Internet Radio

User Manual

WR-220

Please read this user manual carefully before using the receiver.

Contents

Location of Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connect the radio with your Wi-Fi Router . . . . . . . . . . . . . . . . . 4

Start using internet radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

My Favorite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Internet Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Media Centre. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Alarm Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Add your favorite URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Music Streaming from mobile devices . . . . . . . . . . . . . . . . . . . 12

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Helpful Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Technical Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Front

Back

Location of Controls

1. LCD Display

2. Dial Control

- Rotate the dial to adjust volume level

Adjust LCD backlight level under

Standby

Push the dial to confirm / select

menu options

- Push to stop/resume playback of the

radio

3. Speaker

4. On/off

- Press to power on/ Standby

5. Local

- Quick access the local stations in

your country

6. Menu

- Press to enter menu

7. Preset

- Long press to store the station to

Favorite list

- Press briefly to recall the favorite

station

8. Left

- Back to previous menu

- Left cursor

9. Right

- Right cursor

- Enter edit menu under Favorite list

10. Earphone jack

11. Line Out jack

12. DC IN jack

3 4 5 6 7 8 9 10

11 12

Remote Control

1. Power: Standby on/off

2. Mute: Speaker on/off

3. 0-9: Input numbers for encryption code, recall

favorite stations, enter index number to select

item from the list

Toggle the same numeric key gives you a

choiceto input letters

4. : Return to Main Menu

5. Mode: Switch between Internet radio and Media

Centre

6. Alarm: Alarm Setting

7. : Preset the current playing station to Favorite

8. : Recall the favorite station

9. Local: Access radio stations in your local country

10. Cursor up

11. $Cursor down

12. Cursor left/Back

13. Cursor right

14. Info: Access the network and system information

15. Enter: Confirm selection

16. : Next (next item in the list: next station, next

track)

17.: Previous (Previous item in the list: previous

station, previous track)

18. Volume +: Increase volume

19. Volume -: Decrease volume

20. Sleep: Sleep Timer setting

Before you start

Please ensure the following is ready:

You have a broadband internet connection.

A wireless broadband router is connected to the internet successfully.

The radio supports Wireless B, G and N connection (Wireless N router can also be used with

the setting on B or G).

You know the Wired Equivalent Privacy (WEP) or Wi-Fi Protected Access (WPA) data

encryption code/password. You need to key in the correct code when the radio is connected

to the wireless router for network connection.

If you do not know the code/password, please contact the person /technician who set up the

router/network for you.

The radio can work via Wireless network connection (Wi-Fi connection)

Precautions

The radio should not be used in a high temperature or high humidity environment over

prolonged periods of time as this may damage the unit.

Keep the radio away from liquids as it may get damaged. Please switch off the radio

immediately if water or liquids is spilled into the radio. Consult with the shop you bought this

radio for any question.

Avoid using or storing the unit in dusty or sandy environment.

Do not open and repair the radio by yourself.

Use only the AC adaptor supplied with the radio.

Connecting a power supply with a different rating will cause permanent damage to the radio

and may be hazardous.

Clean only with dry cloth.

Connect the radio with your Wi-Fi Router

1. Insert the adaptor plug into the DC socket located at the rear side of the radio.

Plug the adaptor into a wall socket outlet.

Caution: Use only the adaptor supplied with the radio. Connecting a power supply with a

different rating will cause permanent damage to the radio and may be hazardous.

2. The radio will power on and display as follow. Choose <Yes> to start configuring network.

3. Select <Add/Remove AP> and <Add AP>:

4. It will start scanning the available Wi-Fi routers nearby. Choose to connect your AP and

enter the encryption code. Press ‘Enter’ to confirm.

Remark: The encryption codes are case sensitive to upper and lower case.

5. When the Wi-Fi connection is done, the display shows:

Connecting to Network

>>>>>>>

Configure Network?

<Yes> No

Welcome

Add/Remove AP

AP:[ ]

Add AP

Remove AP

Association complete

When this symbol appears, the radio is

trying to connect to the Wi-Fi network

Skytune

< 1/6 >

01:42AM

If you try to select Skytune when the Wi-Fi

network is not connected, it will show the

message below:

Skytune not connected,

retry later

After the Wi-Fi network is connected,

you will see the Wi-Fi signal bar here.

1. fm Bay Smooth Jazz

H2 ch

< 18/11225 00:25

iRadio

Start using internet radio

Press <Menu> to return to the main menu or the key on the remote controller. You will see

the item list below:

<My Favorite>- To show the list of favorite stations which have been assigned to the presets.

There are up to 99 presets available.

<Internet Radio>- Start exploring the worldwide radio stations and music here

<Media Centre>- Music streams from the UPnP servers/ devices under the same Wi-Fi

network

<Alarm>- Setting of Alarms

<Sleep Timer>- You can set the timer to turn the radio standby after certain time elapsed

<Configuration>- More settings available for you to configure the radio as you desire

My Favorite

This is to show the list of your Favorite stations which have been assigned to the presets.

¢ Preset a station

While you are playing a radio station, press the button on the remote controller or long

press the <Preset> key on the unit, you will see the icon appears as below. It means the

station is added to the Favorite list.

The new added station will always showing in the last item on the Favorite list.

You can store up to 99 presets

¢ Recall a station

Press the button on the remote controller or press the <Preset> button briefly on the unit to

recall the Favorite list. You can enter the Index number to quickly scroll to the radio station you

want to listen.

e.g., On the remote controller, press 2 8 and Enter, it will scroll to the station no. 28.

¢ Edit your favorite list

On the Favorite list, choose the radio station you want to edit then press the right "key on the

My Favorite

Media Centre

Alarm

Sleep Timer

Configuration

Internet Radio

1. fm Bay Smooth Jazz

128kbps, 44100 Hz, 2 ch

< 1/1 00:39

HISTORY

Preset icon

remote controller. It will enter the Edit menu with the following options:

Move down – To move down the ranking of a station

Move up – To move up the ranking of a station

Delete – To delete a particular station

Internet Radio

On the main menu, choose <Internet Radio> and you will find the options below:

Skytune

Select Skytune to start enjoying thousands of radio stations over the world. You can filter your

search by Region, Music genre and talks. The <Local Radio> let you access quickly the

stations available in your local area.

You can change the Local Radio area under Configuration> Local radio setup.

Instead of browsing the radio station list, you can access the desired station by performing

search and input the name of the station.

History

The radio will memorize the stations you have listened on the radio. It can memorize up to 99

stations.

If you have listened more than 99 stations, it will supersede the first station that you have

listened.

Media Centre

UPnP (Universal Plug and Play)

You can stream music from the Networked device which supports UPnP function. For

instance, most of the latest computer laptop supports UPnP, and you can stream music from

Windows Media Player application on the computer and listen on your radio.

1. If your PC is running Microsoft Windows XP, then you can use Windows Media Player

11(WMP11) to act as your UPnP( Universal Plug and Play) media server. (For Windows 7 or

above, please download the correspond version of Windows Media Player). Windows Media

Player 11 may be downloaded from Microsoft’s website and install by following the

instructions detailed in its installation wizard.

2. Once installed, Windows Media Player 11 will create a library from all the media files

available to it on your PC. To add new media files to the library, select’ File > Add to

Library…> Advanced Options’, Click ‘Add’ and choose the files you wish to add and click’

OK’.

Skytune

History

Local Radio

Globe All

Globe By Genre

Globe By Region

3. Now you need to connect your Internet radio to Windows Media Player 11 and configure it to

allow the radio to access your media library. In order to this , you will need to do the

following:

a. Go to the main menu of the radio, select <Media Player>g<UPnP>.

b. It will scan for all available UPnP servers . Note, this may take a few seconds for the

radio to complete its scan and before the scan has completed, the radio will display

‘[Empty]’. The radio will continue to display ‘[Empty]’ if no UPnP servers and found.

c. After a successful scan. Select your UPnP server, by rotating the dial if there is more

than one UPnP server, and then press SELECT (note, your radio will display’ Access

Denied’ at this stage)

4. Your PC will now prompt you that a device has attempted to connect to your UPnP server. In

order to allow the radio to have access to the media files, you will need to click the ‘Library’

tab from Windows Media Player 11 and select the <Media Sharing> item to open the ‘Media

Sharing’ window.

Selecting ‘Media Sharing…’ for Windows Media Player11:

5. From the ‘Media Sharing’ windows , the radio will be listed as an unknown device. Click on

the unknown device listed, then click the ‘Allow’ button and then click ‘OK’. Allowing the

Radio to Connect:

Music streaming via UPnP

1. Once the UPnP server is configure to share media files with your radio, you can start music

streaming.

2. On the main menu, select <Media Centre> and choose <UPnP>

3. It may take a few seconds for the radio to complete the scan for available UPnP servers. If

no UPnP servers are found, it will show <Empty List>.

4. After a successful scan is done, select your UPnP server.

5. The radio will show the media categories available from the UPnP server, e.g. ‘Music’,

‘Playlists’ etc.

6. Choose the media files that you wish to play.

You can set the mode of playback under <Configuration g Playback setup>.

My Playlist

You can make you own playlist for the UPnP music files. Choose the song you want to add to

playlist, long pressing the Dial until the sign appears. The song will be added to “My

playlist”. You can add up to 99 songs to “My Playlist”.

The UPnP playlist will be erased when the radio is powered off.

Clear My Playlist

Remove all songs in “My Playlist” to allow a new playlist to be prepared.

Alarm Setting

1. Choose <Alarm> from the main menu or press the <Alarm> button on the remote controller.

2. Select either Alarm 1 or Alarm 2, and choose <Turn on> to activate the Alarm.

3. Follow the alarm wizard instructions to set the alarm.

The wizard will guide you through the settings below:

Time – Set the time for the alarm

Sound – You can choose <Wake to Radio> or <Wake to Melody> for the alarm sound.

¢ Wake to Radio – only the preset stations can be used for the radio alarm (stations from

Favorite list).

Please preset your favorite station before setting the alarm.

¢ Wake to Melody- The Melody is default by system.

Repeat – You can schedule the alarm as you desire – Everyday, Once or multiple days.

Alarm Volume – Adjust the volume of the alarm as you like by rotating the dial.

4. After the above settings are completed, press the left !button to exit and make sure the

Alarm is turned on. You will see the Alarm icon appeared on the display if it is activated.

Inhaltsverzeichnis

Andere Ocean Digital Radio Handbücher

Ocean Digital

Ocean Digital WR-238CD Bedienungsanleitung

Ocean Digital

Ocean Digital WR-03 Bedienungsanleitung

Ocean Digital

Ocean Digital MA-80 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-336F Bedienungsanleitung

Ocean Digital

Ocean Digital DB-330 Bedienungsanleitung

Ocean Digital

Ocean Digital DB-280C Bedienungsanleitung

Ocean Digital

Ocean Digital WR-210CB Bedienungsanleitung

Ocean Digital

Ocean Digital WR-210CB Bedienungsanleitung

Ocean Digital

Ocean Digital WR-230S Bedienungsanleitung

Ocean Digital

Ocean Digital WR-280S Bedienungsanleitung

Ocean Digital

Ocean Digital wr-282cd Bedienungsanleitung

Ocean Digital

Ocean Digital WR-280 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-300 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-100F Bedienungsanleitung

Ocean Digital

Ocean Digital WR-233 Bedienungsanleitung

Ocean Digital

Ocean Digital DK-70 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-800F Bedienungsanleitung

Ocean Digital

Ocean Digital DB-230B Bedienungsanleitung

Ocean Digital

Ocean Digital WR-230 Bedienungsanleitung

Ocean Digital

Ocean Digital DB-220B Bedienungsanleitung

Ocean Digital

Ocean Digital WR-880N Bedienungsanleitung

Ocean Digital

Ocean Digital WR-23F Bedienungsanleitung

Ocean Digital

Ocean Digital DB-332 Bedienungsanleitung

Ocean Digital

Ocean Digital WR-230SF Bedienungsanleitung

Beliebte Radio Handbücher anderer Marken

EisSound

EisSound KBSound iSelect Bedienungsanleitung

Midland

Midland 1001LWX Bedienungsanleitung

Konig

Konig HAV-SR41 Bedienungsanleitung

Roberts

Roberts exprssion Bedienungsanleitung

VDigi

VDigi DD3.0 Bedienungsanleitung

Radio Shack

Radio Shack 21-1863 Bedienungsanleitung

Roberts

Roberts Stream 207 Bedienungsanleitung

Sony

Sony Walkman SRF-M97 Bedienungsanleitung

Stanley

Stanley FatMax FMC770 Bedienungsanleitung

auna

auna DAB-Radio 10026947 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER UR190 Bedienungsanleitung

HYT

HYT TC-320 Bedienungsanleitung

auna multimedia

auna multimedia Yellowstone 10026851 Bedienungsanleitung

B-Tech

B-Tech GMRS-V2 Bedienungsanleitung

Weierwei

Weierwei VEV-V8 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER DAB750 Bedienungsanleitung

Telefunken

Telefunken TF-1505 Bedienungsanleitung

Makita

Makita LXRM03 Bedienungsanleitung
