One Forall URC-7210 Bedienungsanleitung

Universal remote

Universal Fernbedienung

Télécommande universelle

Mando a Distancia Universal

Telecomando Universal

Telecomando Universale

Universele Afstandsbediening

Univerzális távvezérlő

Uniwersalny pilot zdalnego sterowania

Univerzální dálkové ovládání

URC-7210

Instruction manual ..............................P. 2

Bedienungsanleitung ..........................S.10

Mode d’emploi ..................................P.17

Guía del usario ..................................P.24

Manual de instruções .........................P.31

Istruzioni per l’uso .............................P.38

Gebruiksaanwijzing ............................P.45

Használati útmutató

.........................P.52

Instrukcja obsługi

...............................P.59

Návod k použití

..................................P.66

English

Deutsch

Français

Español

Português

Italiano

Nederlands

Magyar

Polski

Česky

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina b

2WWW.ONEFORALL.COM

PICTURE OF ONE FOR ALL TV REMOTE

INSTALLING THE BATTERIES

THE KEYPAD

SET UP

SETTING UP THE ONE FOR ALL

Direct code set up 6

Search Method 7

SET-UP CODES

Televisions 73

COLOUR AND BRIGHTNESS

QUICK CODE REFERENCE

PROBLEM & SOLUTION

Table of Contents

Your ONE FOR ALL Package contains:

• Your ONE FOR ALL TV Remote

• Your ONE FOR ALL Manual

Your manual is divided into two parts: set-up instructions and device codes.

You may need this guide again in the future, so please be sure to

keep it.

Your ONE FOR ALL needs 2 new “AA/LR6” alkaline batteries.

Your ONE FOR ALL can operate a Television.

About Your ONE FOR ALL

English

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina c

WWW.ONEFORALL.COM 3

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 3

Installing the Batteries

Your ONE FOR ALL needs 2 new “AA/LR6” alkaline batteries.

1Remove the battery cover from the back of your ONE FOR ALL by

pressing down on the tab.

2Match the batteries to the + and - marks inside the battery case,

then insert the batteries.

3Press the battery cover back into place.

See picture of ONE FOR ALL TV remote on page 3

1MAGIC Key

The MAGIC key is used to set up your ONE FOR ALL 4.

2POWER

The POWER key operates the same function it did on your original

remote control. The red light (LED - Light Emitting Diode)

underneath the POWER key will light up every time a key

is pressed.

3MENU Key

The MENU key controls the same function as it did on your original

remote.

4DIRECTIONAL KEYS

If available on your original remote, these keys will allow you to

navigate through the menu mode of your device.

5OK

The OK key will confirm your choice in menu operation.

6Programme (Channel) +/- Keys

These keys operate in the same way as the keys on your original

remote.

7MUTE Key

The Mute key operates the same function it did on your orginal

remote control.

8Volume +/- Keys

These keys operate in the same way as the keys on your original

remote.

The Keypad

Important notes:

- In order to avoid having to reprogram your ONE FOR ALL after

you remove the batteries, you will need to insert new batteries

within 5 minutes. Also it is best that you do not use rechargable

batteries.

-On the inside of the battery compartment door you will find a

label on which to write your Set-Up code after your ONE FOR ALL

is set up for your device. Please write down your code for easy,

future reference.

WWW.ONEFORALL.COM 4

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 4

WWW.ON EFORALL. COM 5

9Number Keys

The Number keys (0-9, -/--, AV) provide functions just like your

original remote, such as direct access programme selection. If your

original remote uses one/two digit input switching (-/-- symbol), this

function can be obtained by pressing the -/-- key. If your original

remote has an 10 key, this function can also be found under the -/--

key. If your original remote has an 20 key, this function can also be

found under the AV key.

10 Teletext and Fastext Keys

The text keys are used to access the Teletext functions of your

television. Of course, your television must have Teletext capability.

TEXT ON: Puts the television in the Teletext mode.

TEXT OFF: Switches the television back to regular viewing mode.

On some televisions, this may be done by pressing the TEXT ON key

several times.

EXPAND: Shows the top half of the Teletext page in larger letters.

By pressing again, you can see the bottom half of the Teletext page

enlarged. To return to regular Teletext viewing, press the EXPAND

key again, or press the TEXT ON key, depending on your television.

HOLD/STOP: Stops changing pages.

16:9: The 16:9 key allows you to have wide screen view (if available

on your original remote).

MIX: Shows tel etext and re gular television simultaneously.

You may also use this key for s ubtitling. On some televisions this

function is ac cessed by pressing the t ext key twice.

After accessing the text mode, the bottom row of the keys marked red,

green, yellow and blue, allow you to access the Fastext

functions of your television. If on your original remote control these

keys are used for Menu navigation, the ONE FOR ALL Fastext keys

may operate in the same way.

Important note: For a more detailed explanation of Teletext and Fastext,

please refer to the manual of your television. Remember, different televisions

control Teletext and Fastext features in different ways. Not all of the Teletext

functions may be available for your particular model.

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 5

6WWW.O NEFORALL.CO M

Direct code set up

To set up the ONE FOR ALL for your television:

1Find the code for your device in the Code list (page 73 - 81).

Codes are listed by brand name.

The most popular code is listed first. Make sure your

device is switched on (not on standby).

2 Press and hold the MAGIC key until the POWER key

(LED) blinks twice (the red light (LED) underneath the

POWER key will blink once then twice).

3Enter your (four-digit device code) using the number

keys. The red light will blink twice.

4Now, aim the ONE FOR ALL at your device and

press POWER. If your device switches off, the ONE

FOR ALL is ready to operate your device.

5Turn your device back on and try all the remote’s functions to ensure

they are working properly. If the functions do not work properly,

repeat steps 1-4 using another code listed under your brand.

6 If your device does not respond, follow steps 1 to 4 with

each code listed for your brand. If none of the codes listed

for your brand operate your device, or if your brand is not

listed at all, try the search method described on page 7.

7 Write your code in the four boxes provided in the battery

compartment and on page 8 for easy future reference.

Setting up the ONE FOR ALL

Before you start, please read these instructions carefully

Important notes:

- Most TV’s do not switch on pressing the POWER key. Please try pressing a

“number” key or the “TV-text off” key to switch your TV back on.

- Some codes are quite similar. If your device does not respond or is not

functioning properly with one of the codes, try another code listed under

your brand.

6WWW.O NEFORALL.CO M

ONE FOR ALL



Acura

Admiral

Adyson

Agazi

AGB

Agef

Aiko

0009

0087, 0093, 0363, 041

0217, 0216

0264

0516

0087

0216, 0009, 0037, 0

0037, 0274

0361, 0208, 0371,

__ __

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 6

WWW.ON EFORALL. COM 7

Search Method

If your device does not respond to the ONE FOR ALL after you have tried

all the codes listed for your brand, try searching for your code. The Search

Method allows you to find the code for your device by scanning through all

the codes contained in the memory of the ONE FOR ALL. The Search

Method may also work if your brand is not listed at all.

To search for your TV code:

1Switch your television on (not on standby).

2 Press and hold the MAGIC key until the POWER key

(LED) blinks twice (the red light (LED) underneath the

POWER key will blink once then twice).

3Press 9 9 1. The red lig ht will blink twice.

4Next, press POWER.

5Aim the ONE FOR ALL at your Television. Now press CH+

over and over, until your Television turns off (everytime

you press the CH+ key the ONE FOR ALL will send out a

POWER signal from the next code contained in the memo-

ry). You may have to press this key many times (up to 150

times) so please be patient. If you skip past a code, you

can go to the previous code(s) by pressing the CH- key.

Remember to keep pointing the ONE FOR ALL at your

Television while pressing this key.

6As soon as your television turns off, press MAGIC to store

the code.

Once you have Set-Up your ONE FOR ALL, you can blink back your

SET-UP CODE for future reference.

Example: To blink out your Television code:

1 Press and hold the MAGIC key until the POWER key

(LED) blinks twice (the red light (LED) underneath the

POWER key will blink once then twice).

2Press 9 9 0. The red lig ht will blink twice.

3For the first digit of your four-digit code, press 1and

count all the red blinks. If there are no blinks, the digit is

"0".

4For the second digit, press 2and count all the red blinks.

If there are no blinks, the digit is "0".

5For the third digit, press 3and count all the red blinks.

If there are no blinks, the digit is "0".

6For the fourth digit, press 4and count

all the red blinks. If there are no blinks, the digit is "0".

Now you have your four-digit code.

Important note:

- Most TV’s do not switch on pressing the POWER key. Please try pressing a

“number” key or the “TV-text off” key to switch your TV back on.

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 7

Problem & Solution

Problem:

Your brand is not listed

in the code section?

The ONE FOR ALL does

not operate your

device ?

The ONE FOR ALL is not

performing commands

properly?

Problems changing

channels?

The ONE FOR ALL does

not respond after

pressing a key?

The red light does not

blink when you press

a key?

Solution:

Try the search method on page 7.

A) Try all the codes listed for

your brand. B) Try the search

method on page 7.

You may be using the wrong

code. Try repeating the Direct

Set-Up using another code listed

under your brand or start the

search method over again to

locate the proper code.

Enter the programme number

exactly as you would on your

original remote.

Make sure you are using new

batteries and are aiming the one

for all at your device.

Replace batteries with 2 fresh,

new “AA” alkaline batteries.

8WWW.ONEFORALL.COM

Quick Code Reference

Write down the code for your device in the boxes below and in the

battery compartment for quick and easy reference.

Brand Code

1._________________________

■

■■

■ ■

■

Depending on the functions of your original remote control, the ONE FOR

ALL may operate the colour and brightness settings of your television.

Colour (+) = Press and release MAGIC then hold Volume (+)

Colour (-) = Press and release MAGIC then hold Volume (-)

Brightness (+) = Press and release MAGIC then hold Channel (+)

Brightness (-) = Press and release MAGIC then hold Channel (-)

Colour and Brightness

Note: You have 5 seconds to press the Volume or Channel keys for colour or

brightness adjustment after pressing MAGIC.

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 8

WWW.ONEFORALL.COM 9

Customer Service

If you still have questions about the operation of your ONE FOR ALL 1

universal remote and could not find the answer(s) in the TroubleShooting

section, you may want to contact the customer service department for

assistance.

You may care to visit our Internet-site: www.oneforall.com

Our internet-site has many advantages:

- 24 hours access

- no waiting time

- page for Frequently Asked Questions

- info about the ONE FOR ALL product range

Before contacting us, by Fax, E-mail or Phone, make sure you have

the required information available by filling in the table below.

What do we need to know before you contact us:

1That you have the ONE FOR ALL 1 URC-7210.

universal remote.

2The date of purchase (.........../.........../...........).

3A list of your equipment/models: (see example below).

Device Brand Device Remote SET-UP

model nr. model nr. code

TV Sony KV-25C5D RM-883 1505 (example)

Type/model numbers can often be found in your equipment

owner’s manual or on the factory plate behind the device.

4. Then Fax, E-mail or Dial us:

In the UK

E-mail : ofahelp@uebv.com (*)

Fax : +31 53 432 9816

Tel. : 0901-5510010 (£ 0,50 per minute)

In Ireland In Australia

E-mail : ofahelp@uebv.com (*) E-mail : ofahelp@uebv.com (*)

Fax : +31 53 432 9816 Fax : 03 9672 2479

Tel. : 016015986 Tel. : 1 300 888 298

In South Africa In New Zealand

E-mail : [email protected] E-mail : ofahelp@uebv.com (*)

Fax : 011 298 2302 Fax : (06) 878 2760

Tel. : 0860 100551 Tel. : 0508 ONE 4 ALL (663 4 255)

Tel. : 011 298 2300

(*) Just send a blank message, you’ll get auto-reply.

Trouble Shooting

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 9

10 WWW.ONEFORALL.COM

EINSTELLUNG

ABBILDUNG DER ONE FOR ALL TV FERNBEDIENUNG

BATTERIEWECHSEL

FUNKTIONSTASTEN

EINSTELLUNG DER ONE FOR ALL

Direkte Code Einstellung 12

Code-Suchlauf 13

EINSTELLCODES

Fernseher 73

FARBE & HELLIGKEIT

SCHNELLES CODE NACHSCHLAGWERK

PROBLEM & LÖSUNG

Inhaltsverzeichnis

Ihre ONE FOR ALL

Die ONE FOR ALL -Verpackung enthält:

• die ONE FOR ALL TV Fernbedienung

• das ONE FOR ALL Handbuch

Das Handbuch ist in zwei Teile unterteilt: Einstellungs anleitung und Geräte-

Codes. Bewahren Sie das Handbuch sorgfältig auf, da Sie es in der

Zukunft vielleicht nochmal benötigen.

Ihre ONE FOR ALL benötigt zwei neue AA/LR6-Alkali batterien.

Sie können mit Ihrer ONE FOR ALL einen Fernseher fernbedienen.

Deutsch

704983_URC-7210_E_10T:BIG Ea y_1_E_10T 01-06-2007 15:57 Pagina 10

Inhaltsverzeichnis

Sprachen:

Andere One Forall Universalfernbedienung Handbücher

One Forall

One Forall DVD EXPERT URC-4041 Bedienungsanleitung

One Forall

One Forall URC 4700 Access 4 Bedienungsanleitung

One Forall

One Forall Zapper URC-6512 Bedienungsanleitung

One Forall

One Forall URC-44 Bedienungsanleitung

One Forall

One Forall 3 Zapper Bedienungsanleitung

One Forall

One Forall URC-4220 Installations- und Betriebshandbuch

One Forall

One Forall URC-3720 Bedienungsanleitung

One Forall

One Forall URC-7721 Bedienungsanleitung

One Forall

One Forall Zapper URC-6520 Bedienungsanleitung

One Forall

One Forall URC-7240 Bedienungsanleitung

One Forall

One Forall URC-3300 Bedienungsanleitung

One Forall

One Forall A/V Producer URC 8800 Bedienungsanleitung

One Forall

One Forall URC 3050 Bedienungsanleitung

One Forall

One Forall URC-6210 Bedienungsanleitung

One Forall

One Forall URC 7120 Bedienungsanleitung

One Forall

One Forall URC-6230 Bedienungsanleitung

One Forall

One Forall URC-7525 Bedienungsanleitung

One Forall

One Forall URC-3440 Bedienungsanleitung

One Forall

One Forall 16662 Bedienungsanleitung

One Forall

One Forall URC-6211 Bedienungsanleitung

One Forall

One Forall URC-3550 Bedienungsanleitung

One Forall

One Forall iLifeTV Bedienungsanleitung

One Forall

One Forall Kameleon Bedienungsanleitung

One Forall

One Forall URC 1810 Bedienungsanleitung

Beliebte Universalfernbedienung Handbücher anderer Marken

Pronto

Pronto Peel Bedienungsanleitung

GE 24929 Bedienungsanleitung

Radio Shack

Radio Shack Wireless Remote Control System Bedienungsanleitung

AUVIO

AUVIO Universal Home Theater Remote Bedienungsanleitung

Philips

Philips Icon SRU4106 Bedienungsanleitung

THOMSON

THOMSON ROC4309 Bedienungsanleitung

Philips

Philips pm625S Bedienungsanleitung

GE RM94931 Bedienungsanleitung

RCA

RCA RCU600WMS - Universal Remote Control Bedienungsanleitung

Blackweb

Blackweb BWB17AV002 Bedienungsanleitung

Marmitek

Marmitek DoorGuard 300 Bedienungsanleitung

Chunghop

Chunghop RM-L618 Bedienungsanleitung

GE RM24965 Bedienungsanleitung

Anderic

Anderic KTN828 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Bedienungsanleitung

Medion

Medion E74023 Bedienungsanleitung

intensity

intensity RM02A Bedienungsanleitung

GE RM24950 Bedienungsanleitung
