LP440/LP441/LP470/LP480

Font download tool

The 5th edition: October 22, 2008

Contents

Introduction.................................................................................................................................................1

1. What is Font Download Tool ...........................................................................................................2

2. Set up the printer..............................................................................................................................2

3. Functions of Font Download Tool...................................................................................................3

3.1. Select printer model..................................................................................................................3

3.2. Setting Font Information...........................................................................................................4

3.3. Font registration........................................................................................................................6

3.4. Get font/logo information..........................................................................................................8

3.5. Delete specific item.................................................................................................................11

3.6. Delete all items ........................................................................................................................13



Introduction

Font Download tool is the software for registering font into LP440/LP441/LP470/LP480 printer.

*This manual describes for LP470 as a reference

Supported OS

•Microsoft Windows 2000 Professional Service Pack4

•Microsoft Windows XP Home/Professional Service Pack2 or later

•Microsoft Windows Server2003 Standard Edition Service Pack1 or later

•Microsoft Windows Vista

*Microsoft Windows XP/Server2003/Vista does not support 64bit.



1. What is Font Download Tool

Font Download Tool allows users following operation for LP440/LP441/LP470/LP480 printer.

1. Download Font data to the printer so that it can be retrieved as the residential font

2. View the information of stored font and or logo

3. Delete a stored font and or logo

2. Set up the printer

Before using the Font Download Tool, set the printer to the download mode by following steps.

1. Power off the printer

2. Set DIP switch of the printer to #1-OFF, #2-OFF, #3-OFF, #4-ON

3. Connect the printer and the PC by RSS-232C cable

4. Power on the printer.

Printer is ready.

3. Operation of Font Download Tool

3.1. Select printer model

Following screen is displayed at the activation of the font download tool.

Fig. 3.1 Select printer model

Select the printer in this screen and click "OK".

3.2. Setting Font Information

If you click "OK" at Fig. 3.1, the Font Download Tool will be launched. (Fig.3.2)

Fig.3.2 Font Download Tool

Please refer to Table 3.2.1 to 3.2.3 for details in setting the font information.

Explanations for each item of font setting is as follows.

Table 3.2.1 Font Information

Item Description Restrictions

Registration

ID Set registration ID in the

printer. 0-99(Can register up to 80 of font/logo total)

Maximum capacity may be decreased depending on the

size of font and logo.

Please use 31-99 in compatible mode.

Font name Display registered name in

the printer. 1-32 Byte

Table 3.2.2 Font Setting

Item Description Restriction

True type font Select TrueType font -

Font size Set font size. 1-72 point

Style Set font to Bold style and/or Italic style. -

Preview Preview the selected font. -

Table 3.2.3 Registered character setting

Item Description Restriction

Specific code

registration Check "Register 1byte character by

specific code", and ASCII code can be

specified by number. 32-255(DN)

Input character Input character directly When registering 2 byte character

such as Kanji, True Type font needs

to be applied to the Kanji code.

Input from text file Read character from the text file.

When read Unicode format file, please

check "Read Unicode file". Size of text file must be less than

55KB.

3.3. Font Download

Procedure to download the font data in the printer is as follows.

Fig. 3.3.1 Download

After setting the font information for the downloading, click the "Download" button.

The following screen will be displayed when the font download is completed.

Fig. 3.3.2 Completed registration message

Tips

1 Font setting information can be saved as LP400 font data (pfd) format by clicking "Save"

button after setting font.

2 Setting information will be recovered when the PDF file is opened by clicking “Load” button.

3 When pfd file is opened by the printer with different resolution, the file is converted to current

resolution automatically and opened. (e.g.: Open pfd file saved by LP480 by LP440/LP441

font download tool.)

3.4. Get font/logo information

Procedure to get font/logo information registered in the printer is as follows.

Fig. 3.4.1 Get information

In the “Font Download Tool” window, click on the "Information" button.

The following screen is displayed when the font information from the printer is retrieved. (Fig. 3.4.2)

Fig. 3.4.2 Completed getting information message
