SPECIFICATIONS SHEET
AC-3
AUTOMATED SWITCHING SYSTEM
• Automate power turn-on and turn-off of an A/V component or system
• Individually boxed
•Voltage-Triggered
Voltage-Triggered AC Power Strip
AUTOMATED SWITCHING SYSTEMS
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.259.4434 – www.nilesaudio.com NAAC3PDF
FEATURES
■Three AC outlets—two switched, one unswitched; 1,500W maximum (all outlets combined)
■AC-3 is activated by 12Volt DC signal (100mA minimum)
■Requires 12Volt DC adapter to trigger AC-3 from the switched outlet of a receiver or preamp,
can also be triggered by the 12volt output of a Niles APC-2, AC-3, SPK-1, SAS-1 or RFS-1
■12Volt control output for activating other Niles devices such as an APC-2, AC-3, SPK-1,
SAS-1 or RFS-1
SPECIFICATIONS
■Dimensions: 5-1/4" wide x 2-1/4" high x 4-1/4" deep
Warranty: Two-year limited
120Volt AC Power Switching System
AC-3
Stock Number
FG00242
Product Detail
Using the AC-3 to increase the wattage capacity of a switched outlet to 1500 watts.
IN OUT
+ – + –
LR
AC-3
PREAMP
AMP 1
AC CORD
SWITCHED
UNSWITCHED
AC CORD
WALL
OUTLET
15 AMP
LR
AMP 2
AC CORD
12V DC
OUT
PLUG INTO
SWITCHED OUTLET
(NOT INCLUDED)
