Oki C9200 Service-Handbuch

Contents

Ordering Replacement

Supplies ........................................ 2

Loading Print Media .................... 3

Print Media .................................... 5

Standard Paper................................ 5

Recycled Paper ............................... 6

Matte Photo .................................... 7

Labels ............................................. 8

Transparencies................................ 9

Thick Paper (Cards, Index) .......... 10

Changing Default Media

Settings ....................................... 12

Walk-Up Functions ..................... 14

Secure Print .................................. 14

Proof & Print ................................ 15

Color Balance Adjust ................... 16

Print the MenuMap ...................... 17

Print a Demo Page........................ 17

Print the File List.......................... 17

Power Save Settings ..................... 18

Control Panel Buttons

& Lights ....................................... 19

Clearing Paper Jams .................. 23

Paper Feed Jam............................. 23

Transport Jam ............................... 24

Exit Jam........................................ 25

Tray X Jam ................................... 27

MP Tray Jam ................................ 28

Duplex Paper Jams ....................... 28

Changing Toner Cartridges ......31

Error Messages ........................... 34

Service & Support.......................37

For more information,

see the on-line OKI C9000 Series

Desktop User’s Guide

(click Start ®Programs ®

OKI C Series ®

Desktop User’s Guide).

Image Drums

Black..................OKI #41514708

Cyan ..................OKI #41514707

Magenta .............OKI #41514706

Yellow................OKI #41514705

Fusers

120 V .................OKI #41531401

230 V .................OKI #41531403

Order Numbers

Toner Cartridges

Black..................OKI #41515208

Cyan ..................OKI #41515207

Magenta .............OKI #41515206

Yellow................OKI #41515205

Transfer Belt

Transfer Belt......OKI #41531501

Ordering Replacement Supplies

How to Order

• Consult the dealer where you purchased your printer.

• Consult an Oki Data Authorized Sales or Service

Dealer. (Call 1-800-OKI-DATA [1-800-654-3282] for

the nearest Authorized Sales and Service location.

Have your ZIP code ready.)

•U.S., Puerto Rico, Guam, and U.S. Virgin Islands only:

Order on the Internet http://www.okidata.com.

•U.S. only: Order toll-free at 1-800-OKI-DATA, using

VISA®, MasterCard®or American Express®. $10.00

minimum purchase required.

• Check office supply catalogs or your local stationery

store. Most carry OKI brand supplies.

Take Advantage of

OKI’s Supply Manager

Don’t run out of supplies again!

• Calculates your usage based on

information you provide.

• Sends you an email reminder

when it’s time to reorder.

As easy as 1-2-3:

1. Go to http://www.okidata.com.

2. Click Buy Online.

3. Click the Supply Manager icon

and register directly on line!

Loading Print Media

and change the media

indicator:

3. If loading paper, fan it.

Tray 1, Auxiliary

Trays & High

Capacity Feeder

1. Pull the tray out.

2. If necessary, adjust the

media guides:

(Legal size and larger only):

4. Load the print media, print

side down, keeping the stack

below the PAPER FULL

mark (1), then gently push

the paper tray back into the

printer.

!Letterhead stationery

(letter, A4 or B5 size):

Long edge feed—load with

the top aimed toward you:

Short edge feed—load with

the top to the right:

4. If loading paper, fan it.

5. Place the media print side up

on the tray.

Loading Print Media (cont.)

Multi-Purpose Tray

1. Open the Multi-Purpose

Tray.

2. Adjust the guides for the

media you are using. !Letterhead Stationery

(Letter, A4 or B5):

Long edge feed, load with

top aimed toward the back

of the printer:

Short edge feed, load with

top nosed into the printer:

Transparencies & Labels:

Print side up. (Remember,

default = long edge feed.)

Envelopes:

Flap down and nosed into

the printer:

Print Media

Standard Paper

Recommended

Letter

• HammerMill®Laser,

24 lb.*

• Xerox®

- 4024, 20 lb.*

- 4024DP, 20 lb.*

- Xpressions, 24/28/32 lb.*

- Color Xpressions, 24 lb.*

Legal

• Xerox 4024DP, 20 lb.*

Weight Range

• 16 to 54 lb. US Bond

(60 to 200 g/m2)

!Duplex printing: paper

only, 20 to 28 lb US bond.

If you experience curling

in duplex mode with 20 or

24-lb. paper, switch to

28-lb. US Bond.

Tabloid

• HammerMill Laser, 24 lb*.

• Wausau Exact®Color Copy,

28 lb.*

Usable Sizes

• Tabloid, Tabloid Extra

• Letter, Executive

• Legal-14, -13.5, -13

• A3 Nobi**, A3 Wide, A3,

A4, A5, A6**

• B4, B5

• Custom** (MP Tray only,

must be defined in driver)

Feed Paths

• Tray 1 (range to 47 lb US

Bond)

• Multi-Purpose Tray (range

to 110 lb Index or 54 lb. US

Bond)

• Tray 2 or 3 (optional, range

to 47 lb. US Bond)

• High Capacity Feeder

(optional, range to 47 lb. US

Bond)

Exit Paths

• Top (up to 47 lb. US Bond

max.)

• Straight-Through (up to 54

lb. US Bond max.): required

when using Multi-Purpose

Tray

* US Bond ** Not for duplex printing

Print Media (cont.)

Recycled Paper

Recommended

Letter Size

• Great White®Recycled

Content 86100, 24-lb.*

• Weyerhaeuser®Husky Zero

Copy 3108 20 lb.*

• Xerox®Recycled, 3 Holes,

20 lb.*

Usable Sizes

• Tabloid, Tabloid Extra

• Letter, Executive

• Legal-14, Legal-13.5,

Legal-13

• A3 Nobi, A3 Wide, A3, A4,

A5, A6

• B4, B5

• Custom (MP Tray only;

must be defined in the driver)

Weight Range

• 16 to 54 lb. US Bond

(60 to 200 g/m2)

!Recycled paper is slightly

thicker than non-recycled

paper of the same paper

weight (ream weight). If

the toner is not fusing

properly, change the Media

Weight to the next higher

setting.

Feed Paths

• Tray 1 (range to 47 lb US

Bond)

• Multi-Purpose Tray (range to

110 lb Index or 54 lb. US

Bond)

• Tray 2 or 3 (optional, range

to 47 lb. US Bond)

• High Capacity Feeder

(optional, range to 47 lb. US

Bond)

Exit Paths

• Top (up to 47 lb. US Bond

max.)

• Straight-Through (up to 54

lb. US Bond max.): required

when using Multi-Purpose

Tray

* US Bond

Print Media (cont.)

Matte Photo

Usable Sizes

• Tabloid, Tabloid Extra

• Letter, Executive

• Legal-14, -13.5, -13

• A3 Nobi, A3 Wide, A4, A5,

• B4, B5

• Custom (MP Tray only;

must be defined in the driver)

Weight Range

• 20 to 54 lb. US Bond

(75 to 200 g/m2)

Feed Paths

• Tray 1 (range to 47 lb US

Bond)

• Multi-Purpose Tray (range to

110 lb Index or 54 lb. US

Bond)

• Tray 2 or 3 (optional, range

to 47 lb. US Bond)

• High Capacity Feeder

(optional, range to 47 lb. US

Bond)

Exit Paths

• Top (up to 47 lb. US Bond

max.)

• Straight-Through (up to 54

lb. US Bond max.): required

when using Multi-Purpose

Tray

Labels

Precautions

• Use label sheets designated

for laser printers.

• Labels must be able to

withstand 392°F (200°C) for

0.1 second.

• Labels must cover the entire

carrier sheet.

• Label adhesive must not be

exposed; if it is, it will cause

jamming in the printer.

Print Media (cont.)

For Individual Print

Jobs

Make the following settings in

the printer driver as you print

the job:

•Source = MP Tray

•Size = Letter or A4

•Type = LABEL1 (Heavy) or

LABEL2 (Ultra Heavy)

•Windows®Adobe®

PostScript®driver only:

Paper Size Check (usually

under Paper Source

Options) = Deselected (Off)

Making Labels the

Default

If the MP Tray will normally

be loaded with labels, set the

printer menu as follows (see

page 12):

•MP Tray PaperSize = Letter

or A4

•MP Tray MediaWeight=

Heavy (LABEL1) or Ultra

Heavy (LABEL2)

Usable Sizes

• Letter, A4

Feed Path

• Multi-Purpose Tray only

Exit Path

• Straight-Through Only

Maximum depth of label sheet

feed stack: about

3/8-inch (10 mm)

Print Media (cont.)

Transparencies

Caution!

Transparencies must be

able to withstand 392°F

(200°C) for 0.1-second.

Recommended

•3M

®CG3720 (Letter)

• Folex®BG67 (A4)

Usable Sizes

• Letter, A4

• Tabloid, Tabloid Extra

Feed Paths

• Tray 1 (up to 250, print side

down)

• Multi-Purpose Tray (up to

50, print side up)

!Transparencies can not be

fed from the optional

Auxiliary Trays or from the

optional High Capacity

Feeder.

Exit Path

• Straight-Through only

For Individual Print Jobs

Make the following settings in

the printer driver as you print

the job:

•Source = Tray 1 or MP Tray

•Size = Letter , A4, Tabloid or

Tabloid Extra

•Type = Transparency

•Windows Adobe PostScript

driver only:

Paper Size Check (usually

under Paper Source

Options) = Deselected (Off)

Making Transparencies

the Default

Tray 1

If Tray 1 will normally be

loaded with transparencies, set

the printer menu as follows

(see page 12):

•Tray1 MediaType =

Transparency

Multi-Purpose Tray

If the MP Tray will normally

be loaded with transparencies,

set the printer menu as follows

(see page 12):

•MP Tray PaperSize =

Letter, A4, Tabloid or

Tabloid Extra

•MP Tray MediaType =

Transparency

Print Media (cont.)

Thick Paper

(Cards, Index)

Caution! Failure to change

the printer’s media settings

before printing on thick paper

will damage the printer.

Recommended

Letter

• HammerMill®

- Cover Copy, 60 & 80 lb.*

- Color Cover Copy

#12002-3 80 lb.*

• Springhill®Index, 110 lb.

• Wausau Exact®Index

- #49111, 90 lb.

- #49511, 110 lb.

• Weyerhaeuser®First Choice

Premium Cover #8210, 80

lb.*

• Xerox®

- Color Xpressions, 65 lb.*

- Cover Stock, 65 lb.*

- Index, 90 lb.*

Tabloid

• Strobe™ Gloss, 100 lb.*

Usable Sizes

• Tabloid, Tabloid Extra

• Letter, Executive

• Legal-14, -13.5, -13

• A3 Nobi, A3 Wide, A3, A4,

A5, A6

• B4, B5

• Custom (MP Tray only;

must be defined in the driver)

Weight Range

• Up to 110-lb.* (200 g/m2)

Feed Path

• Tray 1 (up to 95 lb. Index)

• Multi-Purpose Tray

Exit Path

• Straight-Through only

For Individual Print

Jobs

Make the following settings in

the printer driver as you print

the job:

•Source = Tray 1 or MP Tray

•Size = Tabloid, Tabloid

Extra, Letter, Executive,

Legal-14, Legal-13.5,

Legal-13, A3 Nobi, A3

Wide, A3, A4, A5, A6, B4,

B5, Custom (MP Tray only;

must be defined in the printer

driver)

•Type = Medium Heavy,

Heavy, or Ultra Heavy (see

page 12)

* Index

Andere Handbücher für C9200

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Oki Drucker Handbücher

Oki

Oki ML3321 Bedienungsanleitung

Oki

Oki B2200 Bedienungsanleitung

Oki

Oki C9850hdn Bedienungsanleitung

Oki

Oki DP-5000 Metallic and Colour Desktop Printer Bedienungsanleitung

Oki

Oki C3200n Bedienungsanleitung

Oki

Oki C6100dn Bedienungsanleitung

Oki

Oki OKIPAGE6w Kurzanleitung

Oki

Oki ML3310e Referenzhandbuch

Oki

Oki C9200 Bedienungsanleitung

Oki

Oki OKIPAGE6w Programmierhandbuch

Oki

Oki Microline 520 Anleitung zur Verwendung

Oki

Oki OKIPAGE 12i Series Bedienungsanleitung

Oki

Oki C3400n Bedienungsanleitung

Oki

Oki B 6100 Bedienungsanleitung

Oki

Oki C5800Ldn Series Bedienungsanleitung

Oki

Oki ML420 Series Kurzanleitung

Oki

Oki ES6405 Bedienungsanleitung

Oki

Oki C7200 Bedienungsanleitung

Oki

Oki C5800Ldn Series Bedienungsanleitung

Oki

Oki OKIJET 2020 Bedienungsanleitung

Oki

Oki OKIPOS X400 Bedienungsanleitung

Oki

Oki LP441s Bedienungsanleitung

Oki

Oki OL600ex Bedienungsanleitung

Oki

Oki B710n Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
