Northern PTZKBD3 Bedienungsanleitung

Model: PTZKBD3

3-Axis Speed Dome

Controller Operation Manual

Version: 1.1

Please read this operation manual carefully before using this device.

3625 Cincinnati Avenue, Rocklin CA 95765 888-874-3336 www.northernvideo.com

INDEX

█

██

█

Summary ----------------------------------------------------------------------------------------2





Introduction of the Keyboard Panel

-------------------------------------------------------2

Sketch of the Front Panel and Description of Buttons

-------------------------------------2

█

██

█

Rear Panel --------------------------------------------------------------------------------------4

█

██

█

Setting of the Keyboard ----------------------------------------------------------------------4

█

██

█

Operation of the Keyboard ------------------------------------------------------------------6

█

██

█

Installation and Connection ----------------------------------------------------------------10

█

██

█

Technical Specifications ---------------------------------------------------------------------12

█

██

█

Points for Attention ---------------------------------------------------------------------------12

█

██

█

Packing List ------------------------------------------------------------------------------------12

█

██

█

Summary

◆

The keyboard controller is used for terminal receivers such as speed dome cameras.

It can be used for operating and setting up the speed dome camera. The controller can also be used to control

the terminal receiver to for controlling pan/tilt, lens and etc.

◆

Uses the EIA/RS-485 electrical interface between the keyboard and the receiver.

◆

One keyboard can control as much as 32 speed dome and decoders.

◆

The maximum communication distance between the keyboard and the receiver is up to 1.2 km.





Introduction of the keyboard Panel

Sketch of the Front Panel and Description of Buttons (Figure 1)

Figure 1

1. CALL: To call the preset position.

2. PRESET: To set the preset position.

3. SHOT: To call cruising track.

4. F1: Auxiliary control buttons.

5. F2: Auxiliary control buttons.

6. F3: Switching control between intelligent speed dome and multiplexer.

7. WIDE: Use to achieve a wide angle view.

8. TELE: Use to achieve a telescopic view.

9. FAR: To manually focus far.

10. NEAR: To manually focus near.

11. CAM/ID: Selects the address of the Speed Dome.

12. AUTO: To control auto-hori ontal rotation for pan/tilt.

13. OPEN: To open iris.

14. CLOSE: To close iris.

15. ON: Switch on the function setting.

16. OFF: Switch off the function setting.

17. FUNC: Set special function of the system together with other buttons.

18. PIP up arrow): Show picture of the camera in PIP mode (Picture-in-Picture).

19. FULL SCREEN: Show picture of the camera in full screen.

20. 3×3 left arrow): Show picture of the camera in 9-frame.

21. 2×2 down arrow): Show picture of the camera in 4-frame.

22. 4×4 right arrow): Show picture of the camera in 16-frame.

23. CLEAR: To clear inputted data.

24. 0-9: Number key.

25. Enter: To confirm selection.

26. Joystick: Control the up, down, left and right speed motion of the speed dome.

27. Power LED

28. LCD

█

██

█

Rear Panel (Figure 2)

Figure 2

Power Switch: ON/OFF.

Power input connector: input DC12V power.

Communication connector RS485.

Communication connector RJ45.

Communication connector for DVR.

6. Mode

: Used to set the protocol in use and the baud rate of communications.

Communication connector RS232.

█

██

█

Setting of the Keyboard

The protocol in use and the baud rate of communication of the keyboard are set by the MODE in

Figure 2. DIP1-DIP3 are used to select type of the communication protocol and the baud rate ,

shown as following table

◆

Some of the ID-Code of the protocols are set as follows:

◆

Switching control between speed dome and multiplexer: The controller can be operated in two

modes: Speed Dome and Multiplexer. When power supply is on it is operated on the default

mode, namely, the Speed Dome. Press

[F3]

to make switch between two modes. When it is under

the mode of the Multiplexer, you can control it via “Address Box”. At this time, the LCD will

display “Mulx Addr:001”. The RS-485 output of the keyboard cannot be used to control the

multiplexer. When operation, please pay attention to the information on the LCD.

Termination Resistor Setting

◆

The RS485 standard requires a daisy-chain connection between the equipment. There

must be termination resistor with 120 ohms impedance at both ends of the connection

(refer to the following FIGURE):

◆

Setting termination resistor by the DIP5 of the MODE

as follows:

█

██

█

Operation of the Keyboard

1. Select Address of the Speed Dome Camera

：

[CAM]+[N]+[Enter]

Display: Current Cam ID: 001

Description

：

N –– No. of camera from 0 to 255

Function: Select the address of the camera to be controlled. When the value N is in conformity with the

address of the Speed Dome Camera, it will be under control.

2. Set the Preset Position

：

[PRESET]+[N]+[ Enter]

Display: Preset No: 001

Description: N –– No. of preset position from 1 to 128.

Function: Store current position and refer to it as No. N position.

3. Call the Preset Position

：

[CALL]+[N]+[ Enter]

Display: Call Number: 001

Description: N –– No. of preset position from 1 to 128.

Function: Transfer the camera to the position of No. N preset position.

4. Cancel the Preset Position:[PRESET]+[N]+[OFF]

Display: Preset No: 001

Description: N –– No. of preset position from 1 to 128.

Function: Delete the No. N preset position stored.

5. Set the Cruise Track: (COP-2, PELCO-D, PELCO-P Available)

◆

Enter the Status of Track Setting

：

[SHOT]+[N]+ [ON] (N

：

No. of track from 1 to 6).

Display: Track = 01 Sum = 06

Description: Track No.1 is currently setting, in which there are 6 preset points.

◆

Edit Track: Press [TELE] to edit down page and press [WIDE] to edit up page. Each track involves 16 preset

points and the running speed and the dwelling time of each preset position.

Display: No: 01 Point: 001

→

Description: The 1st preset position in the track is 001.

Display: No: 01 Speed: 001

→

Description: The speed of the 1st preset point in the track is the 1st class.

Display: No: 01 Time: 004

→

Description

：

The dwelling time of the 1st preset point in the track is 4

Seconds

◆

Speed Range: 1 to 8 from the fastest to the lowest. Any speed outside the range will be referred as the 1st

class; the range of the dwelling time is: 1 to 255.

◆

When the No. N preset point is set as No. 0, then all preset points before the No. N preset point in the track

will be valid however all numbers of preset points afterward and their speed and dwelling time shall be set as

0 automatically.

◆

After tracks are edited, press OFF to store and exit while push the joystick to exit without storage.

6. Run Cruise Track: [SHOT]+[N]+ [Enter]

Display: Input Tour No: 01

Description: N –– No. of the track from 1 to 6.

Function: Tour the No. N track and stop tour by pushing the joystick.

7. Stop Cruise Track: [SHOT]+[N]+ [OFF]

Display: Input Tour No: 01

Description: N –– No. of the track from 1 to 6.

Function: Stop the No. N track or stop tour by pushing the joystick.

8. Cancel Cruise Track: [SHOT]+[N]+ [OFF] (Pressing [OFF] down until “ Clear Tour OK ”appears)

Display: Input Tour No: 01

Description: N –– No. of the track from 1 to 6.

Function: Delete the No. N track

9. Auto Pan ON (Operation of COP-2 Protocol): [AUTO]+[P1]+[ON]+[P2]+[OFF]

Display: Input 1st No: 001

Description: P1–––– the starting scan No. of preset point from 1 to 128, which should be set already.

Display: Input 2nd No: 002

Description: P2–––– the ending scan No. of preset point from 1 to 128, which should be set already.

If P1 = P2 or P1 and P2 are coincided, the speed dome will make scan in range of 360°.

Note:

(1) For PELCO-D and PELCO-P Protocols the way of operation is as follows:

◆

Set the Starting Scan Position: Transfer the speed dome to the starting scan position, operation

[AUTO]+[ON]

◆

Set the Ending Scan Position: Transfer the speed dome to the ending scan position, operation

[AUTO]+[OFF]

◆

Run Auto Pan

：

[AUTO]+[ENTER]

(2) Auto Pan operation takes the following parameters. You must set these parameters before using a

Auto Pan command to begin the scan operation. You can use the scan Stop command or PT scan stop

command to stop the scan. Setting scan condition:

◆

Auto Pan Position (First specify position, second specify position)

◆

Auto Pan Speed and Direction

10. Stop Auto Pan: [AUTO]+[OFF] (only for

COP-2

protocol)or push the joystick to stop scan.

11. Control the Zoom of the Camera: [WIDE]/[TELE]

12. Control the Focus of the Camera: [FAR]/[NEAR]

13. Control the Iris of the Camera: [OPEN]/[CLOSE]

14. Control the Vibration Correction of the Camera: [ON]/[OFF]

15. Auxiliary Control of the Camera: By combination of [F1] and [ON], [OFF] buttons, you can set some data of the

camera, and functions are listed as follows

：

16. Use the Joystick to control the speed dome camera:

You can use the speed joystick to control the Pan/Tilt direction and speed of the speed dome randomly. The speed

of pan/tilt is decided by the angle of the joystick you operated (Figure 3).

Change the tilting angle of the joystick you can adjust the speed evenly and the camera can be focused automatically

in the course of scan to keep images being distinct.

17.

Control the

NEON Video Multiplexer, as follows:

◆

Enter the Multiplexer OSD menu Press “[FUNC]+ ” enter the password [N]+[ENTER]+[N]+[ENTER]+

…

……

…

Note: system initial password is 1111.

Operation: 1+[ENTER]+1+[ENTER]+1+[ENTER]+1+[ENTER]

◆

Menu control

Press to select the menu you want,

Press F2, to enter the sub menu,

Press CAM/ID, to return the last menu

Press ON or OF , to adjust the parameters.

◆

16-frame pictures

(1) Press “ ”, Show picture of the camera in 16-frame on the monitor.

(2) Press “FUNC+ ”, Show picture of the camera in 13-frame on the monitor,and large one picture on the

center of the monitor.

◆

9-frame pictures

(1) Press “ ”, c

(2) Press “FUNC+ ”, Show picture of the camera in 8-frame on the monitor,and large one picture on the

center of the monitor.

(3) Press “ ”, to display the picture manually.

◆

4-frame pictures

(1) press “ ”, Show picture of the camera in 4-frame on the monitor.

(2) press “ ”, to display the picture manually.

(3) press “ ”, and then press “F2” to display the picture automatically.

，

if you press “F2” again,It will stop

the display the picture automatically.

◆

PIP

(1) press “ ”, Show picture of the camera on the monitor.

(2) press “ ”, and then press “F2” to display the picture automatically on the small picture display, and press

“F2”, exit the function.

◆

1-frame picture

Press “ ”, Show picture of the camera in one-frame on the monitor.

◆

SWAP pictures order

Press “[FUNC] + ” to enter the SWAP function

，

press the and to select the picture you want, and

that picture will display red on the monitor, you can press “N+ENTER” to change the picture, Press

“[FUNC] + ” again to exit the SWAP function.

18. In case error operation occurs, normal display will be recovered after “Error Operation” appears for 1 second.
