Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A)

Document status: Standard

Document version: 01.04

Document date: 6 December 2007

Sourced in Canada, India, and the United States of America

LEGAL NOTICE

While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed

to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY

KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject

to change without notice.

Contents

New in this release 5

Features 5

New SFPs 5

Other changes 5

T1 SFP connections 5

Safety messages 5

Document changes 5

Introduction 7

Safety and regulatory information 9

Handling, safety, and environmental guidelines 9

Electrostatic discharge prevention 9

Care of ﬁber optic equipment 10

Fiber optic cable care 10

Fiber optic connector care 11

Job aid: connector cleaning tools and materials 12

Cleaning single connectors 12

Cleaning duplex connectors 13

Cleaning receptacles 13

Product safety warnings and information 14

ESD and installation caution messages 14

Laser safety warnings 16

Small form factor pluggable transceivers 19

Selecting an SFP 19

Procedure job aid: SFPs and common applications 20

Procedure job aid: SFP models without DDI support 20

Procedure job aid: SFP models with DDI support 21

Installing an SFP 22

Procedure job aid: locking and extractor mechanisms 24

Removing an SFP 25

10 Gigabit small form factor pluggable transceivers 27

Selecting an XFP 27

Procedure job aid: XFP models 28

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

4Contents

Installing an XFP 28

Removing an XFP 30

SFP speciﬁcations 33

SFP labels 33

General SFP speciﬁcations 34

100BASE-FX SFP speciﬁcations 34

T1 SFP speciﬁcations 35

T1 SFP—default settings 37

1000BASE-SX (LC) SFP speciﬁcations 38

1000BASE-SX (MT-RJ) SFP speciﬁcations 39

1000BASE-LX SFP speciﬁcations 40

1000BASE-XD CWDM SFP speciﬁcations 40

1000BASE-ZX CWDM SFP speciﬁcations 41

XFP speciﬁcations 43

XFP labels 43

General XFP speciﬁcations 44

10GBASE-SR XFP speciﬁcations 44

10GBASE-LR/LW XFP speciﬁcations 46

10GBASE-ER/EW XFP speciﬁcations 47

10GBASE-ZR/ZW XFP speciﬁcations 48

Index 50

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

New in this release

The following sections detail what’s new in Nortel Ethernet Routing Switch

4500 Series Installation — SFPs and XFPs (NN47205-301) for Release 5.1.

•"Features" (page 5)

•"Other changes" (page 5)

Features See the following section for information about feature changes:

New SFPs

Release 5.1 supports two new SFPs. See "100BASE-FX SFP

speciﬁcations" (page 34) and "T1 SFP speciﬁcations" (page 35).

Other changes

See the following section for information about changes that are not

feature-related:

T1 SFP connections

Information about T1 SFP connections, including pinout and cable

information, is added to "T1 SFP speciﬁcations" (page 35).

Safety messages

Safety messages and translations are added to "ESD and installation

caution messages" (page 14) and "Laser safety warnings" (page 16).

Document changes

This document is a new document based on the document Installing SFP

and XFP Transceivers and GBICs (318034-D). This document is formatted

to comply with Nortel Customer Documentation Standards.

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

6New in this release

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

Introduction

This document describes how to select, install, and remove an SFP or XFP.

It also provides speciﬁcations for each device.

Navigation

•"Safety and regulatory information" (page 9)

•"Small form factor pluggable transceivers" (page 19)

•"10 Gigabit small form factor pluggable transceivers" (page 27)

•"SFP speciﬁcations" (page 33)

•"XFP speciﬁcations" (page 43)

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

8Introduction

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

Safety and regulatory information

This section contains important safety and regulatory information. Read this

section before you install Small Form Factor Pluggable (SFP) transceivers

or 10 Gigabit SFP (XFP) transceivers.

Navigation

•"Handling, safety, and environmental guidelines" (page 9)

•"Care of ﬁber optic equipment" (page 10)

•"Product safety warnings and information" (page 14)

Handling, safety, and environmental guidelines

Before you install an SFP or XFP, read the following handling, safety, and

environmental guidelines:

•SFPs and XFPs are static sensitive. To prevent damage from

electrostatic discharge (ESD), see "Electrostatic discharge prevention"

(page 9).

•SFPs and XFPs are dust sensitive. When you store an SFP or XFP, or

when you disconnect it from a ﬁber optic cable, always keep a dust

cover over the optical bore.

•To clean contaminants from the optical bores of an SFP or XFP, use an

alcohol swab or equivalent to clean the ferrules of the optical connector.

•Dispose of this product according to all national laws and regulations.

Electrostatic discharge prevention

To prevent equipment damage, observe the following electrostatic discharge

(ESD) precautions when handling or installing the components.

•Ground yourself and the equipment to an earth or building ground. Use

a grounded workbench mat (or foam that dissipates static charge) and

a grounding wrist strap. The wrist strap should touch the skin and be

grounded through a one megaohm resistor.

•Do not touch anyone who is not grounded.

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007

10 Safety and regulatory information

•Leave all components in their ESD-safe packaging until installation, and

use only a static-shielding bag for all storage, transport, and handling.

•Clear the area of synthetic materials such as polyester, plastic, vinyl, or

styrofoam because these materials carry static electricity that damages

the equipment.

Care of ﬁber optic equipment

Fiber optic equipment must be kept clean and damage-free. Use the

information in this section to properly maintain and care for ﬁber optic

equipment.

Care of ﬁber optic equipment navigation

•"Fiber optic cable care" (page 10)

•"Fiber optic connector care" (page 11)

•"Job aid: connector cleaning tools and materials" (page 12)

•"Cleaning single SC and FC connectors" (page 12)

•"Cleaning duplex SC connectors" (page 13)

•"Cleaning receptacles" (page 13)

Fiber optic cable care

Although the glass ﬁber of ﬁber optic cable is protected with reinforcing

material and plastic insulation, it is subject to damage. Use the following

precautions to avoid damaging the glass ﬁber.

•Do not kink, knot, or vigorously ﬂex the cable.

•Do not bend the cable to less than a 40 mm radius.

•Do not stand on ﬁber optic cable; keep the cable off the ﬂoor.

•Do not pull ﬁber optic cable any harder than you would a cable containing

copper wire of comparable size.

•Do not allow a static load of more than a few pounds on any section

of the cable.

•Place protective caps on ﬁber optic connectors that are not in use.

•Store unused ﬁber optic patch cables in a cabinet, on a cable rack, or

ﬂat on a shelf.

Frequent overstressing of ﬁber optic cable causes progressive degeneration

that leads to failure.

Ethernet Routing Switch 4500 Series

Installation — SFPs and XFPs

NN47205-301 (324186-A) 01.04 Standard

5.1 6 December 2007
