NovaJet

PRO 600e Quick Start Guide

P/N 210058-03 Rev. AA

(text P/N 210637-1, Rev. C)

ENCAD®, NovaJet®, Quality Imaging Supplies, Extreme Color Printing, and Graphic

Outdoor Matched System are trademarks of ENCAD, Inc.

Other trademarks and registered trademarks are the property of their respective

owners.

No part of this manual may be copied or distributed, transmitted, transcribed,

stored in a retrieval system, or translated in any human or computing language, in

any form or by any means, electronic, mechanical, magnetic or otherwise, or

disclosed to a third party without the express written permission of:

ENCAD, Inc., 6059 Cornerstone Court West, San Diego, CA 92121, U.S.A.

REVISION HISTORY

Rev.AA October1998

NovaJetPRO600e

2 Quick Start

Contents

Unpackingyourprinter .............................................................................3

LoadingWindowsDrivers and MacintoshENCADPrint Utility (EPU)........8

Usingthe control panel........................................................................... 10

Choosingmenufunctions .......................................................................10

Settingthelanguage ..............................................................................10

Loadingmedia........................................................................................ 11

Movingthe carriage ................................................................................ 12

Installingthe cutter ................................................................................. 12

Primingthe ink deliverylines ..................................................................15

Printing the color test ............................................................................18

Printingtheprime pattern ....................................................................... 18

Aligning the ink cartridges ...................................................................... 20

Cartridgerecognition .............................................................................. 21

QualityImagingSupplies™ ....................................................................22

ENGLISH

NovaJetPRO600e

Quick Start 3

NovaJet PRO 600e Quick Start

Congratulations on your purchase of a NovaJet PRO 600e wide format color printer. This

guide gives you details on the following:

•unpacking and assembling the printer

•loading media

•filling ink reservoirs

•installing ink cartridges

•installing the media cutter

•installing the driver software

• testing ink cartridges.

Unpacking your printer

NovaJet PRO 600e printers are shipped in three boxes. The contents are listed in the table

below.

Box 1 Box 2 Box 3

Printer with four ink reservoirs.

Accessories box which includes

the following:

•quick start guide;

•users guide, installation

instructions and software

drivers on CD-ROM;

•ink reservoirs;

•five cartridge tube needles;

•screwdriver;

•stand screws;

•loopback cable; and

•warranty card.

•Printer stand with

integrated media

feeding/takeup

mechanism;

•dryer;

•2” diameter media

cores; and

•NovaPrime.

•Four ink

cartridges;

•power cords;

•printed users

guide;

•sample m edia;

and

•one 500 ml

bottle of each

ink color (four

colors).

Before starting assembly, you should verify that all the items on the lists are present. If

not, contact your sales representative or ENCAD. You will need to provide an IEEE 1284

parallel cable for connecting to a PC or an ImageWriter II serial cable for connecting to a

Macintosh.

The printer is quite large and heavy. Two people (or a forklift) are recommended to move

the box. Before assembly, you may want to measure halls and elevators to determine

whether the unit should be assembled in the area where it will be used.

NovaJetPRO600e

4 Quick Start

Assembling the stand and printer

1 Locate the box containing the printer head and turn it upside down. Open the

box and remove the Setup box which contains the screws and screwdriver to

use for the next steps.

2 Open the box containing the stand and remove the stand and feet from the

box.

3 Note that each foot has two casters, only one of which locks. Attach the feet

to the stand legs using the screwdriver and screws provided in the setup

box. Locate the casters so that they are diagonally opposite each other.

Lock the casters to prevent the stand from rolling during subsequent assem-

bly.

4 One of the stand legs has a connector on it. Pull the connector from the

access hole in the leg and remove the tiewrap holding the connector in

place. Attach the connector to the receptacle on the bottom of the print

head. Orient the stand legs so that the roll holder brackets are facing the

center of the printer head and align with the holes in the bottom of the printer

head. Attach both stand legs to the printer head using the screwdriver and

eight screws contained in the Setup box.

CAUTION: Be careful not to pinch the cable when attaching the leg.

5 Two persons are required to lift the printer. Remove the assembled printer

and stand from the box. Save the boxes and packing materials in case you

ever need to ship the printer.

ENGLISH

NovaJetPRO600e

Quick Start 5

6 Remove the wing nut and mount the dryer assembly in the slots provided

at the base of the stand. Be sure fans will blow upward and toward the

printer. Position the dryer assembly to the desired angle. Replace and

tighten the wing nut on the left side.

7 Plug the dryer connector into the receptacle on the right stand leg.

NovaJetPRO600e

6 Quick Start

8 Attach the clamp for the grounding strap to the right lower rear edge of the

dryer assembly bracket and tighten the thumbscrew securely so that the

paint is penetrated.

9 Check to be sure that the media sensor is plugged in to the connector on

the right stand leg. You can swing the sensor mounting bracket away from

the printer if necessary when loading media.

10 To load media, slide the media roll over the feed roller. If you will be using the

takeup roller, mount an empty media core on the takeup roller before insert-

ing the roller into the stand. Mount the two rollers as shown below. Insert the

end of a roller into the space provided in the left roller support, then fit the

other end of the roller into the right support. Make sure the gear on the roller

is engaged with the gear on the support.

ENGLISH

NovaJetPRO600e

Quick Start 7

11 Slide the media guide into the media core, and secure it by tightening the

locking mechanism. If you moved the sensor mounting bracket before

loading the roll media, be sure to return it to its normal position.

Removing protective shipping material

CAUTION: Before turning on the printer, make sure to remove the protective material that

secures the carriage. Remove the protective film from the control panel and remove the

tape from the ink reservoir cover. Do not remove the foam insert located between the rear

support bracket and slide shaft on the left side of the unit. Do not remove black tape

affixed to left and right sides of the carriage assembly.

Connecting power and your computer

1 Plug the power cord into the power inlet at the rear of printer.

2 Plug the printer cable into the connector at the rear of the printer. For

connecting to a PC, use an IEEE 1284 parallel cable. For connecting to a

Macintosh, use an ImageWriter II serial cable.

NovaJetPRO600e

8 Quick Start

3 To turn on the printer, turn the power switch on at the rear of the printer. The

control panel will display the printer's model name, the firmware version,

status and progress of the power on self-test, and status and progress of the

RAM test.

Loading Windows drivers and Macintosh ENCAD Print Utility (EPU)

Before continuing, install the printer driver on your computer. The drivers are on the CD-

ROM shipped with your printer in box 1. Be sure to view the Install.txt file for installation

instructions. Details on using the driver are included in the Docs folder on the CD-ROM.

SystemRequirements:

• Microsoft Windows 95, or Windows NT v4.0 or higher.

• Intel 80386 compatible computer or better

• 32 MB memory or better

• Minimum 10 MB free hard disk space for the application and 15 MB for each of the

color tables. You will need additional space for RIPing and printing files.

ForWindows95 installation:

1 Insert the CD-ROM in your disk drive.

2 Select Start/Settings/Printers, then double-click the Add Printer icon.

3 When prompted, select 'Have Disk' then type:

<cd drive>:\drivers\Windows\(language)\95 and select OK

select 'Browse' then navigate to <cd drive>:\drivers\Windows\(language)\95

select 'OK'.

ForWindowsNT4.0 installation

1 Insert the CD-ROM in your disk drive.

2 Select Start/Settings/Printers, then double-click the Add Printer icon.

2 When prompted select 'Have Disk' then type:

<cd drive>:\drivers\Windows\(language)\NT40 and select OK

select 'Browse' then navigate to <cd drive>:\drivers\Windows\(language)\

NT40 select 'OK'.

ForMacintosh

SystemRequirements:

•PowerPC class Macintosh computer

•32MBRAMmin.

•20MB hard disk space. You will need additional space for RIPing and printing files.

ENGLISH

NovaJetPRO600e

Quick Start 9

1 Insert the CD-ROM in your disk drive and navigate to

drivers\MAC\(language)\epu and double-click the Install Print Utility icon.

2 Click Continue. Driver installation information displays. You may want to

print it at this time.

3 Click Continue and the program will prompt you with further instructions.

4 Select the port to which your printer is connected. If you are using a print

server, select AppleTalk for the port, then select the print server in the

Chooser using one of the LaserWriter drivers.

If you are not using AppleTalk, you will need a standard ImageWriter II serial

cable attached to either the printer or modem port. Attach the other end of

the cable to the RS-422 port on the printer. Refer to the instructions on the

CD-ROM for further details.

! Caution:Wider prints (60"vs 42"vs24") and600DPI prints requiresubstantial

filesizes. Youmay experience printerslowing orstalling when usingthe

Windowsdrivertoprintfrom an application,orwhenprintingafile using the

ENCADMacintoshEPU. Thenumberof print passesspecifiedwillsignificantly

impactthedata transferrequirements. Lesspasses requiremore data; conse-

quently, thereis a higher probability ofstalling whenusing lesspasses (faster

printingmodes). To do independentRIPingandprinting,orfastersimultaneous

RIPingandprinting,youmaywanttoconsiderastand-alonesoftwareorhardware

RIPproduct. AlistofRIP products thatsupportstheNovaJetPRO600ecan be

foundatwww.encad.com.

Installing the ICC Color Profiles

Note: ICC color profiles are installed automatically for the Macintosh EPU.

ENCAD Windows drivers use ICC color management profiles to provide the best

possible color match between your original source file and your final printed output.

These files, while not required, are essential to providing the maximum efficiency and

quality from your ENCAD Windows drivers. These color profiles are located in the Color

folder on the CD-ROM shipped with your printer. It is highly recommended that you

install these files prior to printing with your new printer.

1 Insert the CD-ROM into your disk drive.

2 Open the \Color folder.

3 Double click 600eicc.exe.

4 The color management files are installed in C:\Windows\system\color and

have a file extension of .icm.

NovaJetPRO600e

10 Quick Start

Using the control panel

The control panel at the right side of the printer includes eight buttons and a display

which indicates modes and settings. An overview is provided here so that you can load

media and ink cartridges. Details on menu options are included in Chapters 2, 3, and 4 in

the User's Guide. The menu tree in Appendix C of the User's Guide gives you a summary

of all the printer modes and their functions.

Two types of menus are displayed: action menus provide a list of additional menus or

immediate tasks to perform, such as Cut, Load Media, etc. Selection menus let you view

and modify values.

Choosing menu functions

To select a function, press the button adjacent the function displayed.

The display will list options available for the selected function. Press the button for the

option you want and press OK to accept the selection.

Depending on the type of menu, you can return to the previous menu level by pressing

the OK or Exit button. There is no way to immediately return to the top level menu.

Press the Cancel button to restore the previous setting and exit the menu.

Setting the language

With the appropriate firmware version, your printer can display menu items and mes-

sages in English, German, French, Italian, Portuguese, Spanish, Japanese, Chinese, or

Korean.

➪➪

➪To change the language

1 Press Setup/User Setup/Language, and select the language you want.

2 Press OK.

Inhaltsverzeichnis

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
