Observer AWS3155 Bedienungsanleitung
7" Touch Screen Wireless
Surveillance System
Wireless Made Simple.
Remote Monitoring Anytime from Anywhere
User Guide
Please read these instructions completely
before operating this product.
Model AWS3155
— 1 —
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .............................................................................3
INTRODUCTION..................................................................................................................6
System Contents ...............................................................................................................6
Getting to Know Your LCD Touch Screen Monitor.............................................................7
Getting to Know Your Camera...........................................................................................8
INSTALLATION....................................................................................................................9
Installation Tips ................................................................................................................. 9
Night Vision .......................................................................................................................9
Setting Up the Monitor.....................................................................................................10
Installing the Camera(s)....................................................................................................12
SYSTEM INTRODUCTION ................................................................................................14
Live Screen and Menu .....................................................................................................14
Description of Icons .........................................................................................................15
Live Screen Displays........................................................................................................18
Zoom Feature ..................................................................................................................19
Recording Live Video.......................................................................................................20
Playing Back a Recorded Video.......................................................................................21
Deleting a Recorded Video ..............................................................................................23
SYSTEM MENU .................................................................................................................24
Camera Pairing................................................................................................................25
Turning the Camera On or Off..........................................................................................26
Adjusting Brightness........................................................................................................27
Motion Detection .............................................................................................................28
Email Alert .......................................................................................................................29
Schedule Record.............................................................................................................31
Clearing a Scheduled Recording......................................................................................33
Network Setup ................................................................................................................34
Security Code..................................................................................................................35
Network Information ........................................................................................................36
Alarm Setup – Siren Period..............................................................................................37
Alarm Setup – Siren Melody.............................................................................................38
System Setup – Power Saving.........................................................................................39
System Setup – Screen Auto Lock ..................................................................................40
System Setup – Setting the Time.....................................................................................41
System Setup – Setting the Alarm....................................................................................42
System Setup – Setting the Time Zone ............................................................................44
— 2 —
TABLE OF CONTENTS
System Setup – Storage Management.............................................................................45
System Setup – System Upgrade ....................................................................................46
System Setup – Default Language ...................................................................................47
System Setup – Frequency..............................................................................................48
Quick Tips .......................................................................................................................49
ADJUSTING THE ALARM AND OVERALL VOLUME......................................................50
REMOTE ACCESS ........................................................................................................... 51
Overview..........................................................................................................................51
Requirements for Remote View........................................................................................51
Connecting to the Internet ...............................................................................................52
Connecting to the Intranet (Home Network) .....................................................................54
Downloading the ALC Observer App ...............................................................................55
ALC Observer Android Setup Wizard...............................................................................56
ALC Observer Apple Setup Wizard ..................................................................................57
ALC Observer App Icons .................................................................................................59
To Take Snapshots..........................................................................................................62
To View and/or Take Videos ............................................................................................64
To Play Videos.................................................................................................................66
To Delete Videos .............................................................................................................69
Information Screen Options .............................................................................................71
DID Setting Screen ..........................................................................................................75
MAINTENANCE................................................................................................................ 77
Monitor............................................................................................................................77
Cameras..........................................................................................................................77
TROUBLESHOOTING...................................................................................................... 78
PRODUCT SPECIFICATIONS.......................................................................................... 80
Camera ...........................................................................................................................80
Monitor............................................................................................................................80
Memory Card Recording Time .........................................................................................80
WARRANTY...................................................................................................................... 81
— 3 —
— 2 —
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock do not remove cover (or
back). No user serviceable parts inside. Refer servicing to qualied service
personnel.
DANGEROUS VOLTAGE: The lightning ash with arrowhead, within an
equilateral triangle, is intended to alert the user to the presence of
uninsulated dangerous voltage within the product’s enclosure that may be
of sufcient magnitude to constitute a risk of electric shock topersons.
ATTENTION: The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Products with CE Marking comply with EMC Directive (2004/108/EC); Low Voltage
Directive (73/23/EEC); R&TTE(1999/5/EC); ROHS Directive (2011/65/EU) issued by
the Commission of the European Community. Compliance with these directives implies
conformity to the following European Norms:
EMC: EN 301 489 LVD: EN 60950 Radio: EN 300 328
PRODUCT SAFETY: When used in the directed manner, this unit has been designed and manufactured to ensure your
personal safety. Improper use of this product can result in potential electrical shock or fire hazards. Please read all safety and
operating instructions carefully before installation and use, and keep these instructions handy for future reference.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
FCC Compliance Statement: This device complies with Part 15 of the FCC rules. Operation is
subjected to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC/CE WARNING
This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to
Part 15 of the FCC rules and ETSI(EN) 300328. These limits are designed to provide reasonable protection
against harmful interference in residential installations. This equipment generates, uses, and can radiate
radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interference to radio or television equipment reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving Antenna.
• Move the equipment away from the Monitor.
• Plug the equipment into an outlet on a circuit different from that to which the Monitor is connected.
• Consult the dealer or an experienced radio/television technician for additional suggestions.
CAUTION: Any changes or modifications to this equipment not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
— 4 —
IMPORTANT SERVICE SAFETY INSTRUCTIONS
Damages caused by non-compliance with this operating manual will void the warranty!
1. Read and Follow Instructions - All the safety and operating instructions should be read before the
product is operated. Follow all operating instructions.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - Comply with all warnings on the product and in the operating instructions.
4. Power Sources - This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supplied to your location, consult your video
dealer or local power company.
5. Overloading - Do not overload wall outlets or extension cords as this can result in the risk of re or
electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged or cracked
wire insulation, and broken plugs are dangerous. They may result in a shock or re hazard. Periodically
examine the cord, and if its appearance indicates damage or deteriorated insulation, have it replaced
by your service technician.
6. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them. Pay particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the product.
7. Surge Protectors - It is highly recommended that the video equipment be connected to a surge
protector. Doing so will protect the equipment from damage caused by power surges. Surge
protectors should bear the UL listing mark or CSA certication mark.
8. Uninterruptible Power Supplies (UPS) - Because this product is designed for continuous, 24/7
operation, it is recommended that you connect the product to an uninterruptible power supply. An
uninterruptible power supply has an internal battery that will keep the product running in the event of a
power outage. Uninterruptible power supplies should bear the UL listing mark or CSA certication mark.
CAUTION: Maintain electrical safety. Power line operated equipment or accessories connected to this
product should bear the UL listing mark or CSA certication mark on the accessory itself and should not be
modied so as to defeat the safety features. This will help avoid any potential hazard from electrical shock or
re. If in doubt, contact qualied service personnel.
Recycling and Disposal Information:
• Do not dispose of electronic devices or any of their components (especially
batteries and LCD displays) in your municipal trash collection.
• Consult your local waste management authority or a recycling organization like
Earth911.com to nd an electronics recycling facility in your area.
CAUTION: Rechargeable batteries must be recycled or disposed of properly.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
STRANGULATION HAZARD: Infants have STRANGLED in power cords. Keep power cords more than 3 feet away from
cribs, bassinets, play yards, and other safe sleep environments for infants.
— 5 —
— 4 —
IMPORTANT SAFETY INSTRUCTIONS
9. Ventilation - Slots and openings in the case are provided for ventilation to ensure reliable operation of
the product and to protect it from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the video equipment on a bed, sofa, rug, or other similar
surface. This product should never be placed near or over a radiator or heat register. This product
should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided and the product manufacturer’s instructions have been followed.
10. Attachments - Do not use attachments unless recommended by the product manufacturer as they
may cause a hazard.
11. Water and Moisture - Do not use receivers or video monitors near water — for example, near a bath
tub, wash bowl, kitchen sink or laundry tub, in a wet basement, near a swimming pool and the like.
12. Heat - The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including ampliers) that produce heat.
13. Accessories - Do not place this video equipment on an unstable cart, stand, tripod, or table. The
video equipment may fall, causing serious damage to the product. Use this product only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer or sold with the product. Any
mounting of the product should follow the manufacturer’s instructions and use a mounting accessory
recommended by the manufacturer.
14. Camera Extension Cables - Check the rating of your extension cable(s) to verify compliance with your
local authority regulations prior to installation.
15. Mounting - The cameras provided with this system should be mounted only as instructed in this guide
or the instructions that came with your cameras, using the provided mounting brackets.
16. Camera Installation - Cameras are not intended for submersion in water. Not all cameras can be
installed outdoors. Check your camera’s environmental rating to conrm if it can be installed outdoors.
When installing cameras outdoors, installation in a sheltered area is recommended.
— 6 —
System Contents
After unpacking, you will have the following items:
Camera x 2
Screw/Anchor Kit x 2Extension Cable x 2
AC Adapter x 3
Quick Start Guide x 1
Internet Cable x 1
Monitor x 1
Camera Bracket x 2Antenna x 2
Wireless Made Simple.
Please read these instructions completely
before operating this product.
7” Connected
Touch Screen Wireless
Surveillance System
Remote Monitoring Anytimefrom Anywhere
Quick Start
ModelAWS3266
INTRODUCTION
Micro SD Card x 1
— 7 —
— 6 —
Getting to Know Your LCD Touch Screen Monitor
INTRODUCTION
Monitor
Touch Screen
Microphone
Signal
Indicator
Power
Indicator
Antenna
Micro SD
Card Slot
Stand
Reset Button
Internet Jack
Power Jack
Speaker
Power Button
FRONT
REAR
— 8 —
INTRODUCTION
Getting to Know Your Camera
Cover
FRONT
REAR
Mounting
Socket
Power Status
LED
Antenna
Connector
Mounting
Socket
Link Status
LED
Power
Pigtail
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Beliebte Sicherheitssystem Handbücher anderer Marken
EDM
EDM Solution 6+6 Wireless-AE Bedienungsanleitung
Highway Safety Group
Highway Safety Group EA401 Bedienungsanleitung
Siren
Siren LED GSM Bedienungsanleitung
Detection Systems
Detection Systems 7090i Montageanleitung
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung
Siemens
Siemens FDM273 Bedienungsanleitung
