Onlogic HX310 Bedienungsanleitung
HX310 / HX330 Industrial Computer
Product Manual
Revision History
Revision History
Date
First release of HX300 manual
8/4/2021
Update errata list
8/12/2021
Table of Contents
1 - System Overview 5
1.1 - System Introduction 5
1.2 - In-box Accessories 5
1.3 - Product Specifications 6
1.4 - Exterior Features and Dimensions 8
1.4.1 - Front I/O 8
1.4.2 - Back I/O 8
1.4.3 - Helix 300 Dimensions (HX310 / HX330) 9
1.5 - System Block Diagram 10
2 - I/O Definitions 11
2.1 - Front I/O Definition 11
2.2 - Rear I/O definition 15
2.3 - Motherboard Connectors 18
3 - Mounting Instructions 27
3.1 - Wall Mount & DIN Rail Mounting 27
3.1 - VESA Mounting 30
2
4 - Power Management 31
4.1 - Wake-Up Events 31
4.2 - Protection Circuitry 31
5 - Regulatory Compliance 32
CE 32
FCC Statement 32
ISED (Innovation, Science and Economic Development Canada) 32
6. - Appendices 32
6.1 - Appendix A: Power consumption 32
6.2 - Appendix B: Isolated DIO guide 34
6.3 - Appendix C: BIOS manual 34
6.4 - Appendix D: CAN user guide 34
6.4 - Appendix E: System thermal results 36
6.5 - Appendix F: Expansion port pinout 39
6.5.1 - M.2 B-Key 39
6.5.2 - M.2 E-Key 40
6.5.3 - M.2 M-Key 41
6.5.4 - mPCIe 42
6.6 - Appendix G: Safety Information 43
6.6.1 Safe use and installation instructions 43
6.6.2 Précautions et guide d’installation 44
6.7 - Appendix H: Errata 44
IP-263: RS422 and RS485 Require SerCx2 44
Overview 44
Description 45
Workaround 45
Resolution 45
3
1 - System Overview
1.1 - System Introduction
The Helix 300 Series harnesses the enhanced power and capabilities of Intel "Elkhart Lake"
Celeron and Pentium processors in a low profile fanless system built for the challenges of
the IoT edge. With support for triple independent 4K displays, a 0°C to 50°C operating
temperature range, and a wealth of configuration options, the Helix 310 and Helix 330 were
engineered with versatility in mind. The systems also feature compliance testing for IT
Equipment and pre-compliance testing for 60601-1 medical EMC and safety.
1.2 - In-box Accessories
●4x Rubber Feet
●Power cable retention
If you purchased additional items such as mounting brackets, power supplies or terminal
block connectors, they will be located in the system box or within the outer shipping carton.
All drivers and product guides can be found on the corresponding product page. For more
information on accessories and additional features, visit the Helix Product pages.
Helix 310 Product Page: https://www.onlogic.com/hx310/
Helix 330 Product Page: https://www.onlogic.com/hx330/
4
1.3 - Product Specifications
Model
HX310
HX330
System Dimensions
196x37x120 mm (TBD)
same
Motherboard
Dimensions
114 x 175 mm max (TBD)
same
CPU
Celeon N6211 6W, 2 Cores or Pentium
J6426 - 10 W, 4 Cores
Celeon N6211 6W, 2 Cores or Pentium
J6426 - 10 W, 4 Cores
Memory
2 x SO-DIMM (2 x 16 max Dual Channel) 32
GB Total
2 x SO-DIMM (2 x 16 max Dual Channel) 32
GB Total
LAN controller
1x Intel GPY115 or 2x Intel GPY115 with
Pentium J6426
1x Intel GPY115 or 2x Intel GPY115
Expansion
1x M.2 2280/60/3042 B-Key (PCIe x 1, USB
3.0, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe / USB 2.0)
1x M.2 2280 M-key (PCIe x 2, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe / USB 2.0)
1x M.2 2280 M-key (PCIe x 2, SATA III)
Optional Add On
Module
4G/5G, CAN Bus, Coral VPU
Dual LAN
Back I/O
3x Full size DisplayPort 1.4 with CEC
support by optional add-on module
1 x Gb LAN (2 Gb LAN optional with
Pentium J6426)
2x USB 3.1 (Host Gen 2)
2x USB 2.0
Terminal Block Option - Punch out
3x Antenna punch outs
Barrel Jack with 12~24 V input
1x Kang Yang SWPL-3 (Power Cable
Retention)
Kensington Lock
3x Full size DisplayPort 1.4 with CEC
support by optional add-on module
1 x Gb LAN (2 Gb LAN optional with Pentium
J6426)
2x USB 3.1 (Host Gen 2,)
2x USB 2.0
Terminal Block Option - Punch Out
3x Antenna punch outs
Barrel Jack with 12~24 V input
1x Kang Yang SWPL-3 (Power Cable
Retention)
Kensington Lock
Front I/O
1x Power LED button (recessed power
button)
1x USB 2.0
1x USB 3.1 (Host Gen 2)
2FF-Sim slot (Mapped to the B-Key)
1x Serial port (RS-232/422/485)
1x Power LED button (recessed power
button)
2x Gb LAN
1x USB 2.0
1x USB 3.1 (Host Gen 2)
2FF-Sim slot (Mapped to the B-Key)
1x Serial port (RS-232/422/485)
ModBay (Front
plate)
2 DB9 COM ports/CANBus
3 antenna punch outs
10-pin terminal block (for 8-pin DIO)
Dual LAN RJ45
Onboard Headers &
Connectors
1x Battery on a cable
2x Serial Header, RS 232/422/485
1x USB 2.0 (1x5 header)
1x 2-Pin power for devices 5V (J32)
4 Pin in for Terminal Block Power
1x Battery on a cable
2x Serial Header, RS 232/422/485
1x USB 2.0 (1x5 header)
1x 2-Pin power for devices 5V (J32)
4 Pin in for Terminal Block Power
5
Auto Power On (AT/ATX Mode Select)
2x6 connector for GPIO x 8 with Interrupt
(including 1 pin power, 2 pin ground, 1
keyed)
CAN-FD Bus 2x5-pin header with key (to use
standard DB9 cable)
2x6 pin CEC header
Auto Power On (AT/ATX Mode Select)
2x6 connector for GPIO x 8 with Interrupt
(including 1 pin power, 2 pin ground, 1
keyed)
CAN-FD Bus 2x5-pin header with key (to use
standard DB9 cable)
2x6 pin CEC header
Voltage Input
rated input: 8~24V via DC jack or onboard
4-pin power header; +/- 10% tolerance
rated input: 8~24V via DC jack or onboard
4-pin power header; +/- 10% tolerance
Power Input
Barrel Jack with optional 4-pin Terminal
Block (support remote switch, Barrel Jack
covered when not in use.)
Barrel Jack with optional 4-pin Terminal
Block (support remote switch, Barrel Jack
covered when not in use.)
Power Protections
TVS for power input protection
Moderate disturbance protection with a TVS
LC filter. Alternate DC supplies should be IT
equipment rated when possible.
TVS for power input protection
Moderate disturbance protection with a TVS
LC filter. Alternate DC supplies should be IT
equipment rated when possible.
BIOS
Insyde
Insyde
Operating Systems
Windows 10 IoT Enterprise, Ubuntu 20.04
LTS (TBD), Yocto
Windows 10 IoT Enterprise, Ubuntu 20.04
LTS (TBD), Yocto
Special Features
Watchdog timer
RTC
PTT in BIOS,
TPM header, Nuvoton NPCT750AABYX
Hardware Autopower on
Watchdog timer
RTC
PTT in BIOS,
TPM header, Nuvoton NPCT750AABYX
Hardware Autopower on
Mounting Options
DIN (edge mount)
Wall
VESA
Desk
DIN (edge mount)
Wall
VESA
Desk
Thermal Standards,
Subject to Change
through RFI and RFQ
steps
System Operating Temperature: 0-50C
Board Operating Temperature: 0-65C
Storage Temperature: -10-85C
Operating Humidity: 0% - 90%
System Operating Temperature: 0-50C
Board Operating Temperature: 0-65C
Storage Temperature: -10-85C
Operating Humidity: 0% - 90%
6
1.4.3 - Helix 300 Dimensions (HX310 / HX330)
8
1.5 - System Block Diagram
9
2 - I/O Definitions
2.1 - Front I/O Definition
The HX310 with the DIO option is pictured.
The HX330 with the additional dual LAN option is pictured.
Power Button / Power LED
The front power button can be used to turn on and off the Helix system. The power button is a
momentary contact button with a blue LED backlight used to display the status of the system. A
single press while the system is on will initiate a graceful shutdown operation from the OS. Pressing
and holding the button for 4 seconds while the system is running will cause a hard reset of the
system. The system can be woken by a single press of the power button from any state.
10
