Nordmende RET346C Bedienungsanleitung

DOUBLE DOOR REFRIGERATOR

FREEZER - FRIDGE

Instruction booklet

KÜHL-GEFRIER-KOMBINATION

Bedienungsanleitung

RET346C

EN - 1 -

Contents

BEFORE USING YOUR REFRIGERATOR ............................................2

General warnings ........................................................................................... 2

Old and out-of-order fridges ............................................................................ 4

Safety warnings ............................................................................................. 4

Installing and operating your fridge ................................................................. 5

Before Using your Fridge ................................................................................ 5

THE VARIOUS FUNCTION AND POSSIBILITIES.................................. 6

Thermostat setting ......................................................................................... 6

Super switch ................................................................................................. 6

Accessories .................................................................................................. 7

Ice tray ........................................................................................................................... 7

Magic shelf .................................................................................................................... 7

If turbo fan is available on your product ; ................................................................... 7

Bottle holder ................................................................................................................. 7

ARRANGING FOOD IN THE APPLIANCE ..............................................8

Refrigerator compartment ............................................................................... 8

Freezer compartment..................................................................................... 8

CLEANING AND MAINTENANCE ........................................................... 9

Defrosting .....................................................................................................10

Replacing the light bulb ................................................................................. 11

SHIPMENT AND REPOSITIONING ...................................................... 11

Repositioning the door .................................................................................. 11

BEFORE CALLING YOUR AFTER SALES SERVICE .......................... 12

Tips for saving energy ................................................................................... 13

THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....... 14

EN - 2 -

General warnings

WARNING: Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended

by the manufacturer.

WARNING: Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: To avoid a hazard due to the instability of the appliance,

it must be fixed in accordance with the instructions.

• If your appliance uses R600a as a refrigerant – you can learn

this information from the label on the cooler- you should be careful

during shipment and installation to prevent your appliance’s cooler

elements from being damaged. Although R600a is an

environmentally friendly and natural gas. As it is explosive, in the

event of a leak due to damage to the cooler elements, move your

fridge from open flame or heat sources and ventilate the room

where the appliance is located for a few minutes.

• While carrying and positioning the fridge, do not damage the

cooler gas circuit.

• Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

• This appliance is intended to be used in household and similar

applications such as;

- staff kitchen areas in shops, offices and other working

environments

- farm houses and by clients in hotels, motels and other residential

type environments

BEFORE USING YOUR REFRIGERATOR

PART - 1.

EN - 3 -

- bed and breakfast type environments;

- catering and similar non-retail applications

• If the socket does not match the refrigerator plug, it must be

replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety. Children should be

supervised to ensure that they do not play with the appliance.

• A specially grounded plug has been connected to the power

cable of your refrigerator. This plug should be used with a

specially grounded socket of 16 amperes. If there is no such

socket in your house, please have it installed by an authorized

electrician.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similar qualified persons in

order to avoid a hazard.

EN - 4 -

Safety warnings

• Do not use multiple receptacles or extension cord.

• Do not plug in damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• This appliance is designed for use by adults, do not allow children

to play with the appliance or let them hang off the door.

• Do not plug-in or out the plug from the receptacle with wet hands to

prevent electrocution!

• Do not place glass bottles or beverage cans in the freezer

department. Bottles or cans may explode.

• Do not place explosive or flammable material in your fridge for your

safety. Place drinks with higher alcohol amount vertically and by

closing their necks tightly in the fridge department.

• When taking ice made in the freezer department, do not touch it, ice

may cause ice burns and/or cuts.

• Do not touch frozen goods with wet hands! Do not eat ice-cream

and ice cubes immediately after you have taken them out of the

freezer department!

Old and out-of-order fridges

• If your old fridge has a lock, break or remove the lock before discarding it, because

children may get trapped inside it and may cause an accident.

• Old fridges and freezers contain isolation material and refrigerant with

CFC. Therefore, take care not to harm environment when you are discarding

your old fridges.

Please ask your municipal authority about the disposal of the WEEE for the

reuse, recycle and recovery purposes.

Notes:

• Please read the instruction manual carefully before installing and using your appliance.

We are not responsible for the damage occurred due to misuse.

• Follow all instructions on your appliance and instruction manual, and keep this

manual in a safe place to resolve the problems that may occur in the future.

• This appliance is produced to be used in homes and it can only be used in domestic

environments and for the specified purposes. It is not suitable for commercial or

common use. Such use will cause the guarantee of the appliance to be cancelled

and our company will not be responsible for the losses to be occurred.

• This appliance is produced to be used in houses and it is only suitable for cooling /

storing foods. It is not suitable for commercial or common use and/or for storing

substances except for food. Our company is not responsible for the losses to be

occurred in the contrary case.

EN - 5 -

• Do not re-freeze frozen goods after they have melted. This may cause

health issues like food poisoning.

• Do not cover the body or top of fridge with lace. This affects the

performance of your fridge.

• Fix the accessories in the fridge during transportation to prevent damage to

accessories.

Installing and operating your fridge

Before starting to use your fridge, you should pay attention to the following points:

• Operating voltage for your fridge is 220-240 V at 50Hz.

• We do not take the responsibility of the damages that occur due to ungrounded

usage.

• Place your fridge in a place that it would not be exposed to direct sunlight.

• Your appliance should be at least 50 cm away from stoves, Gas

ovens and heater cores, and should be at least 5 cm away from

electrical ovens.

• Your fridge should never be used outdoors or left under the rain.

• When your fridge is placed next to a deep freezer, there should be at

least 2 cm between them to prevent humidity on the outer surface.

• Do not place anything on your fridge, and install your fridge in a

suitable place so that at least 15 cm is available on the upper side.

• The adjustable front legs should be adjusted to make sure your appliance is level

and stable. You can adjust the legs by turning them clockwise (or in the opposite

direction). This should be done before placing food in the fridge.

• Before using your fridge, wipe all parts back with warm water

added with a tea spoonful of sodium bicarbonate, and then

rinse with clean water and dry. Place all parts after cleaning.

• Install the plastic distance guide (the part with black vanes at

the rear) by turning it 90° as shown in the figure to prevent the

condenser from touching the wall.

• Refrigerator should be placed against a wall with a free distance not exceeding 75

mm.

Before Using your Fridge

• When it is operated for the first time or after transportation, keep

your fridge in the upright position for 3 hours and plug it on to

allow efficient operation. Otherwise, you may damage the

compressor.

• Your fridge may have a smell when it is operated for the first time; the smell will fade

away when your fridge starts to cool.

EN - 6 -

PART - 2. THE VARIOUS FUNCTION AND POSSIBILITIES

Thermostat setting

• Thermostat automatically regulates the inside

temperature of the refrigerator compartment and

freezer compartment.By rotating the knob from position

1 to 5, colder temperatures can be obtained. «•» position

shows thermostat is closed and no cooling will be

available.

• For short-term storage of food in the freezer

compartment, you can set the knob between 1 and 3

position.

• For long-term storage of food in the freezer

compartment, you can set knop 3-4 position.

Note that ; the ambient temperature, temperature of the freshly stored food and how often

the door is opened, affects the temperature in the refrigerator compartment. If

required,change the temperature setting.

Super switch

• Normally set this switch to ‘ ’ position. Except when the

ambient temperature is low like in winter.(ie.below 16°C) or

when the freezer temperature needs to be maintained lower.

In that case, turn the switch to ‘ ’ position ON.

• To set super switch ON that is on the thermostat box, press the

switch down to ’position. The switch will lit.

• When the freezer compartment is cooled down to sufficient

temperature, or the weather gets hot, turn the super switch off

to save electrical consumption.

• When you first switch on the appliance, for starting a suitable

cooling, the appliance should work 24 hours continuously until

it cools down to sufficient temperature.

• In this time do not open the door so often and place a lot of

food inside the appliance.

If the unit is switched off or unplugged, you must allow at least 5 minutes before

restarting or re-plugged the unit in order not to damage the compressor.

(If super switch is available)

EN - 7 -

Ice tray

• Fill the ice tray with water and place in freezer compartment.

• After the water completely turned into ice, you can twist the tray as shown below to get

the ice cube.

Bottle holder

In order to prevent the bottles to slip or fall over you can use the bottle holder. You can also

prevent making noise that will be done when you open or close the door.

Accessories

(In some models)

Magic shelf

Magic shelf which is on the Crisper Cover(safety glass) (see part 7-page 14) was designed

to give you more place and comfort placing the things in the appliance. This shelf is

mobile so you can arrange long or big containers on the crisper cover.

(In some models)

If turbo fan is available on your product ;

• Do not block air inlet and outlet openings when storing food, otherwise air circulation

that provided by turbo fan will be impaired.

Turbo fan

EN - 8 -

PART - 3. ARRANGING FOOD IN THE APPLIANCE

Refrigerator compartment

• To reduce humidity and consequent increase of frost never place liquids in unsealed

containers in the refrigerator. Frost tends to concentrate in the coldest parts of the

evaporator and in time will require more frequent defrosting.

• Never place warm food in the refrigerator. Warm food should be allowed to cool at

room temperature and should be arranged to ensure adequate air circulation in the

refrigerator compartment.

• Nothing should touch on the back wall as it will cause frost and the packages can

stick on the back wall. Do not open the refrigerator door too frequently.

• Arrange the meat and cleaned fish(wrapped in packages or sheets of plastic) which

you will use in 1-2 days,in the bottom section of the refrigerator compartment(that is

above the crisper) as this is the coldest section and will ensure the best storing

conditions.

• You can put the fruits and vegetables into crisper without packing.

Freezer compartment

• The use of freezer is, storing of deep-frozen or frozen foods for long periods of time

and making ice cubes.

• To freeze fresh food, ensure that as much of the surface as possible of food to be

frozen is in contact with the cooling surface.

• Do not put fresh food with frozen on side by side as it can thaw the frozen food.

• While freezing fresh foods(i.e meat,fish and mincemeat), divide them in parts you

will use in one time.

• Once the unit has been defrosted replace the foods into freezer and remember to

consume them in as short period of time.

• Never place warm food in the freezer compartment. As it will disturb the frozen foods.

• For storing the frozen foods;the instructions shown on frozen food packages should

always be followed carefully and if no information is provided food should not be

stored for more than 3 months from the purchased date.

• When buying frozen foods ensure that these have been frozen at suitable

temperatures and that the packing is intact.

• Frozen foods should be transported in appropriate containers to maintain the quality

of the food and should be returned to the freezing surfaces of the unit in the shortest

possible time.

• If a package of frozen food shows the sign of humidity and abnormal swelling it is

probable that it has been previously stored at an unsuitable temperature and that

the contents have deteriorated.

• The storage life of froozen foods depends on the room temperature, thermostat

setting, how often the door is opened, the type of food and the length of time required

to transport the product from the shop to your home. Always follow the instructions

printed on the package and never exceed the maximum storage life indicated.

Not that; if you want to open again immediately after closing the freezer door, it will not be

opened easily. It’s quite normal! After reaching equilibrium condition, the door will be

opened easily.

EN - 9 -

PART - 4. CLEANING AND MAINTENANCE

• You should clean the condenser with broom at least once

a year in order to provide energy saving and increase

the productivity.

• Make sure to unplug the fridge before starting to clean it.

• Do not wash your fridge by pouring water.

• You can wipe the inner and outer sides with a soft cloth

or a sponge using warm and soapy water.

• Remove the parts individually and clean with soapy water.

Do not wash in washing machine.

• Never use flammable, explosive or corrosive material like

thinner, gas, acid for cleaning.

Make sure that your fridge is unplugged while cleaning.

Inhaltsverzeichnis

Sprachen:

Andere Nordmende Kühlschrank Handbücher

Nordmende

Nordmende RII1232A+ Bedienungsanleitung

Nordmende

Nordmende RTL395WHA+ Bedienungsanleitung

Nordmende

Nordmende RTL397RIXA+ Bedienungsanleitung

Nordmende

Nordmende RFF315NFWHA+ Bedienungsanleitung

Nordmende

Nordmende RUL152WHA+ Bedienungsanleitung

Nordmende

Nordmende RUL151WHA+ Bedienungsanleitung

Nordmende

Nordmende RFF263WHA+ Bedienungsanleitung

Nordmende

Nordmende RETNF369CA+ Bedienungsanleitung

Nordmende

Nordmende RET340R Bedienungsanleitung

Nordmende

Nordmende RIFF50501NM Bedienungsanleitung

Nordmende

Nordmende RETNF368BLUEA+ Bedienungsanleitung

Nordmende

Nordmende RF70173RIX Bedienungsanleitung

Nordmende

Nordmende RF4DRIXA+ Bedienungsanleitung

Nordmende

Nordmende RFAM510BLA+ Bedienungsanleitung

Nordmende

Nordmende RFF334SL Bedienungsanleitung

Nordmende

Nordmende RIUI161NMA+ Bedienungsanleitung

Nordmende

Nordmende RUI111NMWHA+ Bedienungsanleitung

Nordmende

Nordmende RETNF366C Bedienungsanleitung

Nordmende

Nordmende RUL120NMWHA+ Bedienungsanleitung

Nordmende

Nordmende RIFF50503NMA+ Bedienungsanleitung

Nordmende

Nordmende RFA91IX Bedienungsanleitung

Nordmende

Nordmende RITL395A+ Bedienungsanleitung

Nordmende

Nordmende RET347BLUEA+ Bedienungsanleitung

Nordmende

Nordmende RTL398WH Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
