User Guide

User GuideUser Guide

User Guide

Software Version: 1.0

User Guide Version: 2001-Mar-02

This document contains proprietary information which is the confidential property of

NHRC LLC.

No part of this document may be used or reproduced, by any means, or for any

purpose, without the expressed written consent of NHRC LLC.

No part of this document should be considered to be specifications for the proper or

correct operation of the NHRC-10 Repeater Controller. In no way will NHRC LLC be

liable for direct or indirect damages to the controller or attached equipment.

Printed in the U.S.A.

Thank You!

Thank you for purchasing the NHRC-10 Repeater Controller. This controller has been

designed using the very latest state-of-the-art technology. Please review this manual

carefully before putting your controller into operation.

This manual represents a very large documentation effort. Your comments are

important to us. If you find an error or find any passages that are not clearly

understandable we would like to hear about it. Please send your comments to

[email protected].

Support for the controller is available by email or telephone. Please direct software-

related questions via email to softw[email protected]. Please direct hardware-related

questions via email to hardw[email protected] . Your question(s) will be answered

promptly.

Questions of a more urgent nature can be answered by telephone support. Telephone

support is available Monday through Friday, from 6 PM until 10 PM, eastern time.

Table of Contents

1. INTRODUCTION................................................................................................................................ 1

1.1 SENDING COMMANDS ..................................................................................................................... 2

1.2 ID MESSAGES ................................................................................................................................2

1.3 “UNLOCKED MODE” ...................................................................................................................... 3

2. ELECTRICAL CONNECTIONS ....................................................................................................... 4

2.1 INPUT AND OUTPUT SIGNAL LEVELS .............................................................................................. 4

2.2 DC POWER CONNECTOR ................................................................................................................ 5

2.3 REPEATER CONNECTOR ................................................................................................................. 6

2.4 LINK/REMOTE BASE CONNECTOR .................................................................................................. 7

2.5 CONTROL RECEIVER CONNECTOR.................................................................................................. 8

2.6 DELAY CONNECTORS ..................................................................................................................... 9

2.7 CI-V CONNECTOR........................................................................................................................ 10

2.8 OPTIONAL NHRC-10-DOUT EIGHT-PORT DIGITAL CONTROL OUTPUT BOARD .......................... 11

2.9 AUDIO LEVEL ADJUSTMENT......................................................................................................... 12

2.10 THE LED INDICATORS ................................................................................................................. 17

3. PROGRAMMING THE CONTROLLER....................................................................................... 18

3.1 QUICK START ............................................................................................................................... 18

3.2 INITIALIZING THE CONTROLLER.................................................................................................... 19

3.3 *0: UNLOCKED MODE CONTROL OPERATOR ACCESS .................................................................. 20

3.3.1 Set control operator switches.................................................................................................. 20

3.4 *1: SAVE SETUP ........................................................................................................................... 21

3.4.1 Save configuration setup......................................................................................................... 21

3.5 *2: PROGRAM COMMAND PREFIXES............................................................................................. 22

3.5.1 Set command prefix................................................................................................................. 23

3.6 *3: SET TIMERS ............................................................................................................................ 24

3.6.1 Program a timer...................................................................................................................... 25

3.7 *4: PROGRAM AUTOPATCH RESTRICTIONS................................................................................... 26

3.7.1 Assign an area code number to a bank................................................................................... 26

3.7.2 Set area code bank options ..................................................................................................... 27

3.7.3 Enable or disable an entire area code.................................................................................... 27

3.7.4 Enable or disable individual exchanges within an area code................................................. 28

3.7.5 Set Area Code Dialing Prefix.................................................................................................. 28

3.8 *5: PROGRAM AUTODIAL SLOTS .................................................................................................. 30

3.8.1 Program an emergency autodial number ............................................................................... 30

3.8.2 Clear an emergency autodial number..................................................................................... 30

3.8.3 Program a normal autodial number ....................................................................................... 31

3.8.4 Clear a normal autodial number ............................................................................................ 31

3.9 *6: (RESERVED FOR NHRC) ........................................................................................................ 32

3.10 *7: PROGRAM CW AND BEEP MESSAGES .................................................................................... 33

3.10.1 Program a CW ID............................................................................................................... 33

3.10.2 Program or play courtesy tones ......................................................................................... 34

3.11 *8: PLAY/RECORD VOICE TRACKS............................................................................................... 35

3.11.1 Play a message ................................................................................................................... 35

3.11.2 Record a message ............................................................................................................... 36

3.12 *9: (RESERVED FOR NHRC) ........................................................................................................ 36

3.13 **: RESET CONTROLLER .............................................................................................................. 36

4. CONTROL OPERATOR COMMANDS......................................................................................... 37

4.1 GROUP 0 SWITCHES: REPEATER CONTROL................................................................................... 38

4.2 GROUP 1 SWITCHES: MORE REPEATER CONTROL........................................................................ 39

4.3 GROUP 2 SWITCHES: VOICE ID AND TAIL MESSAGES .................................................................. 40

4.4 GROUP 3 SWITCHES: MISCELLANEOUS SETTINGS ........................................................................ 41

4.5 GROUP 4 SWITCHES: AUTOPATCH CONFIGURATION..................................................................... 43

4.6 GROUP 5 SWITCHES: LINK PORT CONFIGURATION ....................................................................... 45

4.7 GROUP 6 SWITCHES: DIGITAL OUTPUT PORT CONFIGURATION .................................................... 47

4.8 GROUP 7 SWITCHES: DIGITAL OUTPUT PORT CONTROL ............................................................... 48

4.9 GROUP 8 SWITCHES: PROGRAMMING WRITE PROTECT ................................................................ 49

4.10 GROUP 9 SWITCHES: CONTROL OPERATOR GROUP ACCESS ........................................................ 50

5. USER COMMANDS.......................................................................................................................... 51

5.1 AUTOPATCH ................................................................................................................................. 51

5.2 UNRESTRICTED AUTOPATCH ........................................................................................................ 52

5.3 AUTODIAL .................................................................................................................................... 53

5.4 EMERGENCY AUTODIAL ............................................................................................................... 54

5.5 PATCH HANG UP CODE ................................................................................................................ 54

5.6 DTMF ACCESS ............................................................................................................................ 55

5.7 RE-TRANSMIT DTMF................................................................................................................... 56

5.8 DTMF PAD TEST ......................................................................................................................... 57

5.9 REVERSE PATCH .......................................................................................................................... 58

5.10 AUDIO CHECK .............................................................................................................................. 59

5.11 VOICE MAILBOX .......................................................................................................................... 60

5.11.1 Play the voice mailbox headers .......................................................................................... 60

5.11.2 Play a specific message ...................................................................................................... 60

5.11.3 Record a message ............................................................................................................... 61

5.11.4 Delete the last message played........................................................................................... 61

5.11.5 Perform an audio check...................................................................................................... 61

5.12 REMOTE BASE.............................................................................................................................. 63

5.12.1 Select remote base operating mode .................................................................................... 63

5.12.2 Set or check transceiver mode ............................................................................................ 64

5.12.3 Set or check transceiver frequency ..................................................................................... 64

5.12.4 Select transceiver memory or VFO mode ........................................................................... 65

5.12.5 Select a transceiver memory channel ................................................................................. 65

5.12.6 Select transceiver split frequency operation....................................................................... 66

5.12.7 DTMF adjustment of operating frequency.......................................................................... 67

5.13 LOAD SAVED SETUP..................................................................................................................... 68

5.14 LITZ............................................................................................................................................. 69

6. APPENDICES .................................................................................................................................... 70

6.1 FACTORY DEFAULTS .................................................................................................................... 70

6.1.1 Default command prefixes table.............................................................................................. 70

6.1.2 Timer defaults table ................................................................................................................ 71

6.1.3 Courtesy tone component tones table ..................................................................................... 72

6.1.4 CW (“morse code”) character table ....................................................................................... 73

6.2 CONTROL OPERATOR CONTROLS ................................................................................................. 74

6.2.1 Control operator group 0 (repeater control) operations table ............................................... 74

6.2.2 Control operator group 1 (repeater control II) operations table............................................ 74

6.2.3 Control operator group 2 (voice and tail ID messages) operations table .............................. 75

6.2.4 Control operator group 3 (miscellaneous settings) operations table...................................... 75

6.2.5 Control operator group 4 (autopatch configuration) operations table .................................. 76

6.2.6 Control operator group 5 (link port configuration) operations table..................................... 76

6.2.7 Control operator group 6 (digital output port configuration) operations table ..................... 77

6.2.8 Control operator group 7 ( digital output port control) operations table .............................. 77

6.2.9 Control operator group 8 (programming write protect) operations table.............................. 78

6.2.10 Control operator group 9 (control operator group access) operations table .................... 78

6.3 SPEECH VOCABULARY TABLE...................................................................................................... 79

7. TERMINOLOGY AND ABBREVIATIONS................................................................................... 81

8. CIRCUIT BOARD ............................................................................................................................. 83

8.1 INTERCONNECTIONS..................................................................................................................... 83

9. SCHEMATICS................................................................................................................................... 85

10. PARTS LIST .................................................................................................................................. 91

11. NHRC LLC LIMITED WARRANTY ......................................................................................... 96

NHRC-10 User Guide

1. Introduction

The NHRC-10 Repeater Controller represents the current state-of-the-art in repeater

controller designs. It utilizes the latest available technology to provide maximum

functionality with the lowest number of parts. This results in very reliable operation.

The key features of the NHRC-10 are:

• Recording of four real speech ID messages and three real speech tail messages

yourself.

• Local language support using a custom recording capability.

• Six voice mailboxes, five saved operational setup memories, ten timers, and more

than 70 control operator functions.

• An audio test mode that records and plays back user's audio.

• A full-duplex autopatch with a database of 100 autodial numbers plus ten emergency

autodial slots.

• Support for up to four area codes with grant/deny access control to each exchange.

• Land line telephone access for "Reverse Patch" & controller administration.

• DTMF (“Touch Tone”) pad test.

• Dedicated DTMF receiver for telephone control and optional control receiver. (A

separate control receiver audio input with dedicated DTMF receiver is available.)

• Separate control receiver jack and DTMF receiver. DTMF receiver reverts to link

port when control receiver is not present.

• Connections for remote base, link radio, or slave repeater.

• Unique courtesy tones to indicate link/remote base status.

• Frequency-agile remote base supports remote control of ICOM IC-706MkIIG.

• LiTZ (Long Tone Zero)/911 message support; will play dedicated voice message in

response to LiTZ or 911 tones to tell user how to use emergency autodials, what

other repeater to use, etc.

• Transmitter fan control output automatically runs fan while transmitting and for a

programmable delay after.

• Real sine wave audio tones.

• DTMF "Carrier,” “Carrier and CTCSS,” and “Carrier or CTCSS" access modes.

• Granular security features that allow tailored control operator access.

NHRC-10 User Guide

1.1 Sending commands

All of the controller’s commands are sent by DTMF (Touch-Tone) sequences that can

be received on the main repeater, over the telephone, the control receiver (if connected),

or the link radio (if the control receiver is not connected).

Commands received over the main repeater or link radio will be evaluated, and if correct,

executed, when either the DTMF inter-digit timer expires (2.0 seconds) or the CAS

(receiver unsquelched) signal drops; whichever comes first. This allows the controller to

be commanded even when a weak on-channel signal is holding the receiver’s squelch

open.

The telephone and control receiver do not have a CAS signal available. Commands

received from these sources will be evaluated when the DTMF inter-digit timer expires.

To send a command over the main repeater,

1. key your transmitter.

2. enter the DTMF command digits.

3. unkey the transmitter.

This will cause the command to be evaluated immediately.

If you pause for more than 2.0 seconds while sending a command, the command you

entered prior to the pause will be evaluated, the command buffer will be emptied, and

you can immediately enter another command.

When a command is successfully evaluated, the controller will send a response. Each

command’s possible responses are detailed with the command description.

In general, if you do not receive a command response, then the controller did not accept

your command.

1.2 ID Messages

The controller supports four voice ID messages and one CW ID.

The voice messages are comprised of:

• an “initial” ID message, that plays when the controller has been idle for a period

longer than the ID timer, and

• three “normal” ID messages.

Each of the normal ID messages can be individually enabled or disabled.

When more than one normal ID message is enabled, the enabled messages are played in

sequence; one each time the ID timer expires.

The CW ID will play when all the voice IDs are disabled, or when the repeater is keyed

during a voice ID message.

NHRC-10 User Guide

1.3 “Unlocked Mode”

All of the controller’s important programming information is protected by a special

password, the “unlock code.”

Programming the unlock code requires physical access to the controller to place a jumper

on the circuit board.

The unlock code cannot be re-programmed without physical access to the controller.

When the unlock code is successfully entered into the controller, the controller will say

“control access enabled,” and a special courtesy tone will be used to indicate the

controller is unlocked.

The controller can be locked by:

• sending the “#” command, or

• it will lock itself after two minutes of inactivity.

When the controller leaves the unlocked mode:

• it will say “control access disabled,” and

• the courtesy tone will revert to the normal tone for the controller’s current state.

NHRC-10 User Guide

2. Electrical Connections

This section of the User Guide describes the electrical interfaces used to connect the

controller to:

• power,

• repeater and link radios,

• the control receiver, and

• NHRC-DAD digital audio delay boards.

It is intended for the repeater operator to use in the planning and installation of the NHRC-

10 Repeater Controller into a repeater system.

2.1 Input and Output Signal Levels

Control signals into the NHRC-10 are active-high signals. The repeater activity inputs

(CAS and CTCSS Decode) are buffered in the controller to allow the connection of

popular radios to the controller. Signal levels should be 0.0 to 0.5 volts for off, and 2.0

to 16.0 volts for on.

The controller’s PTT and FAN CONTROL outputs are “open-drain” connections to

power MOSFETs. These outputs are active-low, and when activated, will pull the

control signals to within a few ohms of ground. These outputs can sink 100 mA or so.

NHRC recommends that diodes be used to protect the MOSFETs from back-EMF if

these signals are used to drive relays.

Audio signals into the controller should be in the range of 0.2 to 2.0 volts peak-to-peak.

The controller’s transmit audio outputs are adjustable from about 0.1 volt to about 5

volts peak-to-peak.

The optional NHRC-10_DOUT digital output board provides eight additional digital

outputs. These outputs are “open-drain” connections to power MOSFETs. These

outputs are active-low, and when activated, will pull the control signals to within a few

ohms of ground. These outputs can sink 100 mA or so. NHRC recommends that diodes

be used to protect the MOSFETs from back-EMF if these signals are used to drive relays.

Inhaltsverzeichnis

Andere NHRC Controller Handbücher

NHRC

NHRC NHRC-2 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
