Optibase MGW 2000e Bedienungsanleitung

MGW 2000e

MPEG-2 Video Streaming Server

(Version 4.0)

Quick Start Guide

Trademarks

Optibase and VideoPlex are trademarks of Optibase Inc.

Microsoft, MS, and MS-DOS, ActiveMovie, Windows, Windows 2000 and

Windows XP are trademarks of Microsoft Corporation.

IBM PC, XT, AT are registered trademarks of International Business Machine

Corporation.

All other trademarks mentioned in this manual are the sole property of their

respective manufacturers.

Published 2006, Israel

MPEG-2 Packaged Media Notice

Any use of this product other than consumer personal use in any manner that

complies with the MPEG-2 standard for encoding video information for

packaged media is expressively prohibited without a license under applicable

patents in the MPEG-2 Patent portfolio. The required license is available from

MPEG LA, L.L.C., 250 Steele Street, Suite 300, Denver Colorado 80206.

Notice

Information in this document is subject to change without notice. Optibase

Inc. and Optibase Ltd. assume no responsibility for any errors that may appear

in this manual. Companies, names and data used in examples herein are

fictitious unless otherwise noted. No part of this document may be copied or

reproduced in any form, or by any means, electronic or mechanical, for any

purpose, without the express written permission of Optibase Inc. Optibase

makes no warranties with respect to this documentation and disclaims any

implied warranties of merchantability or fitness for a particular purpose. From

time to time changes may occur in the file names and in the files actually

included on the distribution disks. Optibase makes no warranties that such

files or facilities, as mentioned in this documentation, exist on the distribution

disks or as part of the materials distributed.

Safety Instructions

Use the following safety guidelines to help protect your MGW

2000e unit from potential damage and to ensure your own

personal safety.

When using MGW 2000e

As you operate MGW 2000e, observe the following safety

guidelines

Note

Do not open the MGW 2000e unit, as this will void your warranty. MGW

2000e does not contain any user serviceable parts.

•Before installing MGW 2000e, unplug the system to help

prevent electric shock or system board damage. Certain

system board components continue to receive power any

time MGW 2000e is connected to AC power.

•To help prevent electric shock, plug the power cable into

properly grounded sources. Use only properly grounded

extensions and adaptors as the need arises.

•Use only a UL Recognized power cord.

•Make sure nothing rests on your MGW 2000e power cable

and that the cables are not located where they can be

stepped or tripped over.

•Do not spill food or liquids on your MGW 2000e unit.

•Do not push any objects into free slots of your MGW 2000e

unit. Doing so will damage your MGW 2000e unit and can

cause fire or electrical shock by shorting out interior

components.

•Keep your MGW 2000e unit away from radiators and heat

sources. Also, do not block cooling vents. Avoid placing

loose papers underneath your MGW 2000e unit. Do not

place your MGW 2000e unit in a closed-in wall unit or on a

bed, sofa, or rug.

•When you disconnect a cable, pull on its connector or on its

strain relief loop, not on the cable itself. Some cables have a

connector with locking tabs; if you are disconnecting this

type of cable, press in on the locking tabs before

disconnecting the cable. As you pull connectors apart, keep

them evenly aligned to avoid bending any connector pins.

Also, before you connect a cable, make sure both

connectors are correctly oriented and aligned.

•ESD Warning: Normal handling precautions should be

taken to avoid static discharge.

MGW 2000e Overview

MGW 2000e transmits multiple channels of live TV and video

over IP networks. It can receive up to six live analog signals,

encode them in real-time to MPEG-1 or MPEG-2 and then

stream them over an IP network in multicast or unicast mode.

With MGW 2000e, organizations can utilize their IP networks

for business TV, training and corporate communications.

MGW 2000e encodes, multiplexes and transmits up to 6 live

MPEG-2 and MPEG-1 streams.

A Web-based remotely controlled management application lets

you configure, control and operate multiple streams.

MGW 2000e ships with two network interface cards (NIC)

enabling you to transmit streams over one NIC and use the

second one to configure and operate MGW 2000e.

This guide instructs you on how to connect MGW 2000e to a

network and initialize for the first use. It also guides you in

encoding one live channel from an analog or digital source with

pre-set default parameters.

Detailed instructions on setting streaming and encoding

parameters can be found in the user manual.

MGW 2000e Quick Start Guide

MGW 2000e Components

Chassis Components Description

MGW 2000e chassis ‘Housing’ of the MGW 2000e system.

Power cord that fits your local Din

socket.

Connects to MGW 2000e's power

connector

(not supplied by Optibase).

Network cables - shielded category 5 Connect MGW 2000e's NICs A and

B to two different network segments

(not supplied by Optibase).

19”, 23” or ETSI mounted bracket Rack-mounts MGW 2000e.

RS-232 cable Connects PC to MGW 2000e.

USB disk The USB disk is optional. It connects

to MGW 2000e and provides space

to store video clips

(not supplied by Optibase).

Encoding Modules Description

MGE-100 Encodes video from Composite and

S-Video sources at SIF and QSIF

resolutions and audio from

unbalanced audio sources.

MGE-200 FD1 720 Encodes video from Composite and

S-Video sources at SIF, QSIF, HD1

2/3 D1, 3/4 D1 and FD1 resolutions

and audio from unbalanced sources.

MGE-200D FD1 720 Like MGE-200 FD1 720, but encodes

SDI video sources and unbalanced

and AES3 sources.

MGE-200 Low Latency Supports Optibase's low latency

optimized microcode for encoding at

a reduced latency.

Encoding Module Components Description

Video BNC cable Connects a Composite or SDI

source.

S-Video MiniDIN cable Connects an S-Video source.

Audio Stereo MiniJack cable Connects an unbalanced source.

RCA Coaxial cable Connects an AES3 source.

Table 1: MGW 2000e Components

MGW 2000e Quick Start Guide

Getting Started

This section describes how to unpack and initialize MGW

2000e. It instructs you on encoding and transmitting a UDP

stream under default conditions by using one encoding module

and MGW 2000e Director.

For instructions on encoding and transmitting RTP streams,

refer to the user manual.

Unpacking MGW 2000e

1. Choose a dry location for MGW 2000e, which complies

with the requirements regarding temperature specified in

the user manual.

2. Unpack MGW 2000e and its components carefully and

make sure that you have all the required components

available.

3. Desk-mount or rack-mount MGW 2000e.

Power Supply

MGW 2000e operates at 90/260V AC. The power cord connects

to the power connector on MGW 2000e’s rear panel. MGW

2000e recognizes your local voltage automatically.

MGW 2000e does not ship with a power cord. You will have to

purchase a power cord that fits your local DIN socket.

MGW 2000e Quick Start Guide

Installing an Encoding Module in MGW 2000e

Before you start operating MGW 2000e, you have to install one

of the encoding modules listed in Table 1.

For instructions on installing encoding modules, refer to chapter

2 in the user manual.

For tables showing where to connect sources, refer to page 17.

User Authorization

MGW 2000e operates from two user platforms. Table 2

illustrates their access authorization and the tasks they can

perform. For additional tasks performed by the users, refer to

the user manual.

User Password Task Remarks

Administrator Administrator Initializes MGW 2000e

via HyperTerminal from

a separate PC.

Connects via

RS-232.

Configures MGW

2000e via Telnet from a

PC in the network.

Connects

through the

network

Operates MGW 2000e

using MGW 2000e

Director.

Connects

through the

network.

MGW2000Guest -- Views the configuration

using MGW 2000e

Director and previews

content that is being

encoded.

Connects

through the

network.

Table 2: MGW 2000e’s User Profile

Note

•Disconnect the power cable from the power connector prior to

performing any task on the MGW 2000e unit.

•Avoid touching inside free slots as this may cause electrical hazards.

Touching inside free slots may also damage your MGW 2000e unit.
