NIIMBOT B1 Bedienungsanleitung
Sma Label Printer
Quick Sta Guide
NIIMBOT B1
NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentication Technology Ltd.
© 2022 NIIMBOT. All rights reseed.
Suppo Email : se[email protected]
Ocial Website : www.niimbot.com
Wuhan Jingchen Intelligent ldenticationTechnology Co., Ltd.
Production Address : No. 1, Tianyang Road, Chuanlong Avenue, Hengdian
Street, Huangpi District, Wuhan City, Hubei Province, China
Sma Label Printer *1
USB Type-C Cable *1 Quick Guide *1
Label Paper Roll *1
Package Contents
01
01 · 02
EN
Danger! Beware of shape blade when the paper compament is open.
Press the Open Slide on the left to open the paper compament.
1
Push the paper compament bae to the sides and t the
label paper into the paper compament with the print side
facing down.
2
Open Slide
Print Side
Tear-o Blade
Paper Compament Bae
Fit the label paper into the compament
with the print side facing down.
Installation
02
EN
Slide the paper compament bae inwards to secure the
label paper, pull the rst paper out, make sure it sticks out
of the paper exit.
3
Close the paper compament and long-press the Power
Button to turn the printer on.
4
Paper Exit
Power Button
Indicator Light
EN
03 · 04
EN
Installing App
03
Before using the printer, please install the NIIMBOT app from
Google Play or the App Store.
1
Get the NIIM app for more label designs for homes.
2
Design & Print APP
easy to download and use
NIIM
Design & Print APP
easy to download and use
NIIMBOT
More information available on the NIIMBOT app.
Sign in to NIIMBOT Help Center HardwareMe
EN
Connecting and Printing
04
05 · 06
After connecting, tap on "Current label template" on the
Home tab to enter the label editor.
3
On Home, tap Connect sma label printer. Then select device
model.
2
Notice: If a PIN code is required, input 0000 or 1234.
Images of products, accessories, and the app in this manual are
for illustrative purposes only and may be dierent from actual
products. Products are subject to change without prior notice.
Special Notes
8:30
NIIMBOT Turn on Bluetooth
Open NIIMBOT app and turn on Bluetooth on your phone.
1
Function Operation
Switch on
Switch o
Print histo
Hold down the Power button for three seconds.
Hold down the Power button for three seconds when
the device is on.
Press the Power button once when the device is on.
Print a test page Double-press the Power button when the device is on.
EN
Basic Functions
05
Indicator
Blue
Blue
Green
Green
Blinking
Solid
Blinking
Blinking
Solid
Solid
Status
Hardware upgrading
Standby
Printing
Bluetooth connected
Description
Red
Red
Charging
Paper compament open/
Out of paper/Paper exit error
EN
LED Indicators
06
07 · 08
Product Label Printer Model NIIMBOT B1
Dimensions 132*91.2*61.6mm Weight 293g
Charging Time 3.5 - 4 hours Input
Batte Capacity 1500mAh Thermal printing
5V DC, 1A
Printing Method
Printing
Resolution Printing Width
Connectivity Charge
Transmit Power Operating
Temperature
203dpi 20-48mm
Bluetooth、Type-C USB Type-C
4dBm(Maximum) 5~40℃
EN
Specications
07
Don't disassemble the product
without authorization.
Disassembled products cannot
be returned or exchanged.
Do not wipe the product with
corrosive chemicals or cleaning
agents.
Do not use the product
near places with ammable
products such as gas stations
or fuel depots.
Please read all the instructions and warnings in this manual carefully
before using this product to ensure the proper functioning of the
device and your safety.
Please keep the product and accessories out of the reach of children or
they must be used under the supeision and guidance of a guardian;
Turn o the power immediately when water gets into the product;
Turn o the power immediately in case of any product malfunction;
If you want to use a power adapter, always use one that is safe,
regulato-compliant, and compatible;
Do not disassemble the product to replace the batte. Improper operation
may cause an explosion;
1.
2.
3.
4.
5.
*Warnings
EN
Safety Precautions
08
