Oki MPS930b Service-Handbuch

Handy Reference

Guide de référence pratique

Referencia Rápida

59401901 my.okidata.com

MPS930b

Printer Overview ........................4

Using the Printer Menu...............7

Print Media .................................9

Loading Trays 1 & 2...................... 9

Loading the MPT Tray...................11

Loading the HCF Tray...................13

Jams.........................................16

Trays 1-2 ...................................17

Multi-Purpose Tray (MPT) .............19

High Capacity Feeder Tray ............21

Additional Jam Locations ..............23

Finisher ....................................33

Troubleshooting .......................36

Replacement Supplies ..............42

Service & Support....................43

Survol de l’imprimante . . . . . . . 44

Utilisation du menu

d’impression .......................... 47

Support d’impression ............... 49

Chargement des bacs 1 et 2..........49

Chargement du bac multifonction ..51

Chargement de l’alimentateur

haute capacité ..........................54

Bourrages ................................ 57

Bacs 1 et 2 .................................58

Bac multifonction.........................60

Alimentateur haute capacité..........62

Autres emplacements de

bourrages.................................64

L’unité de finition..................... 74

Dépannage............................... 77

Fournitures de

remplacement ........................ 83

Service et support.................... 84

Contents Table des matières

59401901

Generalidades de la

Impresora . . . . . . . . . . . . . . . 85

Cómo utilizar el menú de

la impresora ...........................88

Medios de impresión.................90

Cómo cargar las Bandejas 1 y 2 ....90

Cómo cargar la Bandeja

Multiuso ...................................92

Bandeja del Alimentador

de Alta Capacidad......................95

Atascos.....................................98

Bandejas 1 y 2............................99

Bandeja Multiuso....................... 101

Alimentador de Alta Capacidad .... 103

Otros lugares donde el

papel se atasca ....................... 105

Acabador ................................115

Resolución de problemas........118

Suministros ............................124

Servicio y Soporte ..................125

Contenido

4 • English

Printer Overview

Front View

1FrontDoor

2 Paper Trays (1 and 2)

3 Duplex Unit

4 Multi-Purpose Tray (MPT, Tray 5)

5 Standard top bin output tray and transport to

optional finisher

6 Optional High Capacity

Feeder (HCF)

7 Optional tabloid tray or

tandem tray (Trays 3

and 4)

8 Optional finisher

9 Finisher main stacker

(3000 sheets)

10Finisher upper stacker

(500 sheets)

11Exit 2: used in

conjunction with the

optional duplexer and

the optional finisher.

Present only if the

optional duplexer is

installed.

5 • English

READY light

Off:

printer is idle

On:

printer is active

Blinking: printer is waiting, processing

ATTENTION light

Off:

no error

On:

there is an error requiring user

intervention

CANCEL Button

Cancel a print job.

ON-LINE Button

Toggles the printer on-line and off-

line.

MENU Button

Press to enter or exit the menu.

SELECT Button

Press to select the Menu or Submenu

shown on the second line of the

display or choose and save the setting

shown on the second line of the

display.

NEXT/PREVIOUS Buttons

Press to move to the

(

) or

(

) Menu, Submenu, or

Setting within the same level of the

menu structure.

FORWARD/BACK Buttons

Press to move

Forward

(

) or

Back

(

) one level in the menu structure to

the menu shown on the first line of

the display.

Printer Overview

Operator Panel Overview

6 • English

Print a Summary of the

Printer’s Settings

Press the

Info

button on the Operator

Panel to print a configuration

summary including:

• Status of menu options

• Media selections in trays

• Installed options

Cancel a Print Job at the

Printer

At the Operator Panel:

1. Press the

Cancel

button.

2. Press the

On-line

button.

Note that pages that are printing at

the moment will finish printing.

Reset Printer to Factory

Defaults

At the Operator Panel:

1. Press

2. Press

(

) until

Maintenance

is displayed.

3. Press

Select

. You may be

prompted to enter a password.

4. Press

Forward

(

) until

Reset

is displayed.

5. Press

Select

to reset the menus to

their factory defaults (i.e.,

“execute”).

6. Press

. The printer resets and

goes back to the Ready to Print

state.

Printer Overview

Basic Operator Panel Functions

7 • English

Using the Printer Menu

Changing Settings

1. Press

2. Press

(

) and

(

)

to scroll through the

menus

until

the one you want is displayed.

3. Press

Select

4. Press

Forward

(

) and

Back

(

)

to cycle through the

submenus

for

the selected menu until the one

you want is displayed.

5. Press

Select

6. Press

(

) and

(

)

to scroll through the

options

until

the one you want is displayed.

7. Press

Select

An asterisk appears next to the

setting.

8. To exit Menu mode, press 3 or

press the Menu button.

Note

: If there is a conflict between

settings in the menu, Printing

Preferences, or Embedded Web Server

and printer settings set via your

application, the application settings

supersede any other setting.

C96


NETWORK MENU

8 • English

How to Enter a Pin Number

at the Operator Panel

1. Press

. Press

(

) until

the

Print Jobs

menu is displayed.

Press

Select

2. Press

Forward

(

). You are

prompted to enter a pin number.

3. Use

(

) and

(

)

to specify the first digit in the pin

number, then press

Forward

(

)

to enter the digit.

4. Repeat step 3 until all digits are

entered. Press

Select

5. Press

(

) until the

is displayed. Press

Select

6. Press

(

) until your

document is displayed. Press

Select

7. To print the document: Press

(

) to specify the number of

copies. Press

Select

to print.

Using the Printer Menu

Entering a Pin Number

9 • English

Loading Media in Trays 1-2

Note: Put side to be printed face up.

Slide the paper tray back into the

machine

If custom sizes of paper

are used, make the appropriate

changes in your Printer Properties

and at the Operator Panel as

needed.

For Letterhead stationery:

Long edge feed—face

up, top toward the

front of the printer.

Short edge feed—

face up, top to the

left:

Print Media

Loading Trays 1 & 2

10•English

For Transparencies:

Long edge feed—face up, top

toward the front of the printer.

For Labels:

Insert the label sheets long-edge

feed and face up. Place the top of

the label page toward the front of

the printer.

Print Media

Loading Trays 1 & 2 (cont.)
