One Forall SMART CONTROL PRO Bedienungsanleitung

III

4 X AAA

ENGLISH

ENGLISH 2

DEUTSCH 9

FRANÇAIS 17

SMART

CONTROL PRO

URC 7966

www.oneforall.com/mynevo

Virtual Agent

If you need help at any time during setup,

please use the Virtual Agent in the app.

4 7

5 6

8 10

1111

KEY DESCRIPTION

INPUT Selects the Input of the current device

POWER On / O

TV_STREAM_S. BAR_STB_BL.RAY_AUDIO

Device keys – press these to select the device you

want to control

NETFLIX Netix (if available). Can be programmed

as an App Shortcut

PRIME VIDEO Amazon Prime Video (if available).

Can be programmed as an App Shortcut

DISNEY + Disney+ (if available). Can be

programmed as an App Shortcut

YOUTUBE YouTube (if available). Can be

programmed as an App Shortcut

WATCH TV Combines up to 3 Devices; a TV, a

source device and an audio device

WATCH MOVIE Combines up to 3 Devices; a TV, a

source device and an audio device

ENGLISH

KEY DESCRIPTION KEY DESCRIPTION

LISTEN TO MUSIC Combines up to 3 Devices; a TV,

a source device and an audio device

UP_LEFT_OK_RIGHT_DOWN

Navigate and select items in the menu of the

current device

BACK One step back in the menu

HOME Home /Smart Menu

EXIT Exit the Menu

VOL +_VOL - Controls the Volume of the current

Audio Device

MUTE Mute

MIC / MENU Settings or Options Menu – When

controlling a device using the Google TV OS,

holding this key down will give access to Voice

Commands

CH +_CH - Channel Up and Down

REW_PLAY_FF_PAUSE_REC Controls the playback

of the current show or disc

APPS Apps Menu

Digits 0-9 Digits 0-9 for channel selection for

channel selection

DASH Delimiter for selection of sub-channels

GUIDE TV Guide

RED_GREEN_YELLOW_BLUE Quick access

buttons for the menu of the current device

ENGLISH

www.oneforall.com/mynevo

SETUP DEVICE SETUP

AMAZON FIRE STICK / CUBE SETUP

To set up the remote, rstly please download the My

Nevo app. This app communicates with the remote using

Bluetooth Low Energy or BLE. You can get this app by

scanning the QR code below, or by searching for“My Nevo”

in the App or Play Store.

When you rst use the app, it may

take up to 30 seconds to connect

to your remote. This is a one time

check to see the rmware of the

remote is up to date.

iOS version of setup app requires iPhone 8 or newer or

second-generation SE. First generation SE and iPhone

7 and older are not supported..

Once the app has located your remote, you can follow the

instructions to set it up to control your Audio Video devices

– we recommend setting up your TV rst of all.

You can then add other devices such as set top boxes and

sound bars.You can set up one TV, and up to 5 other devices

that you use as source of your viewing content, for example

a streaming box, satellite or cable and a Blu-ray player.

When you set these up, the remote will also do a quick test

to see which HDMI Input of your TV your source devices are

connected to.

If you have an Amazon Fire Edition Television, this can be

setup as a normal TV. However if you have an Amazon Fire

Stick or Cube, the procedure is slightly dierent. You will

need the original Fire remote control. Next perform the

following 5 steps:

First, simply turn on your TV and select the

input you have the Fire device connected to.

2. Secondly, press any button on the original

Fire remote to wake it up.

ENGLISH

Amazon Fire TV Remotes

Add New Remote

Settings Controllers and Bluetooth

Devices

3. Next, using your original Fire remote select “Settings

> Controllers and Bluetooth Devices > Amazon Fire

Remotes > Add New Remote

4. Hold down the Home key on your

NEW Smart Control Pro Remote

for 10 seconds. The remote will

appear as an Amazon Remote,

now press the Select key on the

ORIGINAL AMAZON REMOTE to

select it. The OFA Remote is now

paired with the Amazon Fire

device, but it needs to be added to

an Activity to control it.

5. The Amazon Fire will automatical-

ly be set up on the STREAM device

key, as well as added to an Activity.

ENGLISH

ACTIVITY SETUP

GOOGLE TV SETUP

The Smart Control Pro can also control devices using the

Google TV operating system, such as a newer Google

Chromecast (with Google TV), or a Sony or TCL TV. It can

also support some systems running Android TV, such as the

Nvidia Shield.

To set up the device using the My Nevo app, select the

device type, for example a TV or a Streaming Device, and

select Google TV.

Next, when prompted by

the My Nevo app open

the Settings Menu on your

Google TV device and select

Remotes and Accessories

and then Pair New accesso-

ry. The Google TV device should start searching and at that

point you will be asked by the My Nevo app to hold down

the Home key for 10 seconds. After 10 seconds your Google

TV Device should nd the Smart Control Pro – please select

it using the ORIGINAL REMOTE.

After this the Google TV

Device should be set up as

a device on the STREAM key

of the Smart Control Pro

remote as well as added to

an Activity.

The Smart Control Pro can

also use voice search on

Google TV devices. Simply

hold down the Menu/Mic

button and hold the top of

the remote close to your

mouth to speak.

The Smart Control Pro combines devices into Activities for

ease of control. An Activity can contain up to 3 devices; a

TV, a source device and an audio device such as a sound bar,

and a good example of an Activity is Watch TV. If for example

you set up a TV, an Amazon Fire stick and a sound bar, the

remote will control all these.

Pressing the Watch TV key will turn on these three devices

and select the right input on your TV.

The remote will remember which devices are powered on,

and pressing the Power key will turn them all o at once.

ENGLISH

APP SHORTCUT KEYS

TIPS AND TRICKS

The remote also features 4 app shortcut keys, which will

give direct access to your favorite streaming apps, such as

Netix or Amazon Prime Video.

If your original remote control had keys to directly access

these services, these keys will act the same. But if not you

can program them to mimic a sequence of keys (a macro)

used to access the app.

To program the macro, you rst need to know the sequence

of keys you need to press to always bring up the service you

prefer. For example on an Apple TV, the sequence is Back (or

Home), Menu Down, Menu Right (until the app is selected)

and OK.

• To power on the devices in the Activity, press the

Activity key.

• To power o your devices, press the Power key.

• The remote will remember which devices are on or

o and which HDMI Input was last selected.

- This can go out of sync, for example if the original

remotes are used

- If you don’t see the picture or a device is not

powered on when it should be, press and hold the

AV sync key.

•

If you need help, the My Nevo app has a help section, just

scroll to the right from the main menu and select“Help”.

To program the Macro, go to the App Shortcut section in the

My Nevo app. You can program one macro per key.

AV SYNC

The Input key is used to manually select the HDMI Input of

your TV. If you press and release it you should see the Input

Selection screen of your TV. But it also has a secondary

function. After pressing the Activity key, if you nd that one

or more of the desired devices did not power on, or that the

TV is on the wrong HDMI Input, hold down this key for 2

seconds. The remote will then try to correct this for you, by

resending the appropriate Power and Input commands.

ENGLISH

PRODUCT DISPOSAL (EUROPEAN DIRECTIVE

2012/19/EU)

The crossed out wheeled bin symbol on this product

ensures that this product is manufactured using high

quality components that can be recycled and reused accor-

ding European Directive 2012/19/EU. Please do not dispose

of this product with your normal household waste, refer

to local regulations for the proper collection or disposal

of electrical and electronic products. This will help this will

help in preventing negative eects on the environment

and/or human health.

BATTERY DISPOSAL (EUROPEAN DIRECTIVE 2006/66/EC)

Please do not dispose of your batteries with your normal household

waste, refer to local regulations for the proper collection or disposal.This

will help preventing potential negative eects on the environment and/

or human health.

GUARANTEE TERMS AND CONDITIONS UNIVERSAL ELECTRONICS

warrants to the original purchaser that this product will be free from defects

in materials and workmanship under normal and correct use for a period of

3 years from the date of original purchase. This product will be repaired or if

necessary, replaced free of charge if it has been proven to be defective within

the 3 year warranty period. The forwarding costs are on the account of the

owner; the costs of returning the product are on the account of UNIVERSAL

ELECTRONICS.

This warranty does not cover damage or failures caused by products or

services not supplied by UNIVERSAL ELECTRONICS, or which result from not

mounting the product according to manual instructions. This also applies

when the product has been modied / repaired by others than UNIVERSAL

ELECTRONICS or if a fault is the result of accident, misuse, abuse, neglect,

mishandling, misapplication, faulty installation, improper maintenance,

alteration, modications, re, water, lightning, natural disasters, wrong use

or carelessness.

To obtain warranty service during the warranty period contact […], and

please note that we need your original purchase receipt so that we may esta-

blish your eligibility for service. If you have bought this product for purposes

which are not related to your trade, business or profession, you may have

legal rights under your national legislation governing the sale of consumer

goods. This guarantee does not aect those rights. www.oneforall.com

ENGLISH

III

4 X AAA

DEUTSCH

SMART

CONTROL PRO

URC 7966

www.oneforall.com/mynevo

Virtual Agent

Wenn Sie während der Einrichtung Hilfe

benötigen, benutzen Sie bitte den Virtual

Agent in der App.

DEUTSCH

4 7

5 6

8 10

1111

BESCHREIBUNG DER TASTEN

INPUT Zum Auswählen des Eingangs des aktuellen

Geräts

POWER Ein / Aus

TV_STREAM_S. BAR_STB_BL.RAY_AUDIO

Gerätetasten - drücken Sie diese Tasten, um das

Gerät auszuwählen, das Sie steuern möchten

NETFLIX Netix (falls verfügbar). Kann als

App-Verknüpfung programmiert werden

PRIME VIDEO Amazon Prime Video (falls verfüg-

bar). Kann als App-Verknüpfung programmiert

werden.

DISNEY + Disney+ (falls verfügbar). Kann als

App-Verknüpfung programmiert werden

YOUTUBE YouTube (falls verfügbar). Kann als

App-Verknüpfung programmiert werden

TV SEHEN Kombiniert bis zu 3 Geräte; einen

Fernseher, ein Quellgerät und ein Audiogerät

FILM SEHEN Kombiniert bis zu 3 Geräte: ein

Fernsehgerät, ein Quellgerät und ein Audiogerät

DEUTSCH

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere One Forall Universalfernbedienung Handbücher

One Forall

One Forall Cinema 6+ URC 6800 Bedienungsanleitung

One Forall

One Forall SO EASY URC-2530 Bedienungsanleitung

One Forall

One Forall URC-6230 Bedienungsanleitung

One Forall

One Forall URC-3425 Bedienungsanleitung

One Forall

One Forall URC-4220 Installations- und Betriebshandbuch

One Forall

One Forall URC 7980 Bedienungsanleitung

One Forall

One Forall URC-7525 Bedienungsanleitung

One Forall

One Forall URC-6211 Bedienungsanleitung

One Forall

One Forall URC-3720 Bedienungsanleitung

One Forall

One Forall Easy 2 Bedienungsanleitung

One Forall

One Forall Zapper URC-6512 Bedienungsanleitung

One Forall

One Forall DVD EXPERT URC-4041 Bedienungsanleitung

One Forall

One Forall URC-7711 Bedienungsanleitung

One Forall

One Forall Universal remote Bedienungsanleitung

One Forall

One Forall Zapper URC-6510 Bedienungsanleitung

One Forall

One Forall URC-9966 Bedienungsanleitung

One Forall

One Forall URC-3415 Bedienungsanleitung

One Forall

One Forall Easy 4 Bedienungsanleitung

One Forall

One Forall URC 3050 Bedienungsanleitung

One Forall

One Forall URC-6231 Bedienungsanleitung

One Forall

One Forall ZAPPER URC-6010 Bedienungsanleitung

One Forall

One Forall KAMELEON URC-8308 Bedienungsanleitung

One Forall

One Forall URC-3710 Administratorhandbuch

One Forall

One Forall URC-7556 Bedienungsanleitung

Beliebte Universalfernbedienung Handbücher anderer Marken

Pronto

Pronto Peel Bedienungsanleitung

GE 24929 Bedienungsanleitung

Radio Shack

Radio Shack Wireless Remote Control System Bedienungsanleitung

AUVIO

AUVIO Universal Home Theater Remote Bedienungsanleitung

Philips

Philips Icon SRU4106 Bedienungsanleitung

THOMSON

THOMSON ROC4309 Bedienungsanleitung

Philips

Philips pm625S Bedienungsanleitung

GE RM94931 Bedienungsanleitung

RCA

RCA RCU600WMS - Universal Remote Control Bedienungsanleitung

Blackweb

Blackweb BWB17AV002 Bedienungsanleitung

Marmitek

Marmitek DoorGuard 300 Bedienungsanleitung

Chunghop

Chunghop RM-L618 Bedienungsanleitung

GE RM24965 Bedienungsanleitung

Anderic

Anderic KTN828 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Bedienungsanleitung

Medion

Medion E74023 Bedienungsanleitung

intensity

intensity RM02A Bedienungsanleitung

GE RM24950 Bedienungsanleitung
