(a) Pull on the tip of one of the Spring Plates to bend it outwards to open up the area formed by
the tips of the three Spring Plates.
(b) Slip the Glass Dome, with the open end forward, into the space formed within the three
Spring Plates. Press against the two Spring Plates slightly to position the Dome in the center.
(c) Let go gently the Spring Plate pulled outward in (a) above to make it press against the Glass
Dome. Now all three Spring Plates should be pressing against the Glass Dome.
(d) Continue to push the dome forward gently all the way until it reaches the surface of the
Reflector. The catch near the tip of the three Spring Plates should at this point lock
themselves into their corresponding holes on the wall of the dome to lock the dome in place.
If any of them does not, rotate the dome in one direction or the other to help the Spring Plates
find their respective locking holes.
(e) Try to pull and rotate the dome lightly to confirm that it is properly secured in place.
3.5. To remove the Glass Dome –
(a) Press the Glass Dome in the direction of one of the three Spring Plates and then tilt it slightly
so that the locking tips of the other two Spring Plates will slip out of their respective locking
holes.
(b) Press the Glass Dome towards the other two Spring Plates, avoiding their tips from going
back into their respective locking holes, and then pull the dome out slightly to let the tip of
the first Spring Plate slip out of its locking hole.
(c) Pull to remove the Glass Dome.
4. Replacement of Lamp Bulbs
4.1. If the user should choose to replace the lamp bulbs with ones of different power ratings, care
must be taken to make sure that the aggregate power of the lamp bulbs does NOT exceed
1000W.
4.2. Take the following steps when replacing the lamp bulbs –
a. Turn off power.
b. Wait until the lamp bulbs and Glass Dome cool down completely.
c. Disconnect the Installation Hooks to remove the Glass Dome.
d. Replace the lamp bulb(s).
e. Put on the Glass Dome and secure it in position with the Installation Hooks.
Caution: Never touch the quartz lamp bulbs with bare hands as the performance and life of the
bulb may be affected adversely if any grease, sweat, moisture, etc. should be left on
