Niles AT8500 Bedienungsanleitung

AT8500

IN-WALL LOUDSPEAKER

• Dual midrange and tweeter array can be rotated and pivoted

•Baffle-mounted bass, midrange and treble tone controls for acoustical adjustments

8" 3-Way AT Advanced Technology

In-wall Loudspeaker

SPECIFICATIONS SHEET

IN-WALL LOUDSPEAKER

WOOFER TECHNOLOGY

■8" Aluminum/urethane cone is extremely rigid to reduce breakup and lower distortion even under

high power

■Butyl rubber cone surround damps resonance and provides exceptional durability

■Sophisticated motor assembly including high BL magnet, extended pole piece, high temperature

aluminum voice coil former and machined top plate for deep bass response and clean bass tones

■Cast aluminum frame and basket secures drive components to prevent distortion and unwanted

harmonics

■Inverted dust cap for added rigidity and wide mid-bass dispersion

MIDRANGE TECHNOLOGY

■Dual 1-1/2" aluminum/urethane hyperbolic dome midrange drivers reproduce critical midrange

sounds with exceptional accuracy

■NDFE 35 neodymium, high BL magnet motor structures enable compact driver construction

■Midrange drivers are housed in a 360° rotating, 30° pivoting DSFG® adjustable array allows

installer to control dispersion patterns for optimal response

TWEETER TECHNOLOGY

■1" fluid-cooled aluminum/urethane hyperbolic dome tweeter reproduces high frequencies and their

harmonics with crystal clear accuracy

■Tweeter is housed in a 360° rotating, 30° pivoting DSFG® adjustable dispersion array allows

installer to control dispersion patterns for optimal response

AUDIOPHILE FEATURES

■Linkwitz-Riley filters with premium crossover components provides seamless driver integration

■Low diffraction, X-Matrix™ reinforced polycarbonate Baffle eliminates unwanted resonance

TONE CONTROLS

■4 increment (-2dB, Flat, +2dB, +4dB) bass, midrange and treble controls adjust from the front

baffle for fine tuning after installation

INSTALLATION

■100% rustproof MicroPerf™ aluminum grille conceals loudspeaker elements yet allows full

frequency sound through. Grille can be painted to match décor

■Moisture and UV resistant materials including all stainless steel and brass hardware stand up to

harsh environments

■Infrared sensor knockout provides a hidden remote control solution

SPECIFICATIONS

■Impedance: 8 ohms (4 ohms minimum)

■Recommended amplifier power: 20W to 200W

■Frequency response: 30Hz-21kHz +/-3dB

■Sensitivity: 89dB for 2.83 pink noise, measured at 1 meter on axis

■Frame dimensions: 11” x 18-3/8”

■Hole cutout dimension: 9-3/4” x 17-1/4”

■Depth behind ceiling: 3-3/4" deep (based on 1/2" drywall)

Warranty: Five-year limited

Shipping weight: 11 lbs.

AT8500

Stock Number

FG00743

8" In-Wall Loudspeaker

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8500PDF

IN-WALL LOUDSPEAKER

Details

HOME THEATER SPECIFIC MODELS

Deliver voice-matched cinema performance and are compatible with all AT High Definition models

MODULAR MOUNTING SYSTEM

Uses innovative mounting technique to simplify installation and ensure uniform contact with wall

BLACK BAFFLES

Deliver a seamless appearance after the speakers are installed and the grilles are in place

MICROPERF™ RUSTPROOF ALUMINUM GRILLES

Are acoustically transparent yet won’t rust or discolor

DEBRIS SCREENS

Block unwanted debris such as fiberglass insulation, sheetrock chips, or other foreign matter from coming in contact with the woofer cone

REQUIRES USE OF BRACKET KIT

Use AT8000 bracket kit - FG00746

REQUIRES USE OF FRAME AND GRILLE KIT

Use AT8000 frame and grille kit - FG00745

Technology

DIRECTED SOUND FIELD GEOMETRY MIDWAY AND TWEETER ARRAY

Directs the flattest frequency response 15° off axis from the tweeter

ROTATING AND PIVOTING MIDRANGE AND TWEETER ARRAY

Enable installers to control dispersion patterns for optimal response and placement flexibility

ADVANCED MATERIAL SCIENCE

Elevates performance of sub component parts like woofer cones, tweeter diaphragms and crossover components

SOPHISTICATED MOTOR AND MAGNETIC DESIGN

Including high BL magnets, Bi-filer voice coils, extended pole pieces, sophisticated audiophile crossover design, Linkwitz-Riley filters and

premium components allow drivers to deliver seamless sound

ACOUSTIC FINE TUNING

Bass, midrange and treble controls optimize system sound for every acoustical environment

ANTI-RESONANT WAVE-BRACING TECHNOLOGY

Prevents transmission of woofer vibrations to the baffle and into the drywall for clear and dynamic bass response

NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAAT8500PDF
