Optoma EX 615 Projector Settings

These are the reference settings and connections for normal SCC operation. Updated Jan 2013 with

revised brightness & degamma settings see associated post on web “Dicentra/Laptop/Optoma

settings, updated Nov 2012”.

Connections

There are 4 leads and a remote control which we keep in a plastic bag to make it easier to pull them

in and out of the tight-fitting Projector bag.

 Mains lead

 VGA lead

 USB lead

 Audio lead

Connect from the PC's External VGA output to EX615 VGA1 In

 You will need to switch the PC's External VGA output on, probably by toggling one of the

Function Keys, perhaps using a Fn Shift key as well. On my Acer 3610 Laptop, use Fn + F5

keys to toggle between laptop only, laptop & projector, and projector only.

Optionally connect the EX615 sub-min USB soc et to a standard size PC USB socket

 This enables the Projector Remote Control to operate the PC's next/last slide function,

simulating the laptop's Page Up/Down and Arrow Left/Right keys. It does not work on

every software programme.

Optionally connect the Audio Lead from the PC sound output to the Projector VGA1 Audio 1 In

 Remember there are volume controls on both the PC and the Projector. The Projector

setting can be accessed via the menu system or the remote control volume button. There is

also a mute button on the remote control.

To turn the projector off, press the Power Button twice. The first time brings up a box at the bottom

right of the screen asking “Turn Off? Do not turn the projector back on immediately after turning

off. You need to avoid turning the projector off inadvertently by pressing the Power button on the

remote control!

Reference Settings

IMAGE TAB

Display Mode User 2

Brightness, Contrast 48%, 50%

(was 50%, 50%)

Sharpness 15

Advanced...

Degamma PC (was Film)

Brilliant Color 0

Color Temp Warm

Color Settings All 0

Color Space Auto

Input Source All ticked

Note: The User 2 settings use the initial default settings from Movie mode. Any further adjustments

by the user in User2 will be saved in this mode for future use.

DISPLAY TAB

Format Auto

Overscan/Zoom 0

Image Shift Horiz/Vert 0

Keystone 0

SETUP TAB

Language English

Projection Projector on table and

Audience in front of screen

Menu location Centre

Signal...

Phase 27

Frequency 0

H 0

V 0

Security... Off

Projector ID 0

Mute Off

Volume Any, e.g. 4

Audio Input Default

Advanced...

Logo Optoma

Logo capture Don't use

RS232 RS232

Network We don't use this

Wireless Off

OPTIONS TAB

Source Lock Off

High Altitude Off

Information Hide Off

Keypad Off

Background Color Blue

Advanced...

Direct Power On Off

Auto Power Off 0

Sleep Timer 0

Power Mode (Standby) Active

Lamp Settings...

Lamp Hours

Lamp Reminder On

Brightness Mode Standard

Lamp Reset No
