INSTRUCTION MANUAL

MODEL:NODOR NMW25Ix

Microwave Oven

SAVE THESE INSTRUCTIONS CAREFULLY

Read these instructions carefully before using your

microwave oven, And keep it carefully for future reference.

If you follow the instructions, your oven will provide you with

many years of good service.

SPECIFICATIONS

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since this can result

in harmful exposure to microwave energy.It is important not to defeat or

tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or

allow soil or cleaner residue to accumulate on sealing surfaces.

that the oven door closes properly and that there is no damage to the:

(1) DOOR(dent)

(2) HINGES AND LATCHES(broken or loosened)

(3) DOOR SEALS AND SEALING SURFACE

(d) The oven should not be adjusted or repaired by anyone except properly

qualified service personnel.

Model:

Power Source:

Power Consumption:

Maximum Output:

Grill Output:

Oven Capacity:

Turntable Diameter:

External Dimensions (LxWxH):

Net Weight:

NMW25Ix

230V~ 50Hz

1450 W

850 W

1000 W

25 Litres

315 mm

516mmX393mmX307mm

Approx. 17.0 Kg

SAFETY

1. The oven must be level.

2. The turntable and turntable roller rest must be in the oven during cooking. Place the

cookware gently on the turntable and handle it carefully to avoid possible breakage.

3. Incorrect use of browning dish may cause the turntable to break.

4. Use only the specified bag size when using Direct Access Popcorn.

5. The oven has several built-in safety switches to ensure that the power remains off when

the door is open. Do not tamper with these switches.

6. Do not operate the microwave oven empty. Operating the oven with no food or food that

is extremely low in moisture can cause fire, charring or sparking.

7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may

cause the turntable to break.

8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating

may occur and could cause physical injury.

9. Do not heat narrow-necked containers, such as syrup bottles.

10. Do not attempt to deep-fry in your microwave oven.

11. Do not attempt home canning in this microwave oven as it is impossible to be sure all

contents of the jar have reached boiling temperature.

12. Do not use this microwave oven for commercial purpose. This microwave oven

is made for household use only.

13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding

yourself, stir liquid before placing the container in the oven and again halfway

through cooking time. Let stand in the oven for a short time and stir again before

removing the container.

14 .Please do notice the food in the microwave oven to avoid burning due to excessive

cooking when cooking food in it.

1. Read all instructions before using the

appliance.

2. Read and follow the specific:"PRECAU-

TIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY".

3. As with most cooking appliances,close

supervision is necessary to reduce the

risk of a fire in the oven cavity.

If a fire should start:

1.Keep the oven door closed

2.Turn the oven off, and unplug the appliance.

3.Disconnect the power at the fuse or circuit

breaker panel.

Keep in mind the following rules at all

times:

1.Do not overcook food. Carefully attend the

appliance if paper,plastic,or other combus-

tible materials are placed inside the oven to

facilitate cooking.

2.Do not use the oven cavity for storage pur-

poses. Do not store combustible items su-

ch as bread, cookies, paper products, etc.

inside the oven. If lightning strikes the power

line, the oven may turn on by itself.

3.Remove wire twist-ties and metal handles

from paper or plastic containers/bags before

placing them in the oven.

4.This oven must be grounded. Connect only

to properly grounded outlet. See"GROUN-

DING INSTRUCTIONS".

5. Install or locate this oven only in accordance

with the installation instructions provided.

6. Some products such as whole

eggs, water with oil or fat, sealed

containers and closed glass jars may

explode and therefore should not be

heated in this oven.

7. Use this appliance only for its intended

uses as described in the manual. Do

not use corrosive chemicals or vapors

in this appliance. This oven is specifically

designed to heat or cook food. It is not

designed for industrial or laboratory use.

8. As with any appliance, close supervision

is necessary when used by children.

9. Do not operate this oven if it has a

damaged cord or plug, if it is not working

properly or if it has been damaged or

dropped.

10. This appliance should be serviced

only by qualified service technicians.

Contact the nearest authorized

service facility for examination,repair

or adjustment.

11. Do not cover or block any vents on the

oven.

12. Do not store or use this appliance

outdoors.

13. Do not use this oven near water,near

a kitchen sink, in a wet basement or

near a swimming pool.

14. Do not immerse cord or plug in water.

15. Keep cord away from heated surfaces.

16. Do not let cord hang over edge of table

or counter.

17. When cleaning door and oven surfaces

use only mild, nonabrasive soaps or

detergents applied with a sponge or

soft cloth.

Important Safety Instructions

SAFETY

WARNING— To reduce the risk of fire, electric shock, injury to

persons, or exposure to excessive microwave oven

energy when using your appliance, follow

these basic precautions :

SAVE THESE INSTRUCTIONS

DANGER

Electric Shock Hazard Touching

some of the internal components

can cause serious personal injury

or death.Do not disassemble this

appliance

WARNING

Electric Shock Hazard

Improper use of the grounding

can result in electric shock. Do

not plug into an outlet until

appliance is properly installed

and grounded.

Three-pronged

(grounding) plug

Grounding Installation

Properly polarized and

grounded outlet

This appliance must be grounded. In the event of an elec-

trical short circuit, grounding reduces the risk of electric

shock by providing an escape wire for the electric current.

This appliance is equipped with a cord having a grounding

wire with a grounding plug. The plug must be plugged into

an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the ground-

ing instructions are not completely understood or if doubt

exists as to whether the appliance is properly grounded.

If it is necessary to use an extension cord, use only a 3-

wire extension cord that has a 3-pronged grounding plug,

and a 3-slot receptacle that will accept the plug on the

appliance.

1. A short power-supply cord is provided to reduce the

risks resulting from becoming entangled in or tripping

over a longer cord.

2. Longer cord sets or extension cord is provided to

reduce the risks resulting from becoming entangled

in or tripping over a longer cord.

3. If a long cord set or extension cord is used: 1)The

marked electrical rating of the cord set or extension

cord should be at least as great as the electrical rating

of the appliance. 2)The extension cord must be a

grounding-type 3-wire cord, and 3)The longer cord

should be arranged so that it will not drape over the

counter top or tabletop where it can be pulled on by

children or tripped over unintentionally.

CAUTION

Personal Injury Hazard

Tightly-closed utensils

could explode. Closed

containers should be

opened and plastic

pouches pierced

before cooking.

Utensils See next page for further instructions “Materials you

can use in microwave oven or to be avoided in micro-

wave oven.”There may be certain nonmetallic utensils

that are not safe to use for microwaving. If in doubt,

you can test the utensil in question following the

procedure below.

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold

water (250ml) along with the utensil in question.

2. Cook on maximum power for 1 minute.

3. Carefully feel the utensil. If the empty utensil is warm,

do not use it for microwave cooking.

4. Do not exceed 1 minute cooking time.

Materials to be avoided in microwave oven

Utensils

Aluminum tray

Food carton with

metal handle

Metal or metal-

trimmed utensils

Metal twist ties

Paper bags

Plastic foam

Wood

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat

or poultry to prevent overcooking. Arcing can occur if foil is too close to

oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls.

Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be at

least 3/16 inch (5mm) above the turntable.Incorrect usage may cause

the turntable to break.

Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked

or chipped dishes.

Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars

are not heat resistant and may break.

Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do

not use cracked or chipped dishes.

Oven cooking Follow manufacturer’s instructions. Do not close with metal tie. Make slits to

bags allow steam to escape.

Paper plates Use for short –term cooking/warming only. Do not leave oven unattended while

and cups cooking.

Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for

short-term cooking only.

Parchment Use as a cover to prevent splattering or a wrap for steaming.

paper

Plastic Microwave-safe only. Follow the manufacturer’s instructions.Should be labelled

“Microwave Safe”. Some plastic containers soften as the food inside gets hot.

“Boiling bags” and tightly closed plastic bags should be slit, pierced or vented

as directed by package.

Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do

not allow plastic wrap to touch food.

Thermometers Microwave-safe only (meat and candy thermometers).

Wax paper Use as a cover to prevent splattering and retain moisture.

Remarks

May cause arcing. Transfer food into microwave-safe dish.

Metal shields the food from microwave energy. Metal trim may cause

arcing.

May cause arcing and could cause a fire in the oven.

May cause a fire in the oven.

Plastic foam may melt or contaminate the liquid inside when exposed

to high temperature.

Wood will dry out when used in the microwave oven and may split or

crack.

A)Control panel

B)Turntable shaft

C)Turntable ring assembly

D)Glass tray

E)Observation window

F) Door assembly

G)Safety interlock system

Grill(OnlyforGrillseries)

SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton.

Your oven comes with the following accessories:

Glass tray 1

Turntable ring assembly 1

Instruction Manual 1

Shuts off oven power if door is opened during operation.

a. Neverplacethe

glasstray

upsidedown.The

glasstray

shouldneverberestricted.

b. Both

glass tray

and

turntable ring assembly

must always

beusedduringcooking.

c. All food and containers of food should always placed

onthe

glasstray

forcooking.

d.The

glasstray

rotatesclockwise;thisisnormal.

e. If

glasstray

turntableringassembly

cracksor breaks, contact

yournearestauthorizedservicecentre.

TURNTABLE INSTALLATION

Hub(underside)

Glass tray

Turntable ring assembly

Turntable shaft

Installation

Remove all packing material and accessories.

Examine the oven for any damage such as

dents or broken door. Do not install if oven is

damaged.

Countertop

Cabinet: Remove any protective film found

on the cabinet surface.

Do not remove the light brown Mica cover

that is screwed to the oven cavity to

protect the magnetron.

Installation

1. Select a level surface that provide

enough open space for the intake

and/or outlet vents.

A minimum clearance of 3.0 inch

(7.5cm) is required between the oven and

any adjacent wall.One side must be open.

(1) Leave a minimum clearance of 12

inch(30cm) above the oven.

(2) Do not remove the legs from the

bottom of the oven.

(3) Blocking the intake and/or outlet openings

can damage the oven.

(4)Place the oven as far away from

radios and TV as possible.Operation

of microwave oven may cause interference

to your radio or TV reception.

2. Plug your oven into a standard household

outlet. Be sure the voltage and the

frequency is the same as the voltage and

the frequency on the rating label.

WARNING: Do not install oven over a

range cooktop or other heat-producing

appliance. If installed could be damaged

and the warranty would be void.

3.0 inch(7.5cm)

12 inch(30cm)

OPEN

3.0 inch(7.5cm)

2). Microwave cooking

Select different microwave power and set cooking time as you wish.

• Five microwave power levels are available. Refer to Chart 1 to choose.

• Maximum microwave cooking time is 99 minutes 90 seconds.

• Keep on pressing "Power level", choose different power as per above attachment.

Chart 1

Microwave Power Chart

A.Microwave.

This microwave oven uses modern electronic control to adjust cooking

parameters to better meet your needs for cooking.

OPERATION

3). Speedy cooking

When the oven is in the waiting states, press directly the "10Min", "1Min" and "10Sec"

keys to input cooking time. And then press the "Start" key, and the oven goes into

100% microwave heat power cooking state.

4). Automatic defrosting

(1) Press the "Defrost" key several times to select defrosting weight (g);

Inhaltsverzeichnis

Andere NODOR Mikrowellenofen Handbücher

NODOR

NODOR NM-25 DG DB Bedienungsanleitung

Beliebte Mikrowellenofen Handbücher anderer Marken

Daewoo

Daewoo KOG-574R0S Bedienungsanleitung

LG MH7040SS Bedienungsanleitung

Sharp

Sharp R-895(AL)M Bedienungsanleitung

Dometic

Dometic DOTRM13W Bedienungsanleitung

Sanyo

Sanyo EM-X680 Bedienungsanleitung

Sharp

Sharp R-393M Bedienungsanleitung

KitchenAid

KitchenAid KMCX4510 Montageanleitung

Smeg

Smeg S45MCX1 Bedienungsanleitung

Russell Hobbs

Russell Hobbs RHM2044 Bedienungsanleitung

Sunbeam

Sunbeam SMW759 Bedienungsanleitung

Gallet

Gallet FMOE230S Bedienungsanleitung

Bosch

Bosch CEG732X.1B Bedienungsanleitung

Dometic

Dometic Roadmate 230 Bedienungsanleitung

Samsung

Samsung SJ0396W Bedienungsanleitung

Sanyo

Sanyo EM-P494WS Bedienungsanleitung

Sharp

Sharp R-240 Bedienungsanleitung

Electrolux

Electrolux EMS2840 Bedienungsanleitung

Daewoo

Daewoo KOC-984T2S13 Bedienungsanleitung
