ASMP-36 Roll-In Rack Proofer
NU-VU®ASMP-36 Roll-In Rack Proofer
SPECIFICATIONS:
ELECTRICAL:
SERVICE CONNECTIONS:
• Unit is shipped from factory to be hard wired on site.
Single phase uses three-wire system. Three phase
uses four-wire system
• 208 or 240 Volt single phase is standard.
Please specify at time of order.
•A
1/4” waterline is required. A water softening system
should be used to minimize mineral build-up.
INSTALLATION:
Allow four inches on each side and back of unit for
ventilation of oven.
DOOR SWING: Proofer - 31-1/2” (800 mm)
PACKING SIZE:
83” High, 60” Wide, 38” Deep
(2108 mm High, 1524 mm Wide, 965 mm Deep)
SHIPPING WEIGHT:
1000 Pounds (454 Kg), FOB Menominee, MI 49858
DIMENSIONS:
Height Width Depth
Exterior 89-1/8” 61-7/8” 37-1/8”
Interior 75-5/8” 24” 32-3/4”
Per Side
Amp Draw 208/1 208/3 240/1 240/3
22 20 19 17
ELECTRICAL:
CAPACITY:
18”x26” 13”x18”
Sheet Pans Sheet Pans Spacing
Proofer 36 72 n/a
617/8”371/8”
891/8”
FRONTTOP SIDE BACK
WATER INLET
1/4” COMPRESSION ELECTRICAL
INLET
