Waterproof Phone Holder with Wireless Charger - Installation Manual
www.bikephoneholder.com
Stick 3M Tape on the
handlebar then set-up plastic
clamp adapter with correct
diameter 7/8" (22m),
1" (25.4mm), 1,1/4" (32mm).
Then Tighten the screw
Put the holder ring to the clamp
ball and Press phone holder to
the mounting ball gently.
Adjust the angle and complete
the installation.
Made in PRC
ORCAS Customer Team
If you have any question or issue please feel free to contact us
Specifications
Product Code
EAN
Power Output
Input
IP Protection
Color
Compatible
Orcas M18W
5060907340031 (3.5-5.8 inches SMALL size)
5060907340048 (6-7 inches LARGE size)
Max. 15W Qi Charging
12-24v DC
IP65
Black
Motorbike, Bike, Scooter
:
:
:
:
:
:
:
Scan the QR code to watch the installation video or visit
www.bikephoneholder.com
S
L
145 mm
165 mm
72 mm
80 mm
SIZE Lengh
Lengh
Wide
Wide
10 mm
10 mm
High
High
Please Check
Your Phone
Dimensions
!
Note: If your phone case is thick more than 10mm,
do not use with your phone case!
Step 1Step 2Step 3
Step 4 - Power Connection
Warning: Don’t use batteries higher than 24V
Connect the wire as shown in below the picture.
When using motorbike battery as input, both
USB-C and wireless charger can work well.
Dear customer, thank you for choosing ORCAS phone holder.
We always keep improving ourselves to keep customer satisfaction high. We are sure
that you will like our product. If for any reason you won't satisfied with our product,
please let us know and we will make sure to provide you with the necessary return as
soon as possible. All of our customers who want to buy this product pay much attention
to user experience and will be very happy if you share your user experience with us.
www.bikephoneholder.com
