NimbeLink Skywire NL-SWDK Bedienungsanleitung

Skywire® Development Kit

User Manual

NimbeLink Corp

Updated: August 2019



Table of Contents

Introduction 4
Orderable Part Numbers 4
Product Overview 5
Block Diagram 5
Connect to Kit using a PC 6
Unpack Kit Contents 6
Skywire Placement 7
Attach Antenna to Baseboard 8
Short Jumper J6 8
Attach Jumper Wires (NL-SW-LTE-WM14 only) 9
Plug in 12V Power Supply to connector J15 9
Plug USB cable into connector J14 and PC 9
Power On the Modem 10
Open Terminal Emulator 11
Install FTDI driver (Windows) 11
Test Serial Communication 12
Test Signal Strength 13
For Non-LTE Modems 13
Note: Bit Error Rate only available during active data connections. 13
For LTE Modems 13
For the following product models (NL-SW-LTE-GELS3, NL-SW-LTE-TC4NAG,
NL-SW-LTE-TC4EU): 15
Activate Modem (one-time step) 16
SIM Card Detection (GSM Only) 17
Send Modem Activation String (1xRTT and EVDO only) 17
Setup PDP Context 18
NL-SW-GPRS, -HSPA, -TNAG, -TEUG, -TC4EU, -TC4NAG (AT&T Firmware)
APN Configuration: 18
NL-SW-LTE-TC4NAG (Verizon Firmware) APN Configuration 19
NL-SW-LTE-TSVG APN Configuration 20
NL-SW-LTE-GELS3 APN Configuration 21
NL-SW-LTE-WM14 APN Configuration: 22
NL-SW-LTE-QBG96 APN Configuration: 22

PN 30005 rev 23 © NimbeLink Corp. 2019. All rights reserved. 2


Check Network Registration 23
2G/3G Network Registration 23
LTE Modem Network Registration 24
NL-SW-LTE-GELS3 24
NL-SW-LTE-WM14 25
NL-SW-LTE-QBG96 25
APN Setup 26
Overview 26
Common APNs and Their Respective Carriers 26
Common Next Steps 26




PN 30005 rev 23 © NimbeLink Corp. 2019. All rights reserved. 3

1. Introduction

1.1. Orderable Part Numbers

Orderable Device

Description

Carrier

Network

Type

NL-SWDK

Skywire Development Kit

Any

NL-SW-1xRTT-A

2G 1xRTT

Aeris

CDMA

NL-SW-1xRTT-S

2G 1xRTT

Sprint

CDMA

NL-SW-1xRTT-V

2G 1xRTT

Verizon

CDMA

NL-SW-GPRS

2G GPRS

Any GSM (AT&T,

T-Mobile, etc.)

GSM

NL-SW-EVDO-A

3G EVDO, GPS, GLONASS

Aeris

CDMA

NL-SW-EVDO-V

3G EVDO, GPS, GLONASS

Verizon

CDMA

NL-SW-HSPA

3G HSPA+, GNSS, GLOBAL BANDS

Any HSPA/GSM

Carrier (AT&T,

T-Mobile, etc.)

HSPA/GSM

NL-SW-HSPA-B

3G HSPA+, GNSS, GLOBAL BANDS

Any HSPA/GSM

Carrier (AT&T,

T-Mobile, etc.)

HSPA/GSM

NL-SW-LTE-TSVG-B

LTE without Fallback, GNSS

Verizon

LTE

NL-SW-LTE-TNAG-B

LTE with HSPA+ Fallback, GNSS

Any GSM Carrier

(AT&T, T-Mobile,

etc.)

LTE/GSM

NL-SW-LTE-TEUG

LTE with HSPA+ Fallback, GNSS, EU

Any EU LTE/GSM

Carrier

LTE/GSM

NL-SW-LTE-GELS3-C

LTE CAT1, Verizon

Verizon

LTE

NL-SW-LTE-GELS3-D

LTE CAT1, Verizon

Verizon

LTE

NL-SW-LTE-WM14-B

LTE CAT1, GSM

Any LTE Carrier

(AT&T, T-Mobile,

etc).

LTE

NL-SW-LTE-QBG96

LTE CAT M1, GNSS

AT&T, Orange,

Telstra, Telus,

T-Mobile,

Verizon,

Vodafone, and

LTE

NL-SW-LTE-TC4EU

LTE Cat4, EU

EU Carriers

LTE

NL-SW-LTE-TC4NAG

LTE Cat 4

AT&T, Verizon

LTE

1.2. Product Overview

The Skywire® Development Kit includes one baseboard, antenna, power supply, SIM

cards, and debug cables. Skywire modems must be purchased separately. The kit

enables you to develop your application directly on the Skywire modem with three

different ways to connect:

● Connect your PC to the Skywire modem UART port via onboard USB-to-UART

converter and send AT commands directly to the modem through PC terminal

applications. You can also connect over USB for access to multiple COM ports.

● The kit is an Arduino shield, so you can plug the kit directly onto an Arduino

microcontroller. Please see Section 4: Common Next Steps for links to example

documentation.

● To connect the kit to a different processor or development kit, a 14-pin header

breaks out the necessary signals for easy connection to any device. The modem

supports I/O levels from 1.65-5.5V, simplifying connection to other systems.

1.3. Block Diagram

*X2 and X3 U.FL connectors not present on all modems.

2. Connect to Kit using a PC

This section covers how to connect your development kit to a PC and provision

the modem with your cellular plan. It also covers how to communicate over the

serial port to the Skywire modem which only requires the use of USB port and

connector marked J14 or USB2 in the diagram below. USB1 (connector J5) is

used for high speed data connections and firmware updates to the modem and is

not used in this section.

2.1. Unpack Kit Contents

2.2. Skywire Placement

To mount your Skywire Cellular modem follow these steps:

1. Gather the following:

a. Skywire Development Kit board

b. Skywire Cellular Modem

c. U.FL extractor tool (Always use a U.FL extractor tool when placing or

removing U.FL cables on the Skywire modem to avoid damaging the U.FL

connectors).

2. Line up your Skywire’s cellular U.FL connector(s) on the side of the board closest

to the antenna connector. Depending on the type of Skywire Modem you have

there may be one, two, or three U.FL connections.

3. To avoid damage to the U.FL connector and maximize connector life, a U.FL

removal tool should be used when attaching/removing the U.FL connector.

Always insert and remove the U.FL connector with a force perpendicular to the

board. If your Skywire is using GPS, attach the GPS antenna to the bottom of the

Skywire connector X3. If you are not using your Skywire’s GPS or if your Skywire

does not support GPS, continue to step 4.

4. Attach the U.FL cable to the top U.FL connector X1 on the Skywire. If you are

using a Skywire with the cellular diversity antenna option attach a second

antenna to connector X2.

5. Carefully seat your Skywire into the board’s Skywire socket (U1). Take care to

ensure that the pins are correctly aligned. Failure to properly align the pins may

damage your Skywire.

A properly mounted SkywireTM Modem with U.FL cable attached to top U.FL

connector X1.

A common issue is accidentally inserting the modem with pins

misaligned by one row. Check pin alignment BEFORE applying

power to prevent modem damage.

2.3. Attach Antenna to Baseboard

Antenna screws onto SMA connector with a clockwise rotation

2.4. Short Jumper J6

Ensure header J6 is shorted with 2 pin Jumper. This enables USB to UART

communication between the PC and the modem.

2.5. Attach Jumper Wires (NL-SW-LTE-WM14

only)

To power on the NL-SW-LTE-WM14 modem, you must tie the SW_ON_OFF pin

to GND. Place a jumper wire to connect header J8 Pins 2 and 8 together.

Please see page 3 of the Skywire Development Kit schematic for pin locations:

http://nimbelink.com/Documentation/Development_Kits/NL-SWDK/20002_NL-S

WDK_Schematic.pdf

2.6. Plug in 12V Power Supply to connector J15

2.7. Plug USB cable into connector J14 and PC

2.8. Power On the Modem

Press and hold button S1 to power on the modem. Please see the table below for

the length of time needed to hold down button S1 for your particular modem.

Device

Hold Time (th) for Button

S1 To Power On the

Modem

Wait Time (tw) Before

Software Communication*

LED D1 Activity

NL-SW-1xRTT-A

1 second <  th < 2 seconds

tw > 10 seconds

Blink once

NL-SW-1xRTT-S

1 second <  th < 2 seconds

tw > 10 seconds

Blink once

NL-SW-1xRTT-V

1 second <  th < 2 seconds

tw > 10 seconds

Blink once

NL-SW-GPRS

th > 5 seconds

tw > 10 second

Blink once

NL-SW-EVDO-A

1 second <  th < 2 seconds

tw > 10 seconds

Blink twice

NL-SW-EVDO-V

1 second <  th < 2 seconds

tw > 10 seconds

Blink twice

NL-SW-HSPA

th > 5 seconds

tw > 2 seconds

Solid on

NL-SW-HSPA-B

th > 5 seconds

tw > 2 seconds

Solid on

NL-SW-LTE-TSVG

1 second <  th < 2 seconds

tw > 15 seconds

No activity

NL-SW-LTE-TNAG

1 second <  th < 2 seconds

tw > 15 seconds

No activity

NL-SW-LTE-TEUG

1 second <  th < 2 seconds

tw > 15 seconds

No activity

NL-SW-LTE-GELS3

1 second <  th < 2 seconds

tw > 30 seconds

Solid on

NL-SW-LTE-WM14

n/a (Done in Section 2.5)

tw > 30 seconds

Solid on

NL-SW-LTE-QBG96

th > 1 second

tw > 4 seconds

Solid on

NL-SW-LTE-TC4EU

th > 5 second

tw > 5 seconds

Solid on

NL-SW-LTE-TC4NAG

th > 1 second

tw > 5 seconds

Solid on

Note: Depending on your modem and depending on the setup, the modem may be available for use before tw.
