CENTER TWO

CENTER THREE

Multi-Channel Controller

Operating Manual GA 09.035/6.02

Cat. No.

230 003

230 004

235 003

235 004

2GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.1 Validity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.3 Product versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.1 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2 Mains connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4 Switching functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.6 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.7 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.2 Mechanical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.3 Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.1 Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.2 Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.3 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.4 Measurement mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.5 Parameter mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5.1 Switching function parameters (PArA SP). . . . . . . . . . . . . . . . . . 36

5.2 Sensor parameters (PArA SEn) . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.3 General parameters (PArA GEn) . . . . . . . . . . . . . . . . . . . . . . . . . 47

5.4 Test parameters (PArA tESt). . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

6 Computer interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

6.1 Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

6.2 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Contents

GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum 3

6.3 Mnemonics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

7 Maintenance and service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

7.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

7.2 Program transfer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

7.3 Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

8.1 Fault indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

8.2 Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

8.3 Technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

9 Storage and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

9.1 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

9.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

9.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Default parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Literature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

4GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum

Introduction

1 Introduction

1.1 Validity

1.1.1 Catalog number

This document applies to the following products:

The catalog number can be found on the type label which is attached to one

side of the unit.

1.1.2 Firmware version

This Operating Manual is based on the firmware version 302-533-F.

If the unit does not work as described, please check if it is equipped with this

firmware version. See Chapter 5.4.2 Firmware version (Pnr), 52.

1.1.3 Type label

There is a type label attached to one side of the unit. In all communication with

Oerlikon Leybold Vacuum, please state the information on the type label. For

this purpose you may want to copy the information into the space provided

below:

Fig. 1-1 Type label (example)

Catalog number Product

230 003 CENTER THREE with mains cable,

EUR version

230 004 CENTER TWO with mains cable,

EUR version

235 003 CENTER THREE with mains cable,

US version

235 004 CENTER TWO with mains cable,

US version

Introduction

GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum 5

1.2 Intended use

The CENTER TWO and CENTER THREE Multi-Channel Controller is a dis-

play and control unit for transmitters made by Oerlikon Leybold Vacuum.

It is used together with transmitters of the THERMOVAC, PENNINGVAC,

CERAVAC and IONIVAC series and is used for total pressure measurements.

The transmitters must be operated in accordance with their respective operat-

ing manuals.

In the following, the CENTER TWO or CENTER THREE Multi-Channel Con-

troller will be referred to as «Multi-Channel Controller».

1.2.1 Liability and warranty

Oerlikon Leybold Vacuum assumes no liability and the warranty becomes null

and void if the end user or third parties

Disregard the information in this document

Use the product in a non-conforming manner

Make any kind of alterations (modifications, repair work, etc.) to the product

Use the product with accessories not listed in the corresponding product

documentation

We reserve the right to make technical changes without prior notice. The fig-

ures are non-committal.

1.3 Product versions

The Multi-Channel Controller is available in two different versions: CENTER

TWO and CENTER THREE. The two products differ from each other with

regard to:

Number of channels

Number of switching functions

Power consumption

Weight

See Chapter 2 Technical data, 9.

This Operating Manual describes both the CENTER TWO and the CENTER

THREE.

6GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum

Introduction

1.4 Safety

1.4.1 Personnel qualifications

All work described in this document may only be carried out by persons who

have suitable technical training and the necessary experience or who have

been instructed by the end user of the product.

1.4.2 Illustration of residual dangers

This Operating Manual illustrates safety notes concerning residual dangers as

follows:

«Danger» indicates an imminently hazardous situation which, if not avoid-

ed, will result in death or severe injury.

«Warning» indicates a potentially hazardous situation which, if not avoided,

could result in death or severe injury.

«Caution» indicates a potentially hazardous situation which, if not avoided,

may result in moderate or minor injury or in property damage.

Note:

A note such as this one indicates particularly important, but not safety-

relevant information.

Danger

Warning

Caution

Introduction

GA 09.035/6.02 - 07/2011 - © Oerlikon Leybold Vacuum 7

1.4.3 General safety instructions

For all work you are going to do, adhere to the applicable safety regulations.

Also observe all safety notes given in this document and forward the informa-

tion to all other users of the product.

In particular, pay attention to the following safety notes:

Mains power.

The Multi-Channel Controller contains parts which are connected to the

mains supply.

Make sure that no objects enter through the louvers of the unit. Keep the

unit dry. Do not open the unit.

Fig. 1-2 Do not insert objects through louvers and keep unit dry

Improper use.

Improper use can damage the Multi-Channel Controller.

Use the Multi-Channel Controller only as intended by the manufacturer.

See Chapter 1.2 Intended use, 5.

Improper installation and operation data.

Improper installation and operation data may damage the Multi-Channel

Controller.

Strictly adhere to the stipulated installation and operation data.

Danger

Caution

Introduction

1.4.4 Disconnecting device

The Multi-Channel Controller is equipped with a disconnecting device accord-

ing to EN 61010-1.

The disconnecting device is located at the back of the Multi-Channel Control-

ler. See Fig. 1-3, 8.

The disconnecting device must be readily identifiable and easily reached by

the user.

In order to disconnect the Multi-Channel Controller from mains, you must

unplug the mains cable.

Fig. 1-3 Back side of the CENTER THREE

A Disconnecting device

Technical data

2 Technical data

2.1 General data

2.1.1 Mechanical data

Fig. 2-1 Dimensions (in mm)

Dimensions Width: 106.3 mm

Height: 128.5 mm (3 HE)

Depth: 207 mm

See Fig. 2-1, 9

Weight CENTER TWO:

1.04 kg

CENTER THREE:

1.16 kg

Use Desktop unit

Control panel mounted

Mounting the unit in a rack

106.3

91.4 3.5

122.5

128.5

103

110

285

204.5 2.5
