Olympus DS-3300 Bedienungsanleitung

DS-3300 2005.03.8 E1-BZ8094-01

Black Cyan

Recording Overwrite Recording

Press the NEW button to create a new file.

Press the REC button to start recording.

The record/play indicator lamp glows red.

Aim the microphone at the sound source.

Press the STOP button to stop recording.

If you want to append additional recordings to

the same file, press the REC button again.

DIGITAL VOICE RECORDER

DS-3300

Quick Start Guide

Record mode

Battery

indicator

Microphone

sensitivity

VCVA indicator

Folder

Priority

indicator

Current file

Total number

of recorded of

files in the folder

Erase lock

indicator

Getting Started

Power Save Mode

When the recorder is ON but not in use for sometime,

it will switch to power save mode automatically. To

reactivate the recorder again, press any of the buttons

on the recorder.

Current recording mode

bNew file number

cSelected Author ID

Insert Recording

Select and play the file you want to

overwrite.

Stop playback at the starting point of

overwrite.

Press the REC button to start overwriting.

The record/play indicator lamp glows red.

Press the STOP button to stop overwriting.

Select and play the file you want to insert

an additional recording into.

While playing the file, press the

FOLDER/MENU button to insert an

additional recording.

“INSERT ?” appears on the display.

Press the REC button to start inserting

an additional recording.

The record/play indicator lamp glows red.

“INSERT REC” and the remaining recording

time will alternate on the display.

Press the STOP button to stop inserting

the additional recording.

Display (LCD Panel)

aCurrent playback

time

bTotal recording

time of the file

Turning ON the Recorder

Slide the power switch to the ON

position to activate the recorder.

CUSTOM Button (Programmable)

The CUSTOM button can be

assigned two kinds of functions by

being pressed in different ways. By

default, the button is programmed

on PRIORITY for both ways:

The following functions can be assigned to CUSTOM button.

- DISPLAY button

- Recording Mode setting button

- Microphone Sensitivity setting button

- VCVA setting button

- PRIORITY setting button

2,4

CUSTOM Button

*Insert here your settings.

DS-3300 2005.03.8 E1-BZ8094-01

Black Cyan

Menu List

Playing

E1-BZ8094-01

Erasing a File Alarm Message List

Select the file,

then press the

PLAY button to

start playback.

Press the STOP

button at any

point you want to

stop the

playback.

AP0503

Playback

functions

Fast Forward

Rewind

Cue

Review

Fast skip

Backward

skip

Operation

Press the FF button once while stopped.

Press the REW button once while stopped.

Hold the FF button while stopped or

playing a file.

Hold the REW button while stopped or

playing a file.

Press the FF button once while fast-

forwarding or twice while stopped.

Press the REW button once while rewinding

or twice while stopped. If the REW button

is pressed within 2 seconds, the recorder

skips to the beginning of the previous file.

File to be erased

Select the file you want to erase.

Press the ERASE button.

“FILE ERASE ?”flashes on the display for

approximately 8 seconds.

Press the ERASE button once more

while “FILE ERASE ?” is flashing.

The display changes to “FILE ERASE !”and

erasing will start.

“ERASE DONE”is displayed when the file

is erased. File numbers will be reassigned

automatically.

REC MODE

MIC SENSE

EXIT

SUB MENU

VCVA

LOCK

BEEP

FORMAT

EXIT

BACKLIGHT

TIME&DATE

CONTRAST

USB CHARG.

Press the FOLDER/MENU button.

SP or LP.

ON or OFF.

CONFERENCE

or DICTATION.

Exit MENU.

Locking files ON or OFF.

Time/Date setting.

Hr/Min, Y/M/D.

Recorder formatting.

LCD contrast

adjustment. 1 to 12.

ON or OFF.

Press the

FF button

or REW

button.

Returns to the MENU.

ON or OFF.

Press the

REC

button.

SUB MENU

Switches to the SUB MENU.

Message

BATTERY

LOW

FILE IS

LOCKED

INDEX

FULL

FOLDER

FULL

MEMORY

ERROR

MEMORY

FULL

FORMAT

ERROR

SYSTEM

ERROR

INSERT

CARD

COVER IS

OPEN

Action

Charge the battery or replace with

new batteries.

Unlock the file.

Erase index marks that are no

longer required.

Erase unnecessary files.

Insert a compatible card.

Erase files that are no longer

required or insert another card.

Reformat the card.

This is a malfunction. Contact the

place of purchase.

Insert a card.

Close the card cover securely until

it click.

2,3

Shinjuku Monolith, 3-1 Nishi-Shinjuku 2-chome, Shinjuku-ku, Tokyo 163-0914, Japa

Tel.

03-3340-2111

Two Corporate Center Drive, PO BOX 9058, Melville, NY 11747-9058, U.S.A

Tel. 1-800-622-6372

(Premises/Goods delivery) Wendenstrasse 14-18, 20097 Hamburg, Germany

Tel. 040-237730

(Letters) Postfach 10 49 08. 20034 Hamburg, Germany.

2-8 Honduras Street, London EC1Y OTX, United Kingdom

Tel. 020-7253-2772

http://www.olympus.com

Authorized Olympus Dealer
