Omega ODW902X Bedienungsanleitung

Dishwasher

ODW902X

Instruction Manual

Thank you for introducing our family to yours

At Omega, we understand that cooking, cleaning and washing may not be your

favourite things in the world. That's why we created a range of no-nonsense, reliable

products that always get the job done for you. With the features you need and

nothing you don't. What's more, they're made to ﬁt perfectly into your home life and

your wallet.

We aim to simplify any further appliance purchases. When researching our products

you will ﬁnd a range of icons that visually represent our products key features. Visit

our website to learn more about these icons and the features and beneﬁts of our

products.

You are welcoming an Omega appliance into your place and you can be sure it'll

always serve you well.

For important information about your Omega such as warranty registration, online

manuals, speciﬁcations and catalogues, please visit

www.omegaappliances.com.au/customer (if you are in Australia) or

www.omegaappliances.co.nz/customer (if you are in New Zealand).

Make sure you activate your product warranty on our websites on the links above.

If you want to know more about promotions, to receive cool tips and tailor made

content, like us on www.facebook.com/omegaappliances and follow us on

www.instagram.com/omegaappliances_aus.

We hope you love this product as much as we do!

www.omegaappliances.com.au / www.omegaappliances.co.nz

omegaappliances

omegaappliances_aus

CONTENTS

•Technical specifications …………………………………………………….. 4

•Conformity with the standards and Test data …………………………….. 4

Safety information and Recommendations………………………………….. 5

•Recycling .......………………………......................................................... 5

•Safety information …………………………………………………………… 5

•Recommendations …...……………………………………………………… 8

•Items not suitable for dishwashing ………………………………………… 9

Installing the machine ………………………………………………………….. 9

•Positioning the machine …………………………………………………….. 9

•Water connections …………………............................................................... 10

•Water inlet hose ….………………………………………………………….. 11

•Water outlet hose …..……………….............................................................. 1 2

•Electrical connection………………………………………………………… 13

•Fitting the machine undercounter …………………………………………. 14

•Prior to using the machine …………………………………………………. 16

•Detergent usage ……………………........................................................ 16

•Filling the detergent compartment…………………………………………. 16

•Combined detergent….……………………………………………………… 16

•Filling with rinse aid and making the setting………………………………. 17

Preparing the machine for use ………………………………………………… 16

Loading your dishwasher .……………………………………………………. 18

•Alternative basket loads …………………………………………………... 23

Programme descriptions .…………………………………………………….. 25

•Programme items ………………………………………………………….. 25

Switching on the machine and selecting a programme……………........ 28

•Switching on the machine…………………………………………………. 28

•Programme follow-up ……………………………………………………… 28

•Changing a programme …………………………………………………… 28

•Changing a programme with resetting …………………………………... 29

•Switching the machine off ….……………………………………………... 29

Maintenance and Cleaning ........................................................................ 30

•Filters ..……………………………………………………………………… 30

•Spray arms …………………………………………………………………. 31

•Hose filter …………………………………………………………………… 31

Failure codes and what to do in case of failure ………………………… 32

Practical and useful information……......................................................... 34

Getting familiar with your machine …………………………………………… 2 6

7. Rating plate

2. Upper basket with racks 8. Control Panel

3. Upper spray arm 9. Detergent and rinse-aid dispenser

4. Lower basket 10. Cutlery basket

5. Lower spray arm 11.

6. Filters

Upper basket track latch

1. Worktop

Active Drying Unit: Thissystemprovides

better drying performance for your dishes.

Ceiling Spray Arm: It provides

better washing for the dishes at

upper basket.

Capacity 15place settings

Height 850 mm

Height (without worktop) 820 mm

Width 598mm

Depth 598 mm

Net Weight 52kg

Electricity input 220-240 V, 50 Hz

Total Power 1900 W

Heating Power 1800 W

Pump Power 100 W

Drain Pump Power 30 W

Water supply pressure 0.03 MPa (0,3 bar)-1 MPa (10 bar)

Current 10 A

Technical specifications

Conformity with the standards and Test data / E Declaration

of Conformity

This product meets the requirements of all applicable EU

directives with the corresponding harmonised standards, which

provide for CE marking.

SAFETYINFORMATIONANDRECOMMENDATIONS

• The appliance is not intended for use by persons

(including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervised or instruction concerning

use of the appliance by a responsible person for their safely.

•Young children should be supervised to ensure that they

do not play with the appliance.

•If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

•If the appliance is installed on a carpet floor, take care that

the openings in its base are not obstructed

Safety Information

When you take delivery of your machine

• Check for any damage to your machine or to its packaging.

Never start a machine damaged in any way, make sure to

contact an authorised service.

• Unwrap the packaging materials as indicated and dispose

of them in accordance with the rules.

The points to pay attention during machine installation

•Choose a suitable, safe and level place to install your

machine.

• Carry out the installation and connection of your machine by

following the instructions.

•This machine should be installed and repaired by an

authorised service only.

• Only original spare parts should be used with the machine.

• Before installing, be sure that the machine is unplugged.

• Check whether the indoor electrical fuse system is connected

according to the regulations.

• All electrical connections must match the values indicated

on the rating plate.

• Pay special attention and be sure that the machine does not

stand on the electricity supply cable.

• Never use an extension cord or a multiple socket for making

a connection. The plug should be comfortably accessible

after the machine has been installed.

• After installing the machine to a suitable place, run it unloaded

for the first time.

In daily use

• This machine is for household use; do not use it for any

other purpose. Commercial usage of the dishwasher will void

the guarantee.

• Do not get up, sit or place a load on the open door of the

dishwasher, it may fall over.

• Never put into the detergent and rinse aid dispensers of

your machine anything other than those detergents and rinse

aids which are produced specifically for dishwashers. Our

company will not be responsible for any damage that might

occur in your machine otherwise.

• The water in the machine's washing section is no drinking

water do not drink it.

- Staff kitchen areas in shops, offices and other working

environments;

- Farm houses;

- By clients in hotels, motels and other residential type

environments;

- Bed and Breakfast type environments.

• Do not put into your machine those items which are not

suitable for dishwashing. Also, do not fill any basket above its

capacity.Our company will not be responsible for any scratch

or rust to form on the inner frame of your machine due to

basket movements otherwise.

•Because hot water may flow out, the machine door

should not be opened under any circumstances while the

machine is in operation. In any case, a safety devices

ensures that the machine stops if the door is opened.

•Please do not leave the door open as this will cause a

tripping hazard.

• Place knives and other sharp-ended objects in the cutlery

basket in blade-down position.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

• This appliance is not intended for use by persons (including

-children) with reduced physical,sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

•WARNING - Knives and other utensils with sharps points

must be loaded in the basket with the points down or placed

in a horizontal position.

•WARNING: SOME DISHWASHER DETERGENTS ARE

STRONGLY ALKALINE. THEY CAN BE EXTREMELY

DANGEROUS IF SWALLOWED. AVOID CONTACT WITH

SKIN AND EYES AND KEEP CHILDREN AWAY FROM

THE DISHWASHER WHEN THE DOOR IS OPEN.

•

• Due to danger of explosion, do not put into the machine’s

washing section any chemical dissolving agents such as

solvents.

• Check whether plastic items are heat-resistant before

washing them in the machine.

For your children’s safety

• After removing the machine’s packaging, make sure that the

packaging material is out of reach of children.

• Do not allow children to play with or start the machine.

• Keep your children away from detergents and rinse aids.

•Keep children away from the machine while it is open

because there may still be residues of cleaning substances

inside the machine.

• Be sure that your old machine does not pose any threat to

your children. Children are known to have gotten themselves

locked in old machines. To forestall such a situation, break

your machine's door lock and tear off the electrical cables.

In case of malfunctioning

• Any malfunction in the machine should be repaired definitely

by qualified persons. Any repair work performed by anyone

other than the authorised service personnel will cause your

machine to be left outside the scope of warranty.

• Prior to any repair work on the machine, be sure that the

machine is cut off from the mains.Switch off the fuse or unplug

the machine.Do not pull by the cable when unplugging. Make

sure to turn off the water tap.

Recommendations

• For energy and water saving, remove coarse residues on

your dishes before placing the dishes into the machine. Start

your machine after having fully loaded it.

• If EnergySave option is selected as "Yes", The door will be

opened at the end of the program. Do not force to close the

door to avoid damaging the auto door mechanism.

The door must be open during 30 minutes to get effective

drying.( in models with auto door opening system )

Warning: Do not stand in front of the door after the signal

sounds belonging auto-open.

Inhaltsverzeichnis

Andere Omega Spülmaschine Handbücher

Omega

Omega OFI700 Bedienungsanleitung

Omega

Omega ODW300X Bedienungsanleitung

Omega

Omega OSI700 Bedienungsanleitung

Omega

Omega BSID346X Bedienungsanleitung

Omega

Omega ODW300XN Bedienungsanleitung

Omega

Omega OFI604A Bedienungsanleitung

Omega

Omega PL403A Bedienungsanleitung

Omega

Omega DW101WA Bedienungsanleitung

Omega

Omega ODW707WB Bedienungsanleitung

Omega

Omega ODD614X Bedienungsanleitung

Omega

Omega OSI700 Bedienungsanleitung

Omega

Omega ODW101W Bedienungsanleitung

Omega

Omega ODW715X Bedienungsanleitung

Omega

Omega PL402XA Bedienungsanleitung

Omega

Omega DW2006 Bedienungsanleitung

Omega

Omega ODW700B Bedienungsanleitung

Omega

Omega OFI101X Bedienungsanleitung

Omega

Omega ODD614X Bedienungsanleitung

Omega

Omega ODW702W Bedienungsanleitung

Omega

Omega DW602XA Bedienungsanleitung

Omega

Omega DW300XA Bedienungsanleitung

Omega

Omega ODW300XN Bedienungsanleitung

Omega

Omega ODW717X Bedienungsanleitung

Omega

Omega ODW717WB Bedienungsanleitung

Beliebte Spülmaschine Handbücher anderer Marken

Electrolux

Electrolux ESI5211LOX Bedienungsanleitung

KitchenAid

KitchenAid KUDB230B Bedienungsanleitung

Brandt

Brandt BDJ424DB Bedienungsanleitung

Asko

Asko DSD767UXXL.AU Bedienungsanleitung

Beko

Beko DFN26210W Bedienungsanleitung

NEFF

NEFF S153ITX00E Technisches Datenblatt

Midea

Midea SV 4.45 wi Bedienungsanleitung

LG LDF7932 Bedienungsanleitung

Gorenje

Gorenje GV63214 Bedienungsanleitung

Hotpoint

Hotpoint HDA1100ZWH Service-Handbuch

Blomberg

Blomberg LDFN2240W Bedienungsanleitung

AEG

AEG FFB83836PM Bedienungsanleitung

Cylinda

Cylinda DM3220RFD Bedienungsanleitung

Atag

Atag DW8214MB Bedienungsanleitung

GE GLD8000 Series Bedienungsanleitung

Siemens

Siemens SN23HI02KE Technisches Datenblatt

BORETTI

BORETTI BVW-683 Bedienungsanleitung

Siemens

Siemens SN 56N591 Bedienungsanleitung
