5
behind and 30cm above. Inadequate ventilation can
result in overheating, possibly causing damage to the
device(s), or even fire.
• Do not use the speaker’s handles for suspended installation.
Doing so can result in damage or injury.
• Do no expose the device to excessive dust or vibrations,
or extreme cold or heat (such as in direct sunlight, near a
heater, or in a car during the day) to prevent the possibility
of panel disfiguration or damage to the internal
components.
• Do not place the device in an unstable position where it
might accidentally fall over.
CONNECTIONS
• Before connecting the device to other devices, turn of the
power for all devices. Before turning the power on or off
for all devices, set all volume levels to minimum.
CAUTION
• When turning on the AC power in your audio system,
always turn on the device LAST, to avoid speaker damage.
When turning the power off, the device should be turned
off FIRST for the same reason.
• Do not insert your fingers or hands in any gaps or
openings on the device (ports, etc.).
• Avoid inserting or dropping foreign objects (paper, plastic,
metal, etc.) into any gaps or openings on the device
(ports, etc.) If this happens, turn off the power immediately
and unplug the power cord from the AC outlet. Then
have the device inspected by qualified Nissindo service
personnel.
• Do not use the device for a long period of time at a high
or uncomfortable volume level, since this can cause
permanent hearing loss. If you experience any hearing
loss or ringing in the ears, consult a physician.
• Do not operate the device if the sound is distorting.
Prolonged use in this condition could cause overheating
and result in fire.
• Do not rest your weight on the device or place heavy
objects on it, and avoid use excessive force on the buttons,
switches or connectors.
GETTING STARTED
WIRING
IMPORTANT: Make sure all equipment is turned off before
making any connections.
For speaker connections, use a high-quality speaker wire with
polarity coding. The side of the wire with a ridge or other
coding is usually considered positive polarity.
If desired, consult Nissindo technical support for
speaker wire and connection options.
The speakers have coded terminals that accept a variety or
wire connectors.
To ensure proper polarity, connect each + terminal on the
back of the amplifier or receiver to the respective + (red)
terminal on each speaker. Connect the – (black) terminals in
a similar way. See the owner’s guides that were included
with your amplifier, receiver and television to confirm connec-
tion procedures.
IMPORTANT: Do not reverse polarities (i.e., + to – or – to +)
when making connections. Doing so will cause poor
imaging and diminished bass response.
ADJUSTING
Check the speakers for playback, first by setting the system
volume control to a minimum level, and then by applying
power to your audio system. Play a favorite music or video
segment and increase the system volume control to a comfort-
able level.
You should hear balanced audio reproduction across
the entire frequency spectrum. If not, check all wiring
connections or consult the authorized dealer from whom you
purchased the system for more help.
The amount of bass you hear and the stereo-image quality
will be affected by a number of different factors, including the
room’s size and shape, the construction materials used to
build the room, the listener’s position relative to the speakers,
and the position of the speakers in the room.
Listen to a variety of music selections and note the bass level.
If there is too much bass, move the speakers away from
nearby walls. Conversely, if you place the speakers closer to
the walls, there will be more bass output.
CARING
Each enclosure has a finish that does not require any routine
maintenance. When needed, use a soft cloth to remove any
fingerprints or dust from the enclosure or grille.
