Olympus LS-12 Bedienungsanleitung

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

LS-12

• Mode Dial & Smart Mode • Linear PCM recording

(96kHz/24bit)

• Two high-sensitivity 90°

mics

• Acoustic resistance of 130

dBspl

• Battery Life: Up to 50 hours

of continuous recording

• Separate audio & system

circuitry

• Switchable low-cut filter

(100Hz/300Hz)

• Pre-record buffer

Pro recordings made easy

Featuring a user-friendly Mode Dial, Smart Mode functionality and more, the LS-12 makes it easier than ever to achieve studio-standard

audio results. This top sound quality is thanks to a high-sensitivity stereo microphone system with two mics set at 90 degrees for

capturing expansive and true-to-life audio with low levels of noise up to an incredible 130 db SPL.

On top of this, you can also enhance your tracks still further with a range of sophisticated functions specifically developed for musicians

to produce the very best recordings - including a Chromatic Tuner for getting instruments in tune, a Metronome for keeping everything

in time, high-powered overdubbing capabilities and variable playback speed control.

Specifications

Storage Media

Internal / Removable Media Internal + Removable

External Memory (Slot) SD / SDHC card (512 MB -

32 GB)

Internal memory 2GB

USB functionality

USB Speed USB 2.0 High Speed

USB Classes USB Storage class

USB Composite device

Display

Display Backlit Yes

Display colour White

Display Type Full Dot Matrix Display

Display Size 30.1 x 35.4mm / 1.83''

Device operation

Mode select dial Yes

Recording Modes

Recording format PCM / MP3

96kHz / 24bit 40min

88.2kHz / 24bit 45min

48kHz / 16bit 2h 10min

44.1kHz / 16bit 2h 20min

44.1kHz (Mono) 4h 40min

320 kbps 10h

256 kbps 13h

128 kbps 26h

64 kbps (Mono) 52h

Smart Rec Yes

PCM (WAV) format

MP3 format

Playback Modes

Playback format PCM (WAV) / MP3

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Frequency response

96 kHz 20 - 44.000Hz

88.1kHz 20 - 42,000Hz

48kHz 20 - 23.000Hz

44.1kHz 20 - 21.000Hz

44.1kHz (Mono) 20 - 21.000Hz

320 kbps 20 - 20.000Hz

256 kbps 20 - 20.000Hz

128 kbps 20 - 17.000Hz

64 kbps (Mono) 20 - 13.000 Hz

MP3 format

PCM (WAV) format

Internal microphones 60 - 20.000Hz

Record function

Index Yes

Auto recording Pre-Recording

Sound control Rec Monitor

Manual Rec level control

Low Cut-Filter

Advanced recording Direct recording

Overdubbing

Playback function

Gapless Playback Yes

Playback control Playback Speed Control

Repeat functions Repeat playback

Data organisation

File move Yes

File divide Yes

File Copy (Folder to Folder) Yes

File Copy (internal memory -

external memory)

Yes

Time/date info Yes

Erase Erase all files

Erase single files

Partial (PCM only)

Other Features

Remote Control Yes (optional)

Chromatic Tuner Yes

Metronome function Yes

Interfaces Input

LINE IN input level - 6 dBv

PC interface USB Cable

Microphone sensitivity / gain High / Middle / Low

Microphone jack 3.5 ø mm mini-jack,

impedance 2 k�

LINE IN jack 3.5 ø mm jack, impedance 10

k�.

Interfaces Output

Max. working output 300mW or more (8 � speaker)

Maximum headphone output 2 mW + 2 mW

Speaker Diameter Built-in ø 28 mm round

dynamic speaker

Earphone jack 3.5 ø mm jack, impedance 8�

or more

Power Supply

Power Supply AA batteries (LR6 or ZR6)

or two Ni-MH rechargeable

batteries

Alkaline battery life Recording: 50h

External power supply USB connecting AC adapter

(A-514)

Dimensions

Weight 170g (incl. batteries)

WxHxD 52.5 x 138.7 x 23.5mm

Languages

Menu languages EN/FR/DE/IT/ES/RU/PL/CS/

SV/DA/NL/CN/TW

Operating Systems & Requirements

Windows Operating system: Microsoft

Windows XP/ Vista/7/8

Macintosh Operating system: Mac OS X

10.4.11 - 10.8

Microphone System

TRESMIC (3 Mic System) No

Max. Sound Pressure 130dB SPL
