Magellan Vector OMS-V 2.3 Release Notes

Magellan Vector OMS-V 2.3 MR1

Release Notes

Software Release Date: September 17 1998

Issue: 2.2

1998 Northern Telecom

*Magellan is a trademark of Northern Telecom

Printed in Canada

Magellan Vector OMS-V 2.3 Release Notes

Revision Record

Issue Date Purpose

1.0 Jun 23, 1998 OMS-V 2.3 Beta release notes.

1.1 Jun 23, 1998 Change HPOV patch list.

Add a unresolved SR on multiple IP interfaces

1.2 Aug 11, 1998 OMS-V 2.3.2 GA Release Notes

1.3 Aug 19, 1998 Add 2.2 and 2.1 resolved SRs

Add unresolved SRs uni-directional links displayed for

multiple IP interface types

2.0 Sep 10, 1998 OMS-V 2.3 MR1 release notes

2.1 Sep 17, 1998 Document review modiﬁcations

2.2 Sep 24, 1998 Add unresolved SR

Table of Contents 3

Magellan Vector OMS-V 2.3 Release Notes

Table of Contents

Chapter 1 Introduction 7

Contents of these Release Notes 7

Conﬁguration Supported 7

Functionality Supported 8

OMS-V Hardware 8

VSS 8

OMS-V 2.3 9

HP-OV 5.01 9

MDP 9

Documentation 9

Limitation 9

Exclusions 10

Chapter 2 Release Considerations 12

OMS-V 2.3 MR1 Installation Instructions 12

OMS-V 2.3 MR1 Release Introduction 13

Sun Microsystems Platform Considerations 13

Sun Solaris Installation 14

Hewlett Packard Platform Considerations 14

OMS-V Installation on Hewlett Packard 14

HP-Openview Considerations 14

VSM to OMS-V Upgrade Strategy Considerations 15

Upgrade VSM 1.1.x/2.0 or OMS-V 2.2.x to OMS-V 2.3 MR1 16

Chapter 3: Resolved Service Requests 17

OMS-V 2.3 Resolved Service Requests 17

10176058 Link Connection Between 2.3 and 2.3 Switches is shown as

Uni-Directional 17

10077699 It takes too long to reﬂect network changes on VSM Magellan

submap 17

10174616 Unable to Conﬁgure CDAS or AVR From The Front Panel View 17

Chapter 4 Unresolved Service Requests 18

4Table of Contents

Magellan Vector OMS-V 2.3 Release Notes

Unresolved Service Requests 18

Descriptions of Unresolved Service Requests 18

10131026 OMS-V 2.2.1 - No Colors Left 18

10092242 Trace PVC feature does not trace the complete VCC 18

10176700 Log Hosts utility does not launch from the Networks submap 19

10171439 conf vcc sh and con vpc sh give error on vmi from host 19

10131028 Front Panel Alarms Don’t Match Popup 19

Chapter 5 Trouble Shooting 21

After performing OMS-V upgrade, switches are not being discovered, Magellan

Network Submap remains empty. What is wrong? 21

The system is very slow, OR, the system seems to be doing something else

from time to time. 21

Chapter 6 Documentation 23

Addendum to NTP 241-9501-200, Software Installation and Commissioning for

Vector and Access Shelf 23

Table of Contents 5

Magellan Vector OMS-V 2.3 Release Notes

Tables and Figures

Table 1: OMS-V compatibility with Vector switching components .........................8

Table 2: OMS-V 2.3 MR1 Feature Limitations.......................................................10

Table 3: Product Release List ..................................................................................12

Table 4: Third Party Product Patch List...................................................................13

Figure 1: Upgrade OMS-V........................................................................................16

Table 5: OMS-V 2.3 Resolved Service Requests ....................................................17

Table 6: Unresolved Service Requests.....................................................................18

6Table of Contents

Magellan Vector OMS-V 2.3 Release Notes

Chapter 1 Introduction

These release notes provide release information for the Vector system

managementcomponentOMS-V(OpenManagementSystem-Vector)release

2.3 MR1 (Maintenance Release 1). OMS-V replaces VSM (Vector System

Manager).

Contents of these Release Notes

• Chapter 1 provides an overview of this document and the product

functionality included and excluded for this release.

• Chapter 2 contains general release considerations.

• Chapter 3 lists Service Requests resolved in this release.

• Chapter 4 lists unresolved high priority Service Requests.

• Chapter 5 outlines common problems encountered with OMS-V and how

to resolve them.

• Chapter 6 provides a list of the changes and additions to NTP 241-9501-

200, Vector Software Installation and Commissioning.

Conﬁguration Supported

The various components of a Vector network include:

• Vector Switching System (VSS), a Vector switching component.

• Magellan Data Provider (MDP), a Magellan product billing component.

• Open Management System - Vector (OMS-V), a Vector network system

management component.

This release includes support for the following conﬁgurations:

• 2.5 or 5.0 Gbits Vector switches with the Vector Switching System (VSS)

versions VSS 1.1.x, VSS 2.0.x, VSS 2.2.x, and/or 2.3.x

• The Magellan Data Provider (MDP). Refer to the MDP release notes for

compatibility with Vector releases.

• The Open Management System - Vector (OMS-V) version OMS-V 2.3

MR1. (This was previously known as the Vector System Manager

component.)

Magellan Vector OMS-V 2.3 Release Notes

The following table outlines the conﬁguration compatibility between the

OMS-V and Vector switching components.

Functionality Supported

OMS-V Hardware

For OMS-V 2.3 MR1, it is recommended that the OMS-V workstations be Sun

Microsystems’ or Hewlett Packard’s current product line that supports their

Solaris 2.6 or HP-UX 10.20 operating systems.

VSS VSS 2.3 MR1 release notes are covered in a separate document. Please refer

to the VSS 2.3 MR1 release notes for any on-switch related issues.

Table 1: Open Management System Vector (OMS-V) compatibility with Vector switching

components

Switching component

Network mgmt release / platform VSS

1.1.x VSS

2.0.x VSS

2.2.x VSS 2.3

MR1 AS 1.0

VSM 1.1 SunOS 3.4 & HP-OV 3.3 Y - - - -

HP-UX 9.05 & HP-OV 3.3 Y - - - -

VSM 2.0 SunOS 3.4 & HP-OV 3.3 Y Y - - -

HP-UX 9.05 & HP-OV 3.3 Y Y - - -

OMS-V 2.1 Solaris 2.5.1 & HP-OV 4.11 Y Y - - Y

HP-UX 10.20 & HP-OV 4.11 Y Y - - Y

OMS-P/V 2.1 Solaris 2.5.1 & HP-OV 4.11 Y Y - - Y

OMS-V 2.2.3 Solaris 2.5.1 & HP-OV 4.11 Y Y Y - Y

HP-UX 10.20 & HP-OV 4.11 Y Y Y - Y

OMS-V 2.3 GA Solaris 2.6 & HP-OV 5.01 Y Y Y Y Y

HP-UX 10.20 & HP-OV 5.01 YYYYY

OMS-V 2.3 MR1 Solaris 2.6 & HP-OV 5.01 Y Y Y Y Y

HP-UX 10.20 & HP-OV 5.01 YYYYY

Bold represents OMS-V 2.3 MR1 (Maintenance Release 1) Vector system management elements

Magellan Vector OMS-V 2.3 Release Notes

OMS-V 2.3

The OMS-V 2.3 MR1 release introduces no new functionality. Please see

OMS-V 2.3 GA Release Notes for new functionality introduced in OMS-V

2.3.

Further details are provided in the related NTP 241-9501-302, Open

Management System for Vector (OMS-V) Guide.

HP-OV 5.01

In HP-OV 5.01, Overlay Submap option is provided for controlling the

creation of map windows. The default option for Overlay Submap is to change

maps/submap without creating new windows, to have only one window visible

at a time. Double clicking on one enclosure in the network submap for

example, will not create a new connection submap, but transforms the network

submap into a connection submap. Further details are provided in the NTP

241-9501-302, Open Management System for Vector (OMS-V) Guide.

MDP Please see the release notes appropriate to MDP releases supporting VSS

components.

Documentation

• Release Notes

• NTP 241-9501-000, Vector List of Terms

• NTP 241-9501-010, Vector General Description

• NTP 241-9501-103, Vector Site Requirements and Preparation Guide

• NTP 241-9501-111, Vector Hardware Description

• NTP 241-9501-200, Vector Software Installation and Commissioning

• NTP 241-9501-205, Vector Hardware Installation and Upgrade User

Guide

• NTP 241-9501-301, Vector Operations and Maintenance Using VMI User

Guide

• NTP 241-9501-302, Open Management System for Vector (OMS-V) Guide

• NTP 241-9501-501, Vector Hardware Maintenance User Guide

• NTP 241-9501-503, Vector Management Interface (VMI) Commands

Reference Guide

Limitation The UNI trafﬁc class and UBR policing features are managed via the OMS-V

Release 2.3 MR1 GUI starting from VSS version Release 2.2.3. Earlier

versions of VSS and OMS-V had a mismatch in the MIB OIDs associated with

Magellan Vector OMS-V 2.3 Release Notes

UBR Policing and UNI trafﬁc class. As a result, OMS-V was unable to obtain

or assign the correct information on the switch. Since Release 2.2.3, the MIB

OID has been updated to be consistent on both VSS and OMS-V. However, all

previous switches still use the old MIB OID, the UNI trafﬁc class can not be

set via the OMS-V Release 2.2.3 GUI on any version of VSS previous to VSS

Release 2.2.3. For all previously released versions of VSS, the on-switch VMI

must be used.

Table 2: OMS-V 2.3 MR1 Feature Limitations

Please note that these features are limited to on-switch VMI only for switches

with previous versions to VSS Release 2.2.3.

A defect exists on showing bi-directional links when qaa0 and non-qaa0 (ie0,

qaa1, qaa2,qaa3) IP interface types are up. This is expanded upon in Chapter

4, Unresolved Service Requests.

Exclusions

Excluded from this release:

• OMS-V inter-work with OMS-P, as documented in 10186505. This SR

stops deployment of OMS-V 2.3.3 MR1 with OMS-P.

• Management Console when OMS-V uses IP over ATM.

• Using Remote Front Panel command when OMS-V is managing switches

with either ie0, qaa1, qaa2, or qaa3 interfaces.

• Auto-discovery when OMS-V is managing switches with either ie0, qaa1,

qaa2, or qaa3 interfaces.

Note 1: Although OMS-V can manage Vector switches using one of the IP in-

terfaces: ie0, qaa0, qaa1, qaa2, or qaa3. Remote Front Panel command

and auto-discovery function can only be used with qaa0 interface. When

OMS-V discovery is not using the qaa0 interface, the user must specify

all the switches to be discovered.

Note 2: OMS-V inter-work with OMS-P is pending a forthcoming release of

OMS-P.

Excluded from the product:

• Simultaneously using more than one of the IP interfaces: ie0, qaa1, qaa2,

or qaa3, on OMS-V workstations. (Note: user must select one of the

OMS-V 2.3 MR1

Features VSS R2.2.1

VSS R2.2.2 VSS R2.2.3

VSS R2.3 MR1

UNI Traffic Class on-switch VMI only VMI & GUI

UBR Policing on-switch VMI only VMI & GUI
