INTRODUCTION
KMS heating controllers are state of the art microprocessor controlled devices, manufac-
tured in digital and SMT technology. KMS is intended for regulating single boiler heating
systems, remote heating, heat pump and bivalent heating systems. It is used for radiator,
floor or convector heating as well as for d .h. w. warming. The controller has a digital mul-
tichannel weekly programmable clock built-in which is used for timed programming of
room and d. h. w. warming.
The KMS controllers are ensuring the maximum comfort and energy saving.
Heating controller
KMS
For the initial setup in three steps, see the »Settings manual« on page 20.
Heruntergeladen von manualslib.de Handbücher-Suchmachiene
GB
7
CONTENTS
USER MANUAL
Description........................................................................................................................8
Graphic LCD display .........................................................................................................9
Operation mode and temperature setting........................................................................16
SETTINGS MANUAL
Three step setup .............................................................................................................20
Menu...............................................................................................................................23
Program timer..................................................................................................................25
Controller parameters settings........................................................................................26
Basic parameters .........................................................................................................29
Mixing heating circuit....................................................................................................30
Direct heating circuit.....................................................................................................30
Domestic hot water.......................................................................................................31
Heat sources................................................................................................................32
Basic controller settings ..................................................................................................33
Default settings................................................................................................................34
Controller data.................................................................................................................34
SERVICE SETTING MANUAL
Service settings...............................................................................................................35
Description of operation and additional possibilities........................................................45
Automatic temperature sensor detection.........................................................................54
INSTALLATION MANUAL
Safety precautions...........................................................................................................55
Controller installation.......................................................................................................55
Technical data.................................................................................................................66
Declarations and statements...........................................................................................67
Hydraulic and electric schemes.....................................................................................133
Notes.............................................................................................................................167
Heruntergeladen von manualslib.de Handbücher-Suchmachiene
8
User manual
GB
USER MANUAL
1 - burner
- heat pump
2 - circulation pump of the direct heating circuit
UWP2
- circulation pump for d. h. w. circulation BCP
- circulation pump for sun collectors KTP
- boiler switching
3 - circulation pump of the mixing heating circuit
UWP
- circulation pump for d. h. w. circulation BCP
- circulation pump for sun collectors KTP
4 - opening of the mixing valve (M+)
5 - closing of the mixing valve (M-)
6 - circulation pump for d. h. w. warming BLP
1 - tightening screws
2 - LCD display
3 - setting the steepness of the heating
curve (MC* or DC** )
4 - setting the minimum temperature of
solid fuel boiler
- setting the start-up temperature
difference for sun collectors
- setting steepness of the heating
curve (DC** )
5 - setting the minimum temperature of
liquid fuel boiler
6 - info / Esc key
7 - navigation button for operating the
display
8 - setting the required day
temperature
9 - setting the required night
temperature
10 - switch for selecting the mode of
operation
11 - setting the d. h. w. temperature
2 5 6 7 1
1 8 9 10 11
34
DESCRIPTION
KMS FRONT PANEL
KMS INDICATORS OF OPERATION
If signal lamps 1, 2, 3, and 6 are flashing, that means, that a delay time to
switch off the indicated device is active.
5
2
1
3
4
6
**MC - mixing heating circuit
**DC - direct heating circuit
Heruntergeladen von manualslib.de Handbücher-Suchmachiene
GB
9
User manual
GRAPHIC LCD DISPLAY
DESCRIPTION OF SYMBOLS ON DISPLAY
Display of inside (room) temperature for MC - mixing heating circuit
(RF).
Display of inside (room) temperature for DC - direct heating circuit (RF).
Outdoor temperature display (AF).
Mixing circuit stand-pipe temperature display (VF).
Mixing circuit return-pipe temperature display (RLF).
Direct circuit stand-pipe temperature display.
Liquid fuel boiler temperature display (KF).
Return-pipe temperature return in the solid fuel boiler display (RLKF).
D. h. w. temperature display (BF1/BF2).
Solid fuel boiler temperature display (KF2).
Floor temperature display (EF).
D. h. w. circulation pipe temperature display (BF3).
Exhaust gas temperature display (AGF).
Heat accumulator temperature display (SF).
Sun collectors temperature display (KTF).
Measured temperature display.
Calculated or required temperature display.
Sensor error display (short circuit, open contact).
Symbols for temperature display:
Heruntergeladen von manualslib.de Handbücher-Suchmachiene
10
User manual
GB
Symbols for heating circuits
Mixing heating circuit - MC.
Direct heating circuit - DC.
D. h. w. warming.
D. h. w. circulation.
Time programs
Time programs for room heating P1 and P2.
Time program for d. h. w. warming.
Time program for d. h. w. circulation.
Time program for anti legionella function.
Switch off.
Heating turned on - automatic heating mode.
Day temperature heating operation mode.
Night temperature heating operation mode.
Manual operation.
D. h. w. warming or circulation - permanent switch on.
D. h. w. warming circulation - permanent switch off.
Room heating with time program on night temperature.
Symbols for operation mode indication
Room heating with time program on day temperature.
