ITEM NO: DKM01B (DKM1BT+VDKM01BR) DVI KVM & USB, RS232 , IR, Audio CAT5
Extender over IP
The DKM01B DVI KVM, USB with Analog audio, RS232, and IR CAT5 extender design for extends and
distribute all signals over one CAT5e up to 150 meters, with local HDMI monitor output. It provides
superior video quality up to 1920 x 1200 resolutions, and using cost effective Cat5e cable, instead of DVI,
RS232 cables, for an easy, neater and reliable installation. The local and remote units can be connected
together for a Point-to-Point connection via CAT5e/6 cable or a Point-to-Many connection via a managed
network switch. It is optimized for applications at broadcasting system, multimedia display and multi-data
sharing, digital signage, home network integration, and industrial control, hospital, education, security, Matrix
network system and system control over RS232 and equipment control over IR.
Features:
Extend and distribute DVI signal with bi-directional RS232, USB signal,IR and analog audio signals
over LAN.
Supports resolutions up to 1080p Full HD and 1920 x 1200 (WUXGA) 32bpp@ 60 Hz
Transmission range up to 150M over CAT5e, 180M over CAT6.
Support window based management software, using PC computer for easy setting input/output
link.
Support Android/iOS APP control.
Receiver input source select could be from IR remote control or front panel button.
Built in RS232 distribution function, to send RS232 signal from one TX to multiple RX.
Supports 2-way RS232 commands at baud rate 115200 (control software on a PC, or other
automated control system hardware) to control devices attached to the matrix using RS232. Full
Duplex data communication.
Built in Bi-Directional analog audio transmission (only in point to point mode ).
Built in Bi-Directional IR.
DKM01BT transmitter unit built in DVI local loop output.
VDKM01BR receiver unit with 4 ports USB devices (1 port USB 1.1 & 3 Port USB 2.0), to extend
USB peripheral devices, such as flash disk, hard disk, keyboard, mouse, etc.
Use IGMP and Jumbo frame protocol Gigabit Switch Hub to do HD signal distribution and transmission.
Support point to point and multiple source devices to multi-display connections via Gigabit network
switch.
The system could be works with any combination on HDMI, DVI, VGA transmitters and receivers.
Support total of transmitter unit up to 16 pieces, receiver unit over 254 pieces based on the number of
ports on your network switch.
Perfect for large scale remote HD content access and security monitoring systems, digital signage
applications.
Optional model:
SR01: Signal repeater for longer distance application.
Application and Installation View:
Point to Point Direct Connection: (Extender)
