Niles AT8 Bedienungsanleitung

AT8

IN-WALL LOUDSPEAKER

• Tweeter can be rotated and pivoted

•Baffle-mounted bass and treble tone controls for

acoustical adjustments

8" 2-Way AT Advanced Technology

In-wall Loudspeaker

SPECIFICATIONS SHEET

IN-WALL LOUDSPEAKER

WOOFER TECHNOLOGY

■8" Interlaced glass and carbon-fiber cone is extremely rigid to reduce breakup and lower distortion

even under high power

■Butyl rubber cone surround damps resonance and provides

exceptional durability

■High BL magnet structure with vented pole piece insures powerful

bass response

■Dispersion stabilizer distributes midrange tones for clear off-axis sound

TWEETER TECHNOLOGY

■Proprietary tweeter-adjustment mechanism ratchets in 1mm increments and then pivots for precise

aiming of high frequencies

■1" Tri-laminate Teteron dome with fluid-cooling and ultra-wide dispersion for clear and detailed

high-frequencies

AUDIOPHILE FEATURES

■Premium crossover components provide seamless driver integration and smooth sound

■Anti-resonant wave-bracing ABS baffle eliminates unwanted resonance to keep bass tones rich

and dynamic

TONE CONTROLS

■Baffle mounted bass and treble controls allow easy access to adjust the sound in any room

INSTALLATION

■Patented snap-in speaker baffle mounting mechanism facilitates quick installations and upgrades

■100% rustproof MicroPerf™ aluminum grille conceals loudspeaker elements yet allows full

frequency sound through. Grille can be painted to match décor

■Infrared sensor knockout provides a hidden remote control solution

SPECIFICATIONS

■Impedance: 6 ohms

■Recommended amplifier power: 10W to 150W

■Frequency response: 40Hz-21kHz +/-3dB

■Sensitivity: 90dB for 2.83V pink noise

■Frame dimensions: 10-3/16" x 14-1/4"

■Hole cutout dimension: 9-1/8" x 13-1/8"

■Depth behind wall: 3-5/8" deep (assumes 1/2" drywall)

Warranty: Five-year limited

Shipping weight: 14 lbs.

AT8

Stock Number

FG00891

8" In-Wall Loudspeaker

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8PDF

IN-WALL LOUDSPEAKER

Technology

PIVOTING RATCHETING TWEETER

Enable installers to precisely adjust the angle of the tweeter for optimum coverage

ADVANCED MATERIAL SCIENCE

Elevates performance of sub component parts like woofer cones, tweeter diaphragms and crossover components

SOPHISTICATED MOTOR AND MAGNETIC DESIGN

Including High BL magnets and vented pole pieces for deep bass response

ACOUSTIC FINE TUNING

Bass and treble controls optimize system sound for every acoustical environment

ANTI-RESONANT WAVE-BRACING TECHNOLOGY

Prevents transmission of woofer vibrations to the baffle and into the drywall for clear and dynamic bass response

Details

HOME THEATER SPECIFIC MODELS

Deliver voice-matched cinema performance and are compatible with all AT Advanced Technology models

SNAP-IN SPEAKER-BAFFLES

Greatly reduces installation time and cost

MODULAR MOUNTING SYSTEM

Uses innovative mounting technique to simplify installation and ensure uniform contact with wall

BLACK BAFFLES

Deliver a seamless appearance after the speakers are installed and the grilles are in place

MICROPERF™ RUSTPROOF ALUMINUM GRILLES

Are acoustically transparent yet won’t rust or discolor

DEBRIS SCREENS

Block unwanted debris such as fiberglass insulation, sheetrock chips, or other foreign matter from coming in contact with the woofer cone

OPTIONAL FIRE-RATED METAL ENCLOSURES

Optimize performance and ensure code compliance

OPTIONAL NEW CONSTRUCTION BRACKETS

Secure loudspeaker’s location and simplify installation

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8PDF
