage the power cable.

Do not damage, change, twist, bend, or forcibly drag the power cable.

Do not put weights (such as the product itself) on the power cable.

Do not forcibly drag the cable when you pull out the power plug. If the power cable is

damaged, please contact the local distributor to repair or replace it.

The power cable in the accessory box is for this product only. Do not use it on other products.

Additional advice:

Use the product in an environment with comfortable lighting. It is harmful to your eyes

to watch in a too bright or too dark environment.

Relax your eyes watching for a period of time.

Keep sufficient distance from the product to protect your eyes and prevent eyestrain.

Adjust the volume to an appropriate level, especially at night.

Use amplifier equipment as the audio input source with caution. If you must use amplifier

equipment, the input power should not exceed the maximum of speaker power. Otherwise, the

speaker can become overpowered and damaged.

About USB port.

Front USB ports and rear USB 3.0/USB 2.0 ports switch connections based on signal sources. If

the current signal source is reading the data from an external product connecting to the port,

please switch the signal source after the data reading is complete. Otherwise, the data or product

CAUTION

may be damaged.

CAUTION

1 Parts and Functions

1.1 Parts

Front View

Rear View

65 INCH：

75 INCH/86 INCH:

Remote Control Receiver

Speakers

Power On/Off

Power Supply Plug

Light Sensor

Power Switch

Front Plate Cover

Internal PC Port (OPS)

Front Ports

Rear Ports

Front Buttons
