NHT SuperPower Bedienungsanleitung

SuperPower

90 Watt Powered Speaker

Setup Guide

NHT's SuperPower 90 watt powered speaker

represents our best efforts to date in active

loudspeakerdesign.

Use this Setup Guide to help you unpack,

connect and place them your new SuperPower

speaker. Ifyouareinterestedinmoreinformation

abouttheseand other NHTspeakers,pleasevisit

our website at , you will find

completeowner'smanualsandothertipstomake

the most of your installation. If at any time during

or after setup you require personal assistance,

feel free to call our Customer Hotline at 1-800-

NHT-9993(800-648-9993).

www.nhthifi.com

Satisfaction and Warranty

We hope you enjoy the sound of your NHT

Classic speakers as much as we do. Warranty

terms and conditions and service procedures

varies by country of purchase. For USA and

Canadian customers (and any worldwide

customers who make their purchase from the

NHT Web Store) please refer to the NHT website

forwarrantydetailsandserviceprocedure. Ifyou

bought from an NHT Authorized Dealer in North

America, think about registering your purchase

(and warranty) with us - not necessary for

customers who purchase directly from the NHT

Web Store. For other countries, please refer to

the dealer and distributor in your country for

warranty terms, warranty registration and service

needs–youcanfindthematwww.nhthifi.com.

Once again, if you have any questions or

problems,pleasecall usatour ConsumerHotline

-800-NHT-9993,or[email protected].

Parts List

Connections

Connection method 1

Here are some additional items you receive with

yourspeaker:

ThisSetupguide

IECPowercord

1/8”StereominitoRCA‘Y’jack.

(4)Rubberbump-ons

Here are four of the most common connection

methodsyoumightencounter.

Simple line out from a computer, Mp3 player

phone,,etc.

Cordsneeded:1/8”StereotoRCA(supplied)

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Source

1/8”

Line Out

Headphone

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Computer

Mp3 Player

Phone

1/8” Stereo

to RCA (supplied)

Connection method 2a

Lineoutfromacomputer,Mp3player,phone,etc.

UsinganNHTPVCpassivevolumecontrol.

WithSubwoofer.

Connection method 2b

Lineoutfromacomputer,Mp3player,phone,etc.

Same as above but without the PVC passive

volumecontrol.WithSubwoofer.

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Source

1/8” Stereo

Output Jack

RCA to RCA

Powered

Subwoofer

Powered

Subwoofer

1/8” mono to RCA

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Computer

Mp3 Player

Phone

RCA to RCA

1/8” Stereo

to RCA (supplied)

Cordsneeded:

1/8”StereotoRCA(supplied),

(2) RCA cables, 1/8” mono to RCA cable (for

subwoofer)

Cordsneeded:

1/8”StereotoRCA(supplied),

(2) Y-Adapter: RCA to RCA (pair), (2) RCA

coupler.

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Source

1/8”

Line Out

Headphone

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

Computer

1/8” Stereo

to RCA (supplied)

Y-Adaptor:

RCA to RCA (pair)

RCA Coupler

Y-Adaptor:

RCA to RCA (pair)

Connection method 3

LineoutfromaStereoPreamp

Cordsneeded:

(2)RCAcables(3ifyouuseasubwoofer)

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA RCA to RCA Cable

Pre /

Main

Out

Sub

Out

Optional:

Powered

Subwoofer

100 ~120V 60Hz 1.2A

Designed and Engineered

in California by NHT

Components mfg. in China

SuperPower

Assembled in the USA

RCA to RCA Cable

Stereo

Preamp
